KBC WESII Series User Manual

Wireless ethernet system
Hide thumbs
Table of Contents

Advertisement

Quick Links

WESII
Wireless Ethernet System
WESII Series

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WESII Series and is the answer not in the manual?

Questions and answers

Summary of Contents for KBC WESII Series

  • Page 1: User Manual

    WESII Wireless Ethernet System WESII Series User Manual...

  • Page 2: About This Users Guide

    WESII User Manual About This Users’ Guide Intended Audience This manual is intended for people who want to configure any of the WESII Series. You will need a basic knowledge of TCP/IP and wireless topology. Related Documentation Quick Start Guide The Quick Start Guide is designed to help you get up and running.

  • Page 3: Document Conventions

    The WESII units may be referred to as the ‘device’, the ‘product’ or the ‘system’ in this guide. <ENTER> denotes enter or return on your keyboard. <*****> denotes that you need to select that option. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 2 of 140 www.kbcnetworks.com...

  • Page 4: Safety Warnings

    OBSERVE WARNINGS: All warnings in the operating instructions should be carefully followed. Do not make any modifications to the WESII unit, Power Injection Module (PIM), or any other KBC Networks electronic device, as the unit(s) will no longer comply with legal regulations and therefore void its warranty.

  • Page 5: Fcc Required Information

    Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Changes or modifications not expressly approved by KBC could void the user’s authority to operate the equipment.

  • Page 6: Industry Canada Restrictions

    Les antennes utilisées pour ce transmetteur doivent être installé en considérant une distance de séparation de toute personnes d'au moins 37.2 cm et ne doivent pas être localisé ou utilisé en conflit avec tout autre antenne ou transmetteur. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 5 of 140 www.kbcnetworks.com...

  • Page 7: Ce Regulatory Statement

    5250 MHz to 5350 MHz or 5470 MHz to 5725 MHz. In addition devices using the 5600 – 5650 MHz band are subject to a 10 minute Channel Availability Check (CAC). The following table shows how this can affect connection times for certain frequencies: Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 6 of 140 www.kbcnetworks.com...
  • Page 8 5670 2 mins 5675 2 mins 2 mins 2 mins 5680 2 mins 5685 2 mins 2 mins 5690 2 mins 5695 2 mins 2 mins 2 mins 5700 Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 7 of 140 www.kbcnetworks.com...

  • Page 9: Environmental Restrictions Of Wireless Devices

    In addition, should a particular environment restrict the usage of the WESII in any way, KBC offers a thirty (30) day return policy from date of shipment to the original purchaser if goods are returned in an ‘as new’ condition.

  • Page 10: Rohs/Weee Compliance Statement

    Remove cover screws attaching top cover to radio module cavity. Remove tightening screws for printed circuit board (PCB). Take out all PCBs. Note: When a product reaches the end of its life – return to KBC. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 9 of 140...

  • Page 11: General Public License Statement

    WESII User Manual General Public License Statement You may have received from KBC Networks products that contained – in part – free software (software licensed in a way that ensures your freedom to run, copy, distribute, study, change and improve the software). Such products include the WESII Series of products.

  • Page 12: Table Of Contents

    ANTENNA OPTIONS……………………………………………………………………………………….20 3.1 Omni-directional antennas………………………………………………………………………………………………………………..20 3.2 Integrated directional antenna options……………………………………………………………………………………………..20 3.3 External directional patch antenna options………………………………………………………………………………………..21 POINT-TO-POINT KITS…………………………………….……………………….………………….22 MOUNTING INSTRUCTIONS…………………………………………………………………………..23 5.1 Pole and wall-mount for integrated directional WESII units………………………………………………………………23 Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 11 of 140 www.kbcnetworks.com...
  • Page 13 11.1 Connecting to the WESII GUI using a PC……………………………………………………..…………………..………………..97 11.2 WESII Menu Options………………………………………………………………………………………………………..……………….99 TROUBLESHOOTING……………………………………………………………………………………136 12.1 Visual Inspection……………………………………………………………………………………………..……………………………..136 12.2 Test Cable Connections…………………………………………………………………………………………………………………...136 12.3 GUI Tools…………………………………………………………………………………………………………………………………………136 12.4 Hard reset to defaults……………………………………………………………………………………………………………………..137 12.5 Contact KBC Technical Assistance…………………………………………………………………………………………………….138 WARRANTY………………………………………………………………………………………………….139 Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 12 of 140 www.kbcnetworks.com...

