Summary of Contents for HELEX HI-FIRE FORMA
- Page 1 Pag.1 OPERATION AND INSTALLATION MANUAL HELEX HI-FIRE COLLECTION For mantles: FORMA COLOR ESTILO ESFERA LIGERO...
-
Page 2: Table Of Contents
Pag.2 Contents General Page 3 - Contents of package - First firing - Guarantee 1. Instructions for using the Hi-fire. Page 4 1.1 Control knobs and other functions of gas regulator block and remote control. 1.2 Operation Lighting procedure . 1.3 Adjusting the flame height 1.4 Shut-off procedure 1.5 Remote control with thermostat and timer... -
Page 3: Contents Of Package
Pag.3 General The Hi- fire free-standing gas stove offers you the attractive sight of a living fire, combined with the comfort and convenience of remote control operation. The complete appliance is supplied with the surround and/or accessories of your choice. Please refer to the installation instructions for the surround and/or accessories in question, which are packaged separately from the Hi- fire stove. -
Page 4: Instructions For Using The Hi-Fire
Pag.4 Instructions for using the Hi-fire. Control knobs and other functions of gas regulator block (see page 13 diagram 2). • Pilot light ignition knob (A1) on gas regulator block • Manual control gas fire (A2) on gas regulator block This gas regulator is fitted with a manual operating system and a radiographic one. - Page 5 Pag.5 • Wait or press button (B-4) to switch to automatic mode • A sensor in the transmitter measures the room temperature. The controler compares the room temperature with the set temperature and sends a signal to the receiver to turn the gas valve motor, which adjusts the flame height accordingly.
-
Page 6: If The Remote Control Does Not Work
Pag.6 The temperature is controlled by activating the motor for a specific length of time to adjust the appropriate flame height. This time is calculated by the transmitter and depends on variables such as room size, heater capacity, battery power, etc. Therefore, a few cycles are necessary before an optimum is achieved. If a low flame is sufficient to provide enough warmth to the room, then the appliance will cycle between low fire and off. -
Page 7: Connection To The Gas Pipe
Pag.7 Connection to the gas pipe Place the basic unit in its intended position and then mount the surround. Adjust the basis unit to ensure that the mounting holes in the surround and the unit are aligned (do not attach yet). Having done this, you can decide on the position of the gas pipe at the same time. -
Page 8: Concentric Duct System
Pag.8 Concentric duct system The concentric duct system consists of a inner duct, 100 mm in diameter, and a outer duct, 150 mm in diameter. These ducts are fitted concentrically; discharge of combustion gas is through the inner duct and supply of com- bustion air to the appliance is between the inner and outer ducts. -
Page 9: Connection To Conventional Chimney
Pag.9 Roof duct without bends (see illustration 6, page 15). A direct course without bends is possible to a maximum length of X=12 metres, measured from the connection to the appliance. The minimum length is 3 metres. The outlet can be positioned anywhere in the roof surface, whether flat or sloping;... -
Page 10: Components Of The Appliance
Pag.10 Fitting roofduct • The outlet can be anywhere in the roof surface (outlet and inlet in identical pressure area) and must meet the regulations currently in force. • A roof plate for flat roofs or a lead roof flashing for sloping tiled roofs can be used to make a watertight duct. -
Page 11: Putting The Ceramic Log Set In Place
Pag.11 Putting the ceramic log set in place The “Oak Set” has already been put in position in new appliances and secured with a string. This string does not have to be removed, it will burn away of its own accord. Only if maintenance work has to be done to the burner, pilot light or thermocouple, the window should be re- moved by dismantling the six glazing tees. - Page 12 Pag.12...
- Page 13 Pag.13...
- Page 14 Pag.14...
-
Page 15: Illustrations Page 11 Till
Pag.15... -
Page 16: Cc Flue System Piece Code Numbers
Pag.16 CC FLUE SYSTEM PIECE CODE NUMBERS DESCRIPTION MEASURE ( mm ) CODE NR. CODE NR BLACK PAINTED STAINLES STEEL ALUMINIUM ** LEAD A) CONCENTRIC PIPE 1000 12965000 12965500 12965002 12965502 12965004 12965504 B) CONCENTRIC BEND 45° SET 12965012 12965512 C) WALL BRACKET 12965024 12965524... -
Page 17: Important Tips
Pag.17 Important tips for heating with gas-fired or wood-fired stoves and fireplaces. Prevent discolouration of walls and ceilings! There are always dust particles in the air in every living space, even if it is regularly vacuumed! These particles are clearly vis ible in rays of sunlight and they will not bother you as long as the concentration of particles in the air remains low. - Page 18 This is also the date of inception of the guarantee. The guarantee lapses if changes have been made to the appliance without the advance knowledge and written permission of Helex / Thermocet, and when an appliance has been shipped without sound packaging and transport protection.
