Meguiar’s G110 Instruction Manual

Variable speed professional electric dual-action polisher
Hide thumbs

Advertisement

Table of Contents

Instruction Manual
The Model and Serial No. located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. _____________________________
Type _________________________________
Serial No. ______________________________
Professional
Electric
Dual-Action
Polisher
MODEL G110/G220
Variable Speed
Please make certain that the person
who is to use this equipment
carefully reads and understands
these instructions before starting
operations.
IMPORTANT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G110 and is the answer not in the manual?

Questions and answers

Jan Willumsen
April 7, 2025

is the motor in g220 high voltage (240/110 V)?

0

Summary of Contents for Meguiar’s G110

  • Page 1 Professional Electric Dual-Action Polisher MODEL G110/G220 Variable Speed Instruction Manual IMPORTANT The Model and Serial No. located on the main Please make certain that the person housing of the tool. Record these numbers in the who is to use this equipment spaces below and retain for future reference.

  • Page 2: Definitions - Safety Guidelines

    EC – Declaration of conformity G110/G220 Meguiar’s declares that this power tool has been designed in compliance with: 98/37/EEC, 89/336/EEC, 72/23/EEC, EN 50144, EN 55014-2, EN 55014, EN-61000-3-2 & EN 61000-3-3.
  • Page 3 Check power source voltage to ensure correct electrical voltage before plugging in power tools. Model G110 should only be used with 110V power sources, while models G220 and G220EU should only be used with 220V - 240V power sources.
  • Page 4 appropriate conditions will reduce personal injuries. c) Avoid accidental starting. Be sure the switch is in the off-position before plugging in. Carrying power tools with your finger on the switch or plugging in power tools that have the switch on invites accidents. d) Remove any adjusting key or wrench before turning on the power tool.

  • Page 5: Additional Specific Safety Rules

    ADDITIONAL SPECIFIC SAFETY RULES Hold power tools by insulated gripping surfaces whenever • performing an operation where the tool may contact hidden wiring or its own cord. Contact with a “live” wire will make exposed metal parts of the tool “live” and may result in electric shock to the operator.
  • Page 6 WARNING: Use of this tool can generate and/or disburse dust, which may cause serious and permanent respiratory or other injury. Always use NIOSH/OSHA approved respiratory protection appropriate for the dust exposure. Direct particles away from face and body. WARNING: ALWAYS USE SAFETY GLASSES. (ANSI Z87.1) and (CAN/ CSA Z94.3) Everyday eyeglasses are NOT safety glasses.

  • Page 7: Variable Speed

    OPERATING INSTRUCTIONS TO START AND STOP POLISHER CAUTION: Make certain the switch is in the “OFF” position, and the power source is the same as specified on the tools nameplate. 2. Connect the tool to the power source. 3. Slide the switch button (A), Fig. 1, forward to start the motor.

  • Page 8: Usage Tips

    G110/G220/G220EU Using The Polisher DIRECTIONS: Wash and dry your car completely. Pull vehicle into covered area. Evaluate the surface to determine which products are necessary. Choose the correct product. Apply product to pad, place machine on surface, turn machine on and begin applying product. (Do not turn machine on until it is on the surface!) Work product evenly and thoroughly into surface.

  • Page 9: Maintenance

    MAINTENANCE KEEP TOOL CLEAN Periodically blow out all air passages with dry compressed air. All plastic parts should be cleaned with a soft damp cloth. NEVER use solvents to clean plastic parts. CAUTION: Wear safety glasses while using compressed air. FAILURE TO START Should your tool fail to start, check to make sure the prongs on the cord plug are making good contact in the outlet.
  • Page 10 Professional Electric Dual-Action Polisher MODEL G110/G220 Fig. 8 WARNING: Electrical repairs should only be attempted by trained repairmen. Contact your local Meguiar’s customer service office.

  • Page 11: Parts Description

    PARTS DESCRIPTION Refer to corresponding #’s in Fig. 8 on opposite page. DESCRIPTION DESCRIPTION BACKING PLATE PINION SPINDLE O RING SCREW BEARING 627 WASHER ROTOR COUNTERWEIGHT SCREW CLIP BRUSH HOLDER BEARING6001 BRUSH SPRING WASHER CARBON BRUSH SCREW BAFFLE WASHER SCREW ECCENTRIC WASHER BEARING MOUNT ECCENTRIC HOUSING...
  • Page 12 MEGUIAR’S LIMITED ONE YEAR WARRANTY ® This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, Meguiar’s will replace, at it’s option, the product covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
  • Page 13 W A R N I N G : Some dust created by power sanding, sawing, grinding, drilling and other construction activities contain chemicals known to cause cancer, birth defects, or other reproductive harm Some examples of these chemicals are: • Lead from lead-based paint •...