  • Page 14: Overview

    1.1.1. WESII The KBC WESII Series is a wireless transmission system that operates in the license free 2.4GHz & 5GHz bands and also in the 4.9GHz Public Safety band (only available in the US). The units are available as PoE or non-PoE with a range of antennas to suit applications.

  • Page 15: General Technical Specification

    Azimuth: Horizontal 56°, Vertical 62° Elevation: Horizontal 38°, Vertical 26° Directional integrated patch Dual polarization 17dBi (4.9GHz & 5GHz) Beamwidth: Azimuth: Horizontal 30°, Vertical 33° Elevation: Horizontal 17°, Vertical 17° Territory specific. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 14 of 140 www.kbcnetworks.com...
  • Page 16 1995+A4; 1996+A1; 1997 EN 300 328-2 EN 300 826 EN 301 489-17 EN 301 893 R&TT Directive (1999/5/EC) Assumes an ideal environment with maximum signal rates & within receive sensitivity specification. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 15 of 140 www.kbcnetworks.com...

  • Page 17: Typical Configurations

    The WESII units are available to work in the following configurations: Point-to-point • Point-to-multipoint • Relay • Wi-Fi Access Point • Mixed systems • 2.1 Point-to-Point 2.1.1 Non-PoE WESII 2.1.2 PoE WESII Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 16 of 140 www.kbcnetworks.com...

  • Page 18: Point-To-Multipoint

    WESII User Manual 2.2 Point-to-multipoint 2.2.1. Non-PoE WESII 2.2.2. PoE WESII Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 17 of 140 www.kbcnetworks.com...

  • Page 19: Relay

    WESII User Manual 2.3 Relay 2.4 Wi-Fi Access Point Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 18 of 140 www.kbcnetworks.com...

  • Page 20: Mixed Systems - Wesii & Meshii

    WESII User Manual 2.5 Mixed systems – WESII & MeshII Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 19 of 140 www.kbcnetworks.com...

  • Page 21: Antenna Options

    This is an integral directional patch antenna option for 2.4GHz operation. The antenna is dual polarized. The beamwidth is: Azimuth: Horizontal 56°, Vertical 62° Elevation: Horizontal 38°, Vertical 26° Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 20 of 140 www.kbcnetworks.com...

  • Page 22: External Directional Patch Antenna Options

    PAT5M. The antenna is supplied as a separate unit that contains 1 x 17dBi patch antenna and 2 x 1m cables. The antenna is dual polarized. The beamwidth is: Azimuth: Horizontal 30°, Vertical 33° Elevation: Horizontal 17°, Vertical 17° Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 21 of 140 www.kbcnetworks.com...

  • Page 23: Point-To-Point Kits

    WESII-KT-ED 5GHz, point-to-point kit with encoder & 2 x 5GHz WESII point-to-point decoder units + KBC encoder & decoder WESII-KT-P5 5GHz, point-to-point kit with 5 port PoE 2 x 5GHz WESII point-to-point switch & narrow temperature range units + ESUL5P-D + DRP-120-...

  • Page 24: Mounting Instructions

    This equipment must be installed in accordance with the instructions found in this manual. The orientation must be as depicted below. Failure to comply with these instructions will invalidate warranty. 5.1 Pole and wall-mount for WESII units Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 23 of 140 www.kbcnetworks.com...
  • Page 25 Position the WESII unit to face the WESII unit at the other end of the link. • Carry out the alignment process – see Section 10.4 for instructions and Section 7 • for LED status information. When in the best position, tighten. • Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 24 of 140 www.kbcnetworks.com...

  • Page 26: Connections

    5. LAN port (RJ-45) 6. Mounting block 7. Reset to default button Rear view Note: See Section 11.2.2.3 for details of how to carry out a hard reset to default settings. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 25 of 140 www.kbcnetworks.com...

  • Page 27: Power Connections

    OUT – Connect to the WESII unit IN – Connect to the Ethernet device For extreme temperature conditions there is also a KBC Networks Industrial DIN Rail power supply available, part number MDR-20-24. These units provide 24W at 24Vdc. These units need to be purchased separately, for further details please contact KBC Networks.
  • Page 28 Power Sourcing Equipment (PSE) such as an Ethernet switch which provides power on the Ethernet cable. There are a number of different Ethernet switches options with PoE available from KBC Networks, these can be purchased separately. Please contact KBC Networks for further information.

  • Page 29: Led Status

    LED 6 comes on again and flashes intermittently showing that a connection is • established. After approximately 1 – 2 minutes RSSI LEDs 1, 2, 3 & 4 will light depending on • the level of signal strength. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 28 of 140 www.kbcnetworks.com...

