Summary of Contents for WAGO IP 350
- Page 1 Manual Plotter IP 350...
-
Page 2: Table Of Contents
1. Introduction 2. Scope of supply 3. Product overview 4. Setting up the Vario Plotter IP 350 4.1. Location 4.2. Connections 5. Operation 6. Cleaning and product care 7. Accessories 8. Troubleshooting 9. Technical Information IP 350 10. Safety instructions... -
Page 3: Introduction
Introduction Thank you for purchasing the IP 350, a flexible plotter for the quick and simple labeling of marking elements Rugged construction in stylish aluminum Labeling area 440 x 305 mm Easy-change holder plates to suit a variety of marking elements... -
Page 4: Scope Of Supply
Please verify that you have received all the items supplied with your labelling device(see list below). Please retain the packaging in case you need to return the device. The following items are supplied as standard: 1) WAGO Plotter IP 350 2) Power supply with corresponding mains power cable 3) Centronics parallel cable... -
Page 5: Product Overview
Product overview 1) Plotting area 2) Pen station 3) Sealed storage holders in pen station 4) Start-up writing area 5) Pin stops for holding plates 6) Vacuum supply of the individual segments 7) Penholder / pen receptacle 8) Lowering unit 9) Vacuum connection point 10) Mains connection 11) Gate terminal for external devices... -
Page 6: Setting Up The Vario Plotter Ip 350
Please ensure that the connections on the right-hand side of the device are accessible at all times. Position the IP 350 firmly on the work surface where is to be used, ensuring it is level. Please ensure that the writing arm can move freely and is not obstructed by other objects. -
Page 7: Operation
PC. 2. Clear buffer If the IP 350 contains data the yellow indicating light will light up. You can delete this data by pressing the 'Clear buffer' key. For this action, the system must be in stop mode (red light on). - Page 8 These key functions are not used for normal operation. They are intended solely for the adjustment settings and servicing. 6. Placing the holder plates in the WAGO Plotter There are eight pin stops on the plotting area where up to four different holder plates can be loaded.
- Page 9 Different size holding plates: 7. Placing the elements in the holding plates Choose the appropriate holding plate for the elements to be labelled and carefully insert the elements into the holding plates. To insert the elements, remove the holding plates to ensure a firm fitting of the elements.
-
Page 10: Cleaning And Product Care
Cleaning and product care Protect the IP 350 from dust and other dirt. When not in use, cover the plotter. A special cover is supplied as accessory. Wipe the device occasionally after use with a dry, lint-free cloth or a mild cleaning agent. -
Page 11: Accessories
Accessories To adjust the sealing station in the pen station: WAGO plotter pens 258-226 – nib thickness 0.18 mm 258-227 – nib thickness 0.25 mm 258-228 – nib thickness 0.35 mm 258-229 – nib thickness 0.50 mm WAGO non-returnable pens 258-326 –... - Page 12 INSERTING AND ADJUSTING A SEALING UNIT: Insert the new sealing unit into the pen station. Press the sealing unit carefully up to the limit-stop into the aluminum tube. Then adjust the sealing unit using the key, until the key is parallel with the plotter surface.
-
Page 13: Troubleshooting
Troubleshooting If your WAGO plotter is not functioning correctly, please check the following: Device fails to switch on. Check whether the mains plug and connecting plug are plugged in correctly. Check whether the socket being used is functioning properly. Is the green light on the power supply illuminated? If not, please replace the power supply. -
Page 14: Technical Information Ip 350
Technical Information IP 350 Type of plotter: Flatbed plotter Maximum plotting area: 442 mm x 296 mm Plotting speed: Max. 40 mm/s Plotter pen: Special plotter pens with HP holding plate Ports: Parallel (Centronics) / USB Level 1.1 Control language:... -
Page 15: 10. Safety Instructions
10. Safety instructions Keep the operating instructions in a safe place. This device complies with all recognized technical standards and all applicable safety regulations. The mains power supply used must correspond with that specified on the name plate. Use in dry conditions only. Disconnect the device from the mains socket by pulling the plug, not the cord. - Page 16 WAGO Kontakttechnik GmbH & Co. KG P.O. Box 28 80 · D-32385 Minden Hansastraße 27 · D-32423 Minden Phone +49 571/ 887-0 +49 571/ 887-169 info@wago.com www.wago.com Support Hotline ProServe: Phone +49 571 887-630 +49 571 / 887-8630 support.proserve@wago.com Plotter IP350...
