  • Page 1 – – User Manual...

  • Page 2: Table Of Contents

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Contents Contents ........................iii List of Figures…......................vii List of Tables.........................ix About This Guide......................x Audience ............................ x Purpose ............................x How This Guide is Organized....................x Document Conventions......................xii Introduction........................13 Dynamix DC-16S/SA Overview......................
  • Page 3 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router System Administration with EmWeb................25 Log In with Embedded Web Interface ..................25 Embedded Web Interface Menu....................26 Default (Factory) Configuration Settings {Default Setting} ...........29 Displaying your Dynamix DC-16S/SA’s System Information {System Information} ....
  • Page 4 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Show Endpointcurr{ Endpointcurr }.................... 56 SHDSL Previous 15-MIN Performance Management {Pre-15min PM}........57 SHDSL Previous 1 Day Performance Management {Pre-1Day PM}......... 58 System Administration with CLI ..................60 Command Structure........................60 Calling Commands........................66 General Configuration ........................67...
  • Page 5 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Modifying Line Profile and Alarm Profile ..................82 Deleting a Line Profile and Alarm Profile ................... 84 Displying a Line Profile and Alarm Profile.................. 84 Port Configuration........................87 Enabling and Disabling a port ....................87 Displaying the Current Status and Information of SHDSL Line ..........

  • Page 6: List Of Figures

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Configuration Backup and Restore ................115 Configuration File “sf_user.cfg”....................115 Control Files used in TFTP Operation..................115 Configuration Backup.......................116 Configuration Restore ......................117 Dynamix DC-16S/SA upgrade ......................119 Troubleshooting......................120 Problems with Starting up Dynamix DC-16S/SA................
  • Page 7 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router List of Tables Table 1-2 Dynamix DC-16S/SA LED Description ...............14 Table 4-1 CLI Command - Action List ................61 Table 4-2 CLI Command – Identifier List...............61 Table 4-3 CLI Command –parameters list ..............62 Table 4-4 Relation between <action>...

  • Page 8: About This Guide

    VT-100s terminal emulation tools. Purpose This book describes how to install, manage, and configure Dynamix DC- 16S/SA/SA via CLI command Line interface through CID/RS-232 or Telnet/Ethernet interface. How This Guide is Organized This book provides task-based instructions for installing and using the CLI interface to configure and administrate the Dynamix DC-16S/SA System.

  • Page 9: Document Conventions

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Document Conventions Screen displays use these conventions: Login with administrator privilege Login with operator privilege > Login with guest privilege Commands descriptions use these conventions: Elements in square brackets are optional <...

  • Page 10: Introduction

    Fig 1-1 Dynamix DC-16S/SA/SA Physical Entity Display Dynamix DC-16S/SA provides 16 G.SHDSL ports. With 2.3 Mbps symmetric transmission characteristics over single loop, SHDSL is best suited to data-only applications that need high upstream bit-rates. Though SHDSL does not carry voice like SHDSL, new voice-over-DSL techniques may be used to convey digitized voice and data via SHDSL.

  • Page 11: Fig 1-2 Dynamix Dc-16S/Sa Front View

    5. Configuration batch file Fig 1-2 Dynamix DC-16S/SA Front View As Fig 1-2 displays, In the front view of Dynamix DC-16S/SA, there are several LEDs to indicate current system and link status and one 100 Mega Ethernet interface for uplink.

  • Page 12: Dynamix Dc-16S/Sa Application

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router SHDSL1-SHDLS16 R/Y/G Lit Red when no carrier is detected in the specified DSL link ; Lit Green when DSL link is in active state; Lit Yellow when the specified DSL link is in connection training state;...

  • Page 13: Dynamix Dc-16S/Sa Features

    The Dynamix DC-16S/SA supports mapping of Ethernet-VLAN to ATM-PVC feSTUre for security concern. Compact design for limited space Dynamix DC-16S/SA occupies 1.5 U of standard Telco rack space. Its compactness is perfect designed for co-location and basement installation. Best solution for SME’s broadband access Deployment in nearly any symmetric application requiring bandwidths from 192kbps to 2.3Mbps, G.SHDSL is poised for the best cost-effective solution for...

  • Page 14: Getting Started

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Getting Started This chapter provides the installation instruction for the hardware installation and system configuration of your Dynamix DC-16S/SA so that you can start up quickly. Unpacking your Dynamix DC-16S/SA This section describes how to unpack your Dynamix DC- 16S/SA.