  • Page 30: Cable Assembly

    100m (325 feet); however, for a non-PoE WESII unit the PIM can be located anywhere along the overall 100m of cable. KBC Networks recommends shielded Ethernet cables for the cable connecting the PIM to the WESII unit. Any cable exposed to the elements should also be outdoor rated.
  • Page 31 8- Solid Brown A cable configured with the 568-A color code on one end and the 568-B color code on the other end is an Ethernet standard crossover cable. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 30 of 140 www.kbcnetworks.com...

  • Page 32: Setting Up A Basic Link

    5 – 10m between them to avoid saturation. The following sections deal with setting up basic links for the three different firmware versions: US & Canada • EMEA • Australian • Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 31 of 140 www.kbcnetworks.com...

  • Page 33: Setting Up A Basic Point-To-Point Link - United States & Canada

    Apply power to the PSE device and allow 60 seconds for the unit to boot Step 3: Set the static IP address on the laptop to the 192.168.1.x subnet. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 32 of 140 www.kbcnetworks.com...
  • Page 34 See Section 11.2.6.1 Manual setting for details for manually setting the channel frequency. Ensure this box is checked Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 33 of 140 www.kbcnetworks.com...
  • Page 35 Enter the Client MAC address here Step 9: Apply Settings Select: <Apply Settings> Step 10: Save the changes. Select: <Save> Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 34 of 140 www.kbcnetworks.com...
  • Page 36 Set the static IP address on the laptop to the 192.168.1.x subnet. Step 4: Open a web browser to access the Client on its 192.168.1.201 IP address; this is the default IP address for the Client unit. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 35 of 140 www.kbcnetworks.com...
  • Page 37 Wi-Fi are disabled. Step 6: Basic Wireless Select: <Radio 1> under the ‘BASIC WIRELESS’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 36 of 140 www.kbcnetworks.com...
  • Page 38 Ensure that the Channel Spectrum Width is on 20/40M & ensure that the Remote AP-ESSID is set to the same as the Host unit. Ensure these are the same as the Host unit you want to connect to Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 37 of 140 www.kbcnetworks.com...
  • Page 39 Select Site Survey to find the WESII Host you want to connect to. Select: <Site Survey> Step 10: The Site Survey will search for the KBC WESII Host that you want to connect to. Click on the actual MAC address of the Host unit you want to connect to.
  • Page 40 Host on its 192.168.1.200 default address. Unless a more advanced set up is desired, the antennas are configured for installation at this point. For advanced configuration see Section 11. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 39 of 140 www.kbcnetworks.com...

  • Page 41: Setting Up A Basic Point-To-Point Link - Emea

    Apply power to the PSE device and allow 60 seconds for the unit to boot Step 3: Set the static IP address on the laptop to the 192.168.1.x subnet. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 40 of 140 www.kbcnetworks.com...
  • Page 42 Wi-Fi are disabled. Step 6: Basic Wireless Select: <Radio 1> under the ‘BASIC WIRELESS’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 41 of 140 www.kbcnetworks.com...
  • Page 43 WESII User Manual Step 7: Selecting the correct country Note: It is the user’s responsibility to ensure that the correct country is selected. KBC Networks accepts no liability for incorrectly configured equipment. Select: the country where the unit will be operating Step 8: Apply the country setting.
  • Page 44 See Section 11.2.6.1 Manual setting for details for manually setting the channel frequency. Ensure this box is checked Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 43 of 140 www.kbcnetworks.com...
  • Page 45 Client unit or on the rear label on the outside of the unit. The MAC address must be entered in the following format: xx:xx:xx:xx:xx:xx. Enter the Client MAC address here Step 12: Apply Settings Select: <Apply Settings> Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 44 of 140 www.kbcnetworks.com...
  • Page 46 WESII User Manual Select: <Save> Step 13: Save the changes. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 45 of 140 www.kbcnetworks.com...
  • Page 47 Apply power to the PSE device and allow 60 seconds for the unit to boot Step 3: Set the static IP address on the laptop to the 192.168.1.x subnet. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 46 of 140 www.kbcnetworks.com...
  • Page 48 Wi-Fi are disabled. Step 6: Basic Wireless Select: <Radio 1> under the ‘BASIC WIRELESS’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 47 of 140 www.kbcnetworks.com...
  • Page 49 Select the correct country. Select: the country where the unit will be operating Note: It is the user’s responsibility to ensure that the correct Country is selected. KBC Networks accepts no liability for incorrectly configured equipment. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 48 of 140 www.kbcnetworks.com...
  • Page 50 WESII User Manual Step 8: Apply the country setting. Select: <Apply Settings> Select: <Save> Step 9: Save Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 49 of 140 www.kbcnetworks.com...
  • Page 51 WESII User Manual Step 10: Check the Remote AP-Lock to MAC box Check this box Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 50 of 140 www.kbcnetworks.com...
  • Page 52 Select Site Survey to find the WESII Host you want to connect to. Select: <Site Survey> Step 13: The Site Survey will search for the KBC WESII Host that you want to connect to. Click on the actual MAC address of the Host unit you want to connect to.
  • Page 53 Host on its 192.168.1.200 default address. Unless a more advanced set up is desired, the antennas are configured for installation at this point. For advanced configuration see Section 11. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 52 of 140 www.kbcnetworks.com...

