Operator's Manual
-------------------------------------------------------------------
Flexible Inspection Camera –SNAKESCOPE
Thanks for chose our flexible inspection camera-SNAKESCOPE. Please read the operation manual
carefully before using this product.
SNAKESCOPE Overview
Protective Cover
AV OUT
Mode (Contrast/Brightness)
Camera / LED
Power Button
Handstrap Loop
Installing the Flexible Camera Shaft
1.Pull the cover in the SNAKESCOPE back.
2.Take the Detent to Tab and meet the connector.
3.Pull the cover forward and rotate the cover in the
SNAKESCOPE.
Installing the accessories
Four accessories (pin, mirror, hook and magnet) attached with the package to the imager
head are the same way. To connect hold the imager head, slip the end of the accessory,
over the flats of the imager head.
(SSV-700)
LCD Screen
Control Buttons
Rotate 180º
Screen Angle Adjustment
Handle Angle Control
LED + Controls
-
Handle
Battery Cover
Inserting/Removing the Battery
1. Pull the battery cover down.
3. Put the battery pack to SNAEKSCOPE
body as following to the direction of
"Arrow" sign.
* Change the batteries only with Alkaline AA batteries.
Operation of Button
Rotate 180º
To rotate the Screen on the Panel, press "
will return to the normal.
Mode (Contrast/Brightness)
To adjust the Contrast value or Brightness in the LCD Screen, press "
Then, to adjust the value, press"
the value will be adjusted automatically.
26
Brightness
TV Out
To display SNAKESCOPE moving picture out to TV or other displayer, connect
Video-out cable into SNAKESCOPE's AV Out port and video in port on the TV
or other displayer.
Video in port
TV or Displayer
TV Out System sets into NTSC or PAL on shipment from factory and can not be changed
*
into other TV out system.
2. Take the Battery cartridge out and
insert four (4) AA batteries,
as shown.
4. Insert battery cartridge into the
handle and close the battery cover.
" button.If press again, the screen
" "
"Button. Press and hold the"
19
Contrast
AV out
port
Video out cable
SNAKESCOPE
" Button.
" "
"button,
