- Page 1 HKM SWEEPER OPERATING INSTRUCTION MANUAL SPARE PARTS CATALOGUE November 2007...
- Page 2 Contents...
-
Page 4: General Information
General Information 1.1 Intended Purpose The HKM sweepers were specially devel o ped for sweeping and show c l e arance. Any other appl i cation should be discussed with the manufacturer prior to that use. Any damage caused by usage outside these areas are fully at the risk of the user. - Page 5 1.3 Technical data NOTE for engine s pecifications refer to the motor instruction booklet (included) Working width HKM 100 : 1000 mm HKM 120 : 1200 mm Distance between wheels 560 mm Height including engine 600 mm Brush diameter 330 mm Driving speed 2.5 –...
- Page 6 2. Safety 2.1 Basic safety rules This handbook contains safety information concerning the operation and maintenance and SHOULD BE READ PRIOR TO OPERATING OR MAINTAINING THE SWEEPER. Failure to observe these safety rules can endanger the operator and cause damage to the environment. Failure to conform to these rules removes all possible claims for damage.
- Page 7 2.4 Personnel qualification and training The sweeper may only be operated, maintained and repaired by competent persons, that have been fully informed about the associated dangers. T he area of responsibility, the competence and the monitoring of the personnel must be regul a ted by the operator. If the personnel do possess the necessary knowledge, then they are to be supervised and given instruction.
-
Page 8: Operation
3. Operation The HKM 100 and HKM 120 machines come in 2 cartons. Carton 1 – Main part with the motor mounted 1 Sweeper power component 2 Wheels 1 Cover 1 Power transmission cover 1 Packet containing: instructions and spares list, engine instructions & small components Carton 2 –... - Page 9 Tighten the nut on the brush rotational point carefully. Prepare the engine (read the engine handbook). The engine is delivered without any oil ( use 10 W 40). All HKM engines use 91 octane lead free petrol.
- Page 10 3.3 Notes on use Prior to starting the machine familiarise yourself with the controls. The machine has controls for brush and machine driving speed. T he brus h and drive operation levers are dead man levers and will go to the off position if released.
-
Page 11: Maintenance
4. Maintenance 4.1 General You have purchased a virtually free maintenance machine. Generally speaking the sweeper is service free apart from the motor. This means there is no general maintenance work. In order to keep the machine in good general working order and maintain the value of the machine the operator should note the following: Motor-oil level: Check before each machine use. - Page 13 Diagram 001...
- Page 14 HKM 100 / 120 Parts List Diagram 001...
- Page 15 Diagram 002...
- Page 16 HKM 100 / 120 Parts List Diagram 002...
- Page 17 Diagram 003...
- Page 18 HKM 100 / 120 Parts List Diagram 003...
- Page 19 Diagram 004...
- Page 20 HKM 100 / 120 Parts List Diagram 004...
- Page 21 Accessories For Collector For Snow Plough Note: The DIN and standard parts from this list are delivered predominantly in packing units. If the last place of the part is a "1“, then this means a packing unit of 10 pieces. Examples: 4HW A10 Z 1 =10 Star Washers DIN 125 10.5 4HU-A20 1 = 10 pieces snap ring for wave brush...
- Page 22 Imported and Distribu ted by:...