  • Page 54: Setting Up A Basic Point-To-Point Link - Australia

    Set the static IP address on the laptop to the 192.168.1.x subnet. Step 4: Open a web browser to access the Host on its 192.168.1.200 IP address; this is the default IP address for the Host unit. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 53 of 140 www.kbcnetworks.com...
  • Page 55 See Section 11.2.6.1 Manual setting for details for manually setting the channel frequency. Ensure this box is checked Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 54 of 140 www.kbcnetworks.com...
  • Page 56 Client unit or the rear label on the outside of the unit. The MAC address must be in the format: xx:xx:xx:xx:xx:xx. Enter the Client MAC address here. Step 9: Apply Settings Select: <Apply Settings> Select: <Save> Step 10: Save the changes. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 55 of 140 www.kbcnetworks.com...
  • Page 57 Set the static IP address on the laptop to the 192.168.1.x subnet. Step 4: Open a web browser to access the Client on its 192.168.1.201 IP address; this is the default IP address for the Client unit. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 56 of 140 www.kbcnetworks.com...
  • Page 58 Wi-Fi are disabled. Step 6: Basic Wireless Select: <BASIC WIRELESS> under the ‘NETWORK’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 57 of 140 www.kbcnetworks.com...
  • Page 59 Ensure that the Channel Spectrum Width is on 20/40M & ensure that the Remote AP-ESSID are set to the same as the Host unit. Ensure these are the same as the Host unit you want to connect to Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 58 of 140 www.kbcnetworks.com...
  • Page 60 Select Site Survey to find the WESII Host you want to connect to. Select: <Site Survey> Step 10: The Site Survey will search for the KBC WESII Host that you want to connect to. Click on the actual MAC address of the Host unit you want to connect to.
  • Page 61 Host on its 192.168.1.200 default address. Unless a more advanced set up is desired, the antennas are configured for installation at this point. For advanced configuration see Section 11. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 60 of 140 www.kbcnetworks.com...

  • Page 62: Setting Up A Basic Point-To-Multipoint Link - United States & Canada

    Connect a second Ethernet cable from another port on the PSE to the laptop or PC LAN port. Apply power to the PSE device and allow 60 seconds for the unit to boot Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 61 of 140 www.kbcnetworks.com...
  • Page 63 Wi-Fi are disabled. Step 6: Basic Wireless Select: <Radio 1> under the ‘BASIC WIRELESS’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 62 of 140 www.kbcnetworks.com...
  • Page 64 Clients so that each group operates on a different frequency. See Section 11.2.6.1 Manual setting for details of how to manually set the channel frequency. Ensure this box is checked Manual-WESII-Rev1403_p63 Copyright © KBC Networks 2014 Page 63 of 140 www.kbcnetworks.com...
  • Page 65 Apply power to the PSE device and allow 60 seconds for the unit to boot Step 3: Set the static IP address on the laptop to the 192.168.1.x subnet. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 64 of 140 www.kbcnetworks.com...
  • Page 66 Wi-Fi are disabled. Step 6: Basic Wireless Select: <Radio 1> under the ‘BASIC WIRELESS’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 65 of 140 www.kbcnetworks.com...
  • Page 67 IP address will be 192.168.1.201. Type in a new IP address on the 192.168.1.xx subnet eg. 192.168.1.8. For a site example see Section 10. Client default IP address NETWORK: Basic Network Type in a new IP address on the 192.168.1.xx subnet Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 66 of 140 www.kbcnetworks.com...
  • Page 68 WESII User Manual Step 8: Apply Settings and Save Save Apply Settings Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 67 of 140 www.kbcnetworks.com...
  • Page 69 Select Site Survey to find the WESII Host you want to connect to. Select: <Site Survey> Step 11: The Site Survey will search for the KBC WESII Host that you want to connect to. Click on the actual MAC address of the Host unit you want to connect to.
  • Page 70 Host on its 192.168.1.200 default address. Unless a more advanced set up is desired, the antennas are configured for installation at this point. For advanced configuration see Section 11. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 69 of 140 www.kbcnetworks.com...