  • Page 15: Installation

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Installation The Dynamix DC-16S/SA can be installed in a standard 19-inch rack, by using the mounting brackets provided. Mount the shelf on the rack using the large screws provided. Safety Instruction The following is the safety instructions for Dynamix DC-16S/SA before installation: 1.
  • Page 16 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Dynamix DC-16S/SA Rear Panel Connection The following figure shows the rear panel connection of Dynamix DC-16S/SA: Fig 2-2 Dynamix DC-16S/SA Rear Panel Connection Step 1 Ground the Dynamix DC-16S/SA by connecting a grounded wire Step 2 Connect the SHDSL line connector, a 50-pin centronic connector, of Dynamix DC-16S/SA to CPE by using the telco cable.

  • Page 17: Ways Of Connection

    Ways of Connection Embedded Web Interface(EmWeb) The embedded Web Interface (EmWeb), comprised of HTML files, is more user friendly than CLI for your configuring Dynamix DC-16S/SA. The HTML files embedded in Dynamix DC-16S/SA are dynamically linked to the system’s functional command sets.

  • Page 18: Embedded Web Interface Menu

    See page 30. Save to Flash Allow you to save your configuration in Flash. See page 31. Current Event Allow you to view the alarm and event status of your Dynamix DC-16S/SA. See page 32. User Manual...
  • Page 19 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router System Set Port Filter: Allow you configure the port filtering function. See page 33. System IP / Location: Allow you to configure the IP address and location of your Dynamix DC-16S/SA. See page 35.

  • Page 20: Default (Factory) Configuration Settings {Default Setting

    Default (Factory) Configuration Settings {Default Setting} This section describes how to get the information of the default setting of your Dynamix DC-16S/SA. 1. Click on “Default Setting” from the Dynamix DC-16S/SA Main Menu. The Default Setting screen appears as follows: User Manual...

  • Page 21: Displaying Your Dynamix Dc-16S/Sa's System Information {System Information

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Displaying your Dynamix DC-16S/SA’s System Information {System Information} This section describes how to get the information of your Dynamix DC-16S/SA. 1. Click on “System Information” from the Dynamix DC-16S/SA Main Menu. The System Information screen appears as follows:...

  • Page 22: Configuring Dynamix Dc-16S/Sa

    3. Click on DELETE ALL button in order to delete all events. Configuring Dynamix DC-16S/SA This section describes how to configure your Dynamix DC-16S/SA by selecting System from EmWeb Menu. This section will cover all the function from System Menu. It includes: Configuring Port Filtering {Set Port Filter} Allow you to configure the port filtering function.

  • Page 23: Configuring Ip And Location {System Ip / Location

    3. Press Apply button in order to submit your configuration. Note: Make sure to save all the configurations in flash by selecting Save to Flash from main menu when you want to restart your Dynamix DC-16S/SA. Configuring IP and Location {System IP / Location} Allow you to configure the system IP address and location.
  • Page 24 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router 2. Configure the IP address you want to set, say 192.168.100.123 3. Configure the subnet mask with reference to IP address, say 255.255.255.0 User Manual...

  • Page 25: Configuring Date And Time {System Date And Time

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router 4. Configure the gateway with reference to IP address, say 192.168.0.1 5. Configure the system name you want to set, say IP DSLAM 6. Configure the site of location you want to set.

  • Page 26: Changing Your Password {Changing Password

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Changing your Password {Changing Password} Allow you to change your password. 1. Click on “Changing Password” from the System Menu. The Changing Password screen appears with your user name and your password can be changed as follows: 2.

  • Page 27: Creating A Shdsl Alarm Profile {Create Alarm Profile

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router 2. Configure the name of line profile, say service 1552K. 3. Configure the line profile, for example, Configure the WireInterface, Minimum Line Rate, Maximum Line Rate, PSD, TransmissionMode, RemoteEnabled, PowerFeeding,...
  • Page 28 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router The Create Alarm Profile screen appears as follows: 2. Configure the name of alarm profile. 3. Configure the alarm profile. For example, Configure the ThreshLoopAttenuation, ThreshSNRMargin, ThreshES, ThreshSES, ThreshCRCanomalies, and ThreshLOSWS as 0s db, 0s db, 0, 0s ec, 0s ec, 4.

  • Page 29: Port Configuration

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Port Configuration This section covers how to configure a port and subscriber information by selecting Port Configuration from EmWeb Menu. This chapter will cover all the function from Port Configuration Menu.

  • Page 30: Pvc Configuration{Pvc Configuration

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router 4.Configure the administration status as “Up” or “Down”. Here in example , “Up” is configured. 5. Attach the line profile, says “DEFAULT” 6. Attach the alarm profile, says “DEFAULT” 7. Click on the Apply button to submit your changes, or click on the Cancel button if you want to clear all the values you have configured.
  • Page 31 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Modify Delete Modify Modify Delete Modify Modify Delete Modify Modify Delete Modify Modify Delete Modify Modify Delete Modify Modify Delete Modify Delete Modify Modify Delete Modify Modify Delete Modify 2. Click on the Port No you want to configure or view.