  • Page 71: Setting Up A Basic Point-To-Multipoint Link - Emea

    Connect a second Ethernet cable from another port on the PSE to the laptop or PC LAN port. Apply power to the PSE device and allow 60 seconds for the unit to boot Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 70 of 140 www.kbcnetworks.com...
  • Page 72 Wi-Fi are disabled. Step 6: Basic Wireless Select: <Radio 1> under the ‘BASIC WIRELESS’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 71 of 140 www.kbcnetworks.com...
  • Page 73 Select the correct country. Select: the country where the unit will be operating Note: It is the user’s responsibility to ensure that the correct country is selected. KBC Networks accepts no liability for incorrectly configured equipment. Step 8: Apply the country setting.
  • Page 74 Clients so that each group operates on a different frequency. See Section 11.2.6.1 Manual setting for details of how to manually set the channel frequency. Ensure this box is checked Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 73 of 140 www.kbcnetworks.com...
  • Page 75 Apply power to the PSE device and allow 60 seconds for the unit to boot Step 3: Set the static IP address on the laptop to the 192.168.1.x subnet. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 74 of 140 www.kbcnetworks.com...
  • Page 76 Wi-Fi are disabled. Step 6: Basic Wireless Select: <Radio 1> under the ‘BASIC WIRELESS’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 75 of 140 www.kbcnetworks.com...
  • Page 77 Select: the country where the unit will be operating Note: It is the user’s responsibility to ensure that the correct Country is selected. KBC Networks accepts no liability for incorrectly configured equipment. A Country Code setting is not required for units purchased in the US.
  • Page 78 WESII User Manual Step 8: Apply the Country Code setting. Select: <Apply Settings> Select: <Save> Step 9: Save the settings. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 77 of 140 www.kbcnetworks.com...
  • Page 79 IP address will be 192.168.1.201. Type in a new IP address on the 192.168.1.xx subnet eg. 192.168.1.8. For a site example see Section 10. Client default IP address NETWORK: Basic Network Type in a new IP address on the 192.168.1.xx subnet Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 78 of 140 www.kbcnetworks.com...
  • Page 80 WESII User Manual Step 11: Apply Settings and Save Select: <Save> Apply Settings Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 79 of 140 www.kbcnetworks.com...
  • Page 81 Ensure this is the same as the Host unit you want to connect to. Ensure this is the same as the Host unit you want to connect Ensure this is on 20/40M Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 80 of 140 www.kbcnetworks.com...
  • Page 82 Select Site Survey to find the WESII Host you want to connect to. Select: <Site Survey> Step 14: The Site Survey will search for the KBC WESII Host that you want to connect to. Click on the actual MAC address of the Host unit you want to connect to.
  • Page 83 Host on its 192.168.1.200 default address. Unless a more advanced set up is desired, the antennas are configured for installation at this point. For advanced configuration see Section 11. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 82 of 140 www.kbcnetworks.com...

  • Page 84: Setting Up A Basic Point-To-Point Link - Australia

    Connect a second Ethernet cable from another port on the PSE to the laptop or PC LAN port. Apply power to the PSE device and allow 60 seconds for the unit to boot Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 83 of 140 www.kbcnetworks.com...
  • Page 85 Wi-Fi are disabled. Step 6: Basic Wireless Select: <BASIC WIRELESS> under the ‘NETWORK’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 84 of 140 www.kbcnetworks.com...
  • Page 86 Clients so that each group operates on a different frequency. See Section 11.2.6.1 Manual setting for details of how to manually set the channel frequency. Ensure this box is checked Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 85 of 140 www.kbcnetworks.com...
  • Page 87 Connect a second Ethernet cable from another port on the PSE to the laptop or PC LAN port. Apply power to the PSE device and allow 60 seconds for the unit to boot Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 86 of 140 www.kbcnetworks.com...
  • Page 88 Wi-Fi are disabled. Step 6: Basic Wireless Select: <BASIC WIRELESS> under the ‘NETWORK’ option from the left hand menu Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 87 of 140 www.kbcnetworks.com...
  • Page 89 192.168.1.xx subnet eg. 192.168.1.8. For a site example see Section 10. Client default IP address NETWORK: Basic Network Type in a new IP address on the 192.168.1.xx subnet Save Step 8: Apply Settings and Save Apply Settings Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 88 of 140 www.kbcnetworks.com...
  • Page 90 Select Site Survey to find the WESII Host you want to connect to. Select: <Site Survey> Step 11: The Site Survey will search for the KBC WESII Host that you want to connect to. Click on the actual MAC address of the Host unit you want to connect to.
  • Page 91 Host on its 192.168.1.200 default address. Unless a more advanced set up is desired, the antennas are configured for installation at this point. For advanced configuration see Section 11. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 90 of 140 www.kbcnetworks.com...