  • Page 32: List Of Subscriber {List Of Subscriber

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router will apears as follows: 6. Configure the VPI, says 8 7. Configure the VCI, says 81 8. Configure the administration status of PVC “Up” or “Down”, says “Up. 9. Configure the VID of the port.
  • Page 33 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router For the first time configuration, the List of Subscriber screen appears with the default setting as follows: 2. Click on the Port No you want to configure or view. 3. Click on the Apply button to submit your choice.

  • Page 34: Management Configuration

    Configuring Management IP {Management IP} Allow you to configure the management IPs so that only with those configured management IPs can access to your Dynamix DC-16S/SA remotely. The procedures are as follows: 1. Click on “Management IP” from the Management Menu.

  • Page 35: Shdsl Maintenance

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router The Management IP screen appears as follows: 2. Configure the management group as you want. The management IP group can be created maximum up to 5 groups. 3. Click on the Update button to submit your changes, or click on the Cancel button if you want to clear all the values you have configured.
  • Page 36 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router noLoopback default ready MODIFY noLoopback default ready MODIFY noLoopback default ready noLoopback default ready MODIFY noLoopback default ready noLoopback default ready MODIFY noLoopback default ready noLoopback default ready MODIFY noLoopback...

  • Page 37: Performance Monitor

    EmWeb Menu. It includes: Show SHDSL Span Status { Span Status } Allow you to view the configuration information of the SHDSL span on Dynamix DC-24S. 1. Click on “Span Status” of G.SHDSL from the DSL Port Performance Menu.

  • Page 38: Show Endpointcurr{ Endpointcurr

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router The Inventory screen appears as follows: Show Endpointcurr{ Endpointcurr } Allow you to view current status and performance information for segment endpoints in SHDSL line. 1. Click on “Endpointcurr” of G.SHDSL from the DSL Port Performance Menu.

  • Page 39: Shdsl Previous 15-Min Performance Management {Pre-15Min Pm

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router SHDSL Previous 15-MIN Performance Management {Pre-15min Allow you to view the SHDSL information of Previous 15-MIN Performance Management. 1. Click on “Pre-15min PM” of G.SHDSL from the DSL Port Performance Menu.

  • Page 40: Command Line Interface (Cli)

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router System Administration with CLI Command Line Interface (CLI) is the primary user interface to administrate the system. CLI can be accessed either from the CID port or telnet session. All CLI commands are simple strings designed for the administrator to manage your Dynamix DC-16S/SA easily.

  • Page 41: Table 4-2 Cli Command - Identifier List

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router means if the line profile is occupied by SHDSL span, the user can’t config it exactly. delete This is used to delete configuration of objects corresponding the identifier and parameters. If the user confirms the delete action, the configuration of objects will no longer exist.
  • Page 42 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router subscriber Allow users to view, add, delete or config the basic information of the subscriber of each port. event Allow users to view the events of system. trapdest Allow users to view, add or delete the trap destination.

  • Page 43: Table 4-3 Cli Command -Parameters List

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Table 4-3 CLI Command –parameters list action Parameter Description Allow users to view all information. port no. Allow users to view the information by selecting unit no (1 ~ 7)/ port no (1 ~ 24).
  • Page 44 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router UsedTargetMargins(1 = currCondDown,2 = worstCaseDown,3 = currCondUp,4 = worstCaseUp(Multi-selection))# ReferenceClock(1 = localClk,2 = networkClk)# LineProbeEnable(1 = disable,2 = enable)# add alarmprof <profile name> enter the selecting parameter of every item.
  • Page 45 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router config <profile name> enter the selecting parameter alarmprof of every item. The same with “add alarmprof” config None Modify current user’s password. password config span <port no.> <lineprof name> Modify SHDSL line <alarmprof name>...

  • Page 46: Table 4-4 Relation Between And

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router reset port <port no.> Reset Port restart None Restart system save None Save configuration to Flash Ram. default None Restore the default setting to system. upgrade <enable / disable> Enable / disable upgrade function.

  • Page 47: Calling Commands

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Calling Commands To recall commands from the history buffer, perform one of these tasks. Command Task The up arrow key Recall commands in the history buffer, beginning with the most recent command. Repeat the key sequence to recall successively older commands.