  • Page 92: Installing On A Site

    Fresnel zone, the wireless system may not transmit the signal the required distance. In a situation like this, the transmit and receive antennas need to be mounted on higher poles to get above the trees. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 91 of 140 www.kbcnetworks.com...
  • Page 93 9.1m 4 miles 92 feet 60 feet 6.4km 18.3m 10 miles 148 feet 100 feet 16.1km 45.1m 30.5m 30 miles 200 feet 48.3km 60.1m Note: all measurements are estimated. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 92 of 140 www.kbcnetworks.com...

  • Page 94: Spacing Required When Mounting Wesii Units

    See section 5 for mounting instructions. When mounting units in a relay configuration the following distances between units are required. Note: The operation of the units must be as depicted, failure to comply with these instructions will invalidate warranty. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 93 of 140 www.kbcnetworks.com...

  • Page 95: Cable Lengths When Installing Wesii Units

    If the port is a 10/100 port, you may require a crossover cable. A crossover cable is not necessary if the two PIMs connect into an Ethernet switch. Most cables used to connect the WESII system are configured using a straight-through color code. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 94 of 140 www.kbcnetworks.com...

  • Page 96: Aligning The Wesii Units

    IP address. To change the WESII unit’s IP addresses from their default (192.168.1.200 – Host, 192.168.1 201 – Client) see Section 11.2.6.1 Manual setting. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 95 of 140 www.kbcnetworks.com...

  • Page 97: Replacing/Adding A Wesii Module From/To The Existing Application

    Country Code and channel spectrum width settings must be configured to match the Host/ AP configuration with which it wants to connect. If a Client is being replaced in a point-to-point network see Section 9 to reconfigure the link. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 96 of 140 www.kbcnetworks.com...

  • Page 98: Graphical User Interface

    Note: Due to various port types, a crossover Ethernet cable may be required between the Ethernet device and ‘IN’ port on the PIM. KBC Networks recommends a crossover cable be available during set up, trouble-shooting and maintenance of the system.
  • Page 99 IP is correct and the link activity is established, the browser will prompt you to enter the User Name and Password. The User Name and Password are ‘admin’ / ‘admin’ (case sensitive). User Name: admin Password: admin Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 98 of 140 www.kbcnetworks.com...