  • Page 48: Displaying Module Type

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Displaying Module type Viewing the module type of every unit Command: show moduletype Example: This example shows how to display the moduletype of every unit. Event Viewing and Deleting Displaying the Current Event Describes how to display events of system.

  • Page 49: Deleting The Event Of Dynamix Dc-16S/Sa

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Table 4-6 event Field Definition Field Definition Index of each event. Time The time when the event occurs. Source The location where the event occurs. Severity Priority of event (major/minor/inform).

  • Page 50: Resetting All Configurations To Default Setting

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Example: This example shows how to restart the system. Note: Before you restart the system, be sure that you save all the configurations by entering the command “save” or the system will start with the previous settings.

  • Page 51: Logging Out Your Dynamix Dc-16S/Sa

    Configuring Your Dynamix DC-16S/SA System Configuration Displaying Hardware and Software Information Describes how to view the identification information of Dynamix DC-16S/SA. Command: show sysinfo Example: This example shows how to display the hardware and software information of Dynamix DC-16S/SA. The following descriptions are default setting, of which system name, location, contact and console name can be modified.

  • Page 52: Table 4-7 Sysinfo Field Definition

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Table 4-7 sysinfo field definition Field Definition System name Alias name of Dynamix DC-16S/SA Location Location of system Contact Contact person for service and how to contact. Console name Console name of the system.

  • Page 53: Port-Filtering Configuration

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Example: This example shows how to modify the name of system as ZTE 123, console name as Dynamix DC-16S/SA and location of system as For North Area Service. Port-Filtering Configuration Displaying Port-Filtering Describes how to display the status of port-based VLAN.

  • Page 54: Ip Configuration

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Argument List: Parameter type Parameter data-type Description and field Status Enable/disable Enable or disable status Example: This example shows how to enable the portfilter and allow each DSL port to communicate with the uplink Ethernet port only.

  • Page 55: Time Configuration

    Time Configuration Displaying Time Describes how to display the current system time, system up time and period Command: show time Example: This example shows how to display the time of Dynamix DC-16S/SA. Table 4-10 time Field Definition Field Definition Current Time Current system time.

  • Page 56: Changing The Password

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Modifying Time Describes how to modify the date and time of system. Command: config time <date> <time> Argument List: Parameter type Parameter data-type and field Description date yyyy/mm/dd Example: 2001/07/13...

  • Page 57: Configuring Dsl

    Example: This example shows how the user changes his own password. Configuring DSL Creating Line Profile and Alarm Profile Creating Line Profile Describes how to add the content of SHDSL profile on Dynamix DC-16S/SA. Command: add lineprof <profile name> Argument List: Parameter type...
  • Page 58 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router CurrCondTargetMa -10…21 dB The downstream current rginDown condition target SNR margin for a SHDSL line. WorstCaseTargetM -10…21 dB The downstream worst case arginDown target SNR margin for a SHDSL line.
  • Page 59 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Creating Alarm Profile This section describes how to add the content of SHDSL alarm profile on Dynamix DC-16S/SA. Command: add alarmprof <profile name> Argument List: Parameter type Parameter data-type Description and field <alarmprof name>...

  • Page 60: Modifying Line Profile And Alarm Profile

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Example: Modifying Line Profile and Alarm Profile Modifying Line Profile modify the content of SHDSL profile on Dynamix DC-16S/SA Describes how to Command: config lineprof <profile name> Argument List: The same as Creating DSL Profile. See page 78...
  • Page 61 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Modifying Alarm Profile Describes how to modify the content of SHDSL alarm profile on Dynamix DC-16S/SA. Command: config alarmprof <profile name> Argument List: Parameter type Parameter data-type Description and field <alarmprof name>...

  • Page 62: Deleting A Line Profile And Alarm Profile

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router ThreshLOSWS 0s ~ 900s seconds The threshold for the number of Loss of Sync Word (LOSW) Seconds within any given 15-minute performance data collection interval. ThreshUAS 0s ~ 900s seconds...

  • Page 63: Displying A Line Profile And Alarm Profile

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Deleting Alarm Profile Describes how to delete the content of SHDSL alarm profile by selecting the profile name.. Command: delete alarmprof <profile name> Example:This example shows how to delete existing alarm profile money.

  • Page 64: Table 4-14 Alarmprof Shdsl Field Definition

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router SNR margin for a SHDSL line. (dB) WorstCaseTargetMarginDow The downstream worst case target SNR margin for a SHDSL line. (dB) UsedTargetMargins Whether a target SNR margin is enabled or disabled.

  • Page 65: Port Configuration

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router data collection interval. (seconds) ThreshSES The threshold for the number of severely error seconds (SES) within any given 15-minute performance data collection interval. (seconds) ThreshCRCanomalies Threshold for the number of CRC anomalies within any given 15-minute performance data collection interval.