  • Page 100: Wesii Menu Options

    Radio 1 ADVANCED WIRELESS • Radio 1 The WESII has the following menu options for Australian firmware: DIAGOSTICS • Status Services System NETWORK • Basic Network Basic Wireless Advanced Wireless Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 99 of 140 www.kbcnetworks.com...
  • Page 101 WESII User Manual 11.2.1 DIAGNOSTICS 11.2.1.1 Status The initial page displayed on the web browser GUI is the ‘Status’ screen. The individual sections and description are as follows: Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 100 of 140 www.kbcnetworks.com...
  • Page 102 The ‘LAN SETTING’ section shows the LAN MAC, Mode, IP Address, Gateway IP Address and LAN cable information. These are set in the ‘Basic Network’ menu option see Section 11.2.6. The Host/AP default configuration is: Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 101 of 140 www.kbcnetworks.com...
  • Page 103 If a connected WESII device is available on the RF link, its MAC address and other link details will also appear. This page assists in providing critical details needed for wireless link set up, trouble-shooting and/or maintenance. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 102 of 140 www.kbcnetworks.com...
  • Page 104 WESII User Manual Client Radio 1 tab: Host/AP Radio 1 tab: Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 103 of 140 www.kbcnetworks.com...
  • Page 105 In the screen shot below the important details are defined: MAC Address: the MAC address of the connected WESII unit. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 104 of 140 www.kbcnetworks.com...
  • Page 106 A reasonable RSSI for average deployments will be in the 40 to 50 range. A bare minimum RSSI that KBC Networks recommends to maintain an RF link for constant streaming video is no less than 20. If max TX and RX rates are established at lower RSSIs then the system is performing as optimally as possible in a harsh RF environment.
  • Page 107 Ping Utility: Use this tool to ping from within the WESII node. ARP Table: This allows you to view the ARP Table. Bridge Table: This allows you to view the Bridge Table. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 106 of 140 www.kbcnetworks.com...
  • Page 108 WESII User Manual 11.2.2 Services The ‘Services’ menu is where the tools to set-up trouble-shooting and maintenance are found. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 107 of 140 www.kbcnetworks.com...
  • Page 109 RF link to its mate radio. Though this tool limits down time it may only mask the greater environmental problems at the site. KBC Networks recommends trouble-shooting all system and connection issues before resorting to the ping watchdog tool.
  • Page 110 ‘Stop’ button below is clicked. Continuous pings will determine when a device has reconnected after either being rebooted or having left the network. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 109 of 140 www.kbcnetworks.com...
  • Page 111 The Bridge table displays the MAC addresses of the connected devices to the node. The table will indicate whether the device is local to the node or if it is connected via the RF connection through one of the WiFi radios. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 110 of 140 www.kbcnetworks.com...
  • Page 112 By Time Insert the time (according to the internal WESII clock) at which the system will reboot. Note: The internal clock cannot be set to match real time. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 111 of 140 www.kbcnetworks.com...
  • Page 113 Select the time zone of the node deployment and check the ‘Known Time Server’ box. Ensure that all the nodes connected are using the same Known Time Server. Select <Apply> and <Save> to initiate the NTP set up. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 112 of 140 www.kbcnetworks.com...
  • Page 114 11.2.2.9 Services: SYSTEM LOG When enabled the system will begin to log the connection status to the configured IP using Telnet via the default log port 514. Results are viewed in Telnet. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 113 of 140 www.kbcnetworks.com...
  • Page 115 11.2.3 System The ‘System’ page allows certain configuration and upgrade changes to be performed to the WESII system. KBC Networks recommends using the configuration backup to save the settings of each unit once any custom configurations are complete. 11.2.3.1 System: FIRMWARE UPGRADE To upgrade the WESII firmware, follow the procedures below: 1.
  • Page 116 Restoring to defaults will return the username and password to ‘admin’ / ‘admin’ see Section 11.2.3.3 Reset to defaults for default settings. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 115 of 140 www.kbcnetworks.com...
  • Page 117 Transmit Power: 23 dBm (North America) 19 dBm (all other countries) Local AP WPA Cipher: Local AP Preshared Key: 11111111 Long Range Parameters: Enabled RSSI LEDs: LED1=10; LED2=20; LED3=30; LED4=40 Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 116 of 140 www.kbcnetworks.com...
  • Page 118 (ex 00-01-1a-2b-3c-d5) which will be an invalid MAC if copied and pasted into the Host MAC lock function. Other potential changes will also be reset to defaults, contact KBC technical assistance for more details. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 117 of 140 www.kbcnetworks.com...
  • Page 119 Note: Only KBC Network nodes are shown on the topology page. If any node goes down within the network then it is shown in red after 100 seconds (default). If it then remains down for more than 200 seconds (default) the node entry will be removed from topology view.
  • Page 120 The Refresh button can be used to refresh the topology page manually however it is automatically refreshed every 60 seconds. The following browsers are supported: Firefox : 13.0.1 11.0, 10.0.2, 9.0.1 Internet Explorer: 9.0, 8.0 Safari: 5.1.5, 5.1.7 Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 119 of 140 www.kbcnetworks.com...
  • Page 121 If the system map were to be viewed from outside the network, then this will be an actual gateway. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 120 of 140 www.kbcnetworks.com...
  • Page 122 Note: the image size is limited to 120KB and must be in a JPEG or GIF format. The topology page will auto size to fit the uploaded image Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 121 of 140 www.kbcnetworks.com...
  • Page 123 Move the WESII nodes around on the page to represent their physical locations as shown below: Step 6: Once the image has been loaded and the nodes moved, select <Save> to store the page configurations in nonvolatile memory. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 122 of 140 www.kbcnetworks.com...
  • Page 124 WESII User Manual Note: The mouse hover over feature will display details for the radio as shown below: Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 123 of 140 www.kbcnetworks.com...
  • Page 125 The ‘Basic Network’ menu option allows the LAN IP, subnet mask and Gateway IP to be set as either static IPs on the network or configured automatically by a DHCP server. 11.2.5.1 Basic Network: LOCAL AREA NETWORK Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 124 of 140 www.kbcnetworks.com...
  • Page 126 If Static is selected enter the LAN IP, Netmask and Gateway IP using an available IP on the network. KBC Networks recommends obtaining valid unused IPs from the network administrator if the units will reside on the network. The WESII units can connect independently from the network structure and are not required to be configured as static IPs within the network subnet.
  • Page 127 Channel frequency selection and bandwidth options are set within the Basic Wireless: Radio 1 menu option. The Host/AP will connect to a Client provided that the SSID, MAC Lock (if applicable) and Country Code settings are the same. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 126 of 140 www.kbcnetworks.com...
  • Page 128 These menu option show the default settings for the Host and Client units. Host/AP Client In the AP mode the unit will connect with remote Client units which are configured with the same SSID, Country Code and Channel spectrum Width. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 127 of 140 www.kbcnetworks.com...
  • Page 129 ‘NG’ to show that the system is working to IEEE802.11g and IEEE802.11n specifications (2.4GHz operation and using MIMO technology). ‘NY’ to show that the system is working to IEEE802.11y and IEEE802.11n specifications (4.9GHz operation and using MIMO technology). Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 128 of 140 www.kbcnetworks.com...
  • Page 130 GI: Guard Interval Channel-Frequency: The frequency to be used can be either be selected automatically by the Host/AP based on the Country Code selection and Spectrum Width or manually. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 129 of 140 www.kbcnetworks.com...
  • Page 131 5650MHz band. If these frequencies are included the link connection time can increase to 10 mins due to Dynamic Frequency Selection (DFS) regulations see page 7. EMEA firmware version Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 130 of 140 www.kbcnetworks.com...
  • Page 132 To carry out a frequency site survey select <Interference Analyzer>. The Interference Analyzer is only found on the Host/AP unit and only available if a channel width of either 20M or 20/40MHz is selected. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 131 of 140 www.kbcnetworks.com...
  • Page 133 22dBi. The power output max for global deployments is 19dBm. Please check legal requirements according to the local regulatory domain for use with high gain parabolic, patch, sector or other antenna types. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 132 of 140 www.kbcnetworks.com...
  • Page 134 EMEA firmware version Note: It is the responsibility of the user to operate the system under the local regulatory domain requirements. KBC Networks recommends researching the regulations prior to deploying a license free wireless system. Local AP – Wireless Security The Local AP section is used to configure the Host/AP as an Access Point in order to connect using a laptop/PC via WiFi connection.
  • Page 135 In the example below, the WESII is configured for a 1600m (1 mile) connection. Both the Host/AP and Client units must be configured for the distance parameters: Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 134 of 140 www.kbcnetworks.com...
  • Page 136 The default setting for Noise Immunity is to be Enabled. Signal Strength Indicator (RSSI) The following are the default RSSI LED configurations. These parameters can be changed to any desired RSSI (0 through 100). Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 135 of 140 www.kbcnetworks.com...

  • Page 137: Troubleshooting

    12.3 GUI Tools See section 3 of this manual for the diagnostic tools available to use to determine the problem and probable solution. Contact KBC Networks for technical assistance. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 136 of 140 www.kbcnetworks.com...

  • Page 138: Hard Reset To Defaults

    (ex 00-01-1a-2b-3c-d5) which will be an invalid MAC if copied and pasted into the Host MAC lock function. Other potential changes will also be reset to defaults, contact KBC technical assistance for more details. Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 137 of 140 www.kbcnetworks.com...

  • Page 139: Contact Kbc Technical Assistance

    Our toll free technical assistance is available should you require additional assistance. KBC offers technical support over the phone or by way of e-mail to all KBC integrators, dealers and end users of the WES products. Our technical support hotline is available during regular US west coast business hours, Monday through Friday on all non-major holiday business days.

  • Page 140: Warranty

    KBC, to be defective in material or workmanship, KBC will repair or replace such part or portion at KBC’s option. The warranty period on the repaired or replaced part or portion of this product shall be limited to the unexpired term of the original warranty.
  • Page 141 Fax: 1-949-297-4933 KBC Networks Ltd. EMEA KBC Networks Ltd. Barham Court Teston, Maidstone Kent, ME18 5BZ United Kingdom Phone: +44(0)1622 618787 Fax: +44(0)20 7100 8147 Email: info@kbcnetworks.com Manual-WESII-Rev1403 Copyright © KBC Networks 2014 Page 140 of 140 www.kbcnetworks.com Web: www.kbcnetworks.com...