  • Page 66: Displaying The Current Status And Information Of Shdsl Line

    Example: Those 2 example shows how to set the port 8 and all ports enable. Displaying the Current Status and Information of SHDSL Line Displaying the Current Status of Line Describes how to view the information of ports on Dynamix DC-16S/SA Command: show port <all | port no.> Argument List:...

  • Page 67: Pvc Configuration

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Example 1: Example 2: PVC Configuration Creating PVC Describes how to add the connection information and config Admin Status on Dynamix DC-16S/SA. Command: add connection < port no.> <vpi/vci> <up|down> [2~4094] [priority]...
  • Page 68 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Modifying PVC Describes how to modify the PVC connection (vpi/vci) by selecting a Dynamix DC-16S port no. Command: config connection <port no.> <vpi_old/vci_old> <vpi_new/vci_new> <AdminStatus> <VID> <Priority> Argument List: Parameter type...

  • Page 69: Table 4-17 Connection Field Definition

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Deleting PVC delete the connection on Dynamix DC-16S/SA. Describes how to Command: delete connection < port no.> <vpi/vci> Argument List: Parameter type Parameter data-type and Description field port no. 1 ~ 16 Indicated Dynamix DC- 16S port no.

  • Page 70: Table 4-18 Vid Field Definition

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Example: Sorted by VID Describes how to view the information of connections sorting by VID on Dynamix DC-16S. Command: show vid <all | port no.> Argument List: Parameter Description Show all information.

  • Page 71: Subscriber Configuration

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Admin Status Show the admin status of each connection (up/down). Operating Status Show the status of each connection (up/down). Port ID Show the Dynamix DC-16S/SA port no. Show vpi/vci. Priority Show the priority of this connection.

  • Page 72: Table 4-19 Subscriber Field Definition

    The description of subscriber of this port. Example: Modifying the Information of Subscriber Describes how to modify the information of subscriber by selecting Dynamix DC- 16S port no. Typing the command, it will enter the next degree (subscriber). After finished, it will be back the root degree.

  • Page 73: Management Configuration

    SNMP community. SNMP VID. (“-” means no-VID.) Example: This example shows how to display the information of SNMP. Modifying SNMP Describes how to configure the information about SNMP of Dynamix DC-16S/SA. Command: config snmp <community> [VID] Argument List: Parameter type...

  • Page 74: Configuring Trap Ip

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Argument List: Parameter type Parameter data-type and field Description <community> String, < 32 SNMP community. [VID] 2 ~ 4094 or ”-” for no VID. VID for SNMP. Example: Configuring Trap IP Creating Trap IP Describes how to create the destination of trap IP.

  • Page 75: Configuring Management Ip

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Displaying SNMP Trap Describes how to display the IP of destination that SNMP trap reached. Command: show trapdest Table 4-21 trapdest Field Definition Parameter type Parameter data-type and Description field A.B.C.D...

  • Page 76: Displaying Management Ip

    A.B.C.D IP address Submask A.B.C.D Submask Example: Displaying Management IP Describes how to view the IP groups that can manage Dynamix DC-16S/SA. Command: show manip Table 4-22 manip Field Definition Field Definition A.B.C.D (Max: 5 IP groups) Submask The submask of management group.

  • Page 77: Performance Monitor

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Example: Performance Monitor Displaying span Describes how to view the configuration information of the SHDSL span on Dynamix DC-16S/SA. Command; show span<all>< port no.> Argument List: Parameter Description <all> Show all information.

  • Page 78: Config Span

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Config span Command: config span < port no.> <lineprof name> <alarmprof name> Describes how to configure the configuration of SHDSL span by selecting Dynamix DC-16S/SA port. Argument List: Parameter type...

  • Page 79: Displaying Spanstatus

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Displaying spanstatus Describe how to view the overall spanstatus of a SHDSL span. Command: show spanstatus<all><port no.> Argument List: Parameter Description <all> Show all information. < port no.> 1 ~ 16. Indicate the Dynamix DC-16S/SA port no.

  • Page 80: Displaying Inventory

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Displaying inventory Describe how to view the inventory information of a SHDSL span. Command: show inventory<all><port no.> <c/r> Argument List: Parameter Description <all> Show all information. < port no.> 1 ~ 16. Indicate the Dynamix DC-16S/SA port no.

  • Page 81: Displaying Endpointcurr

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Example: Displaying endpointcurr Describe how to view current status and performance information for segment endpoints in SHDSL line. Command: show endpointcurr<all><port no.> <c/r> Argument List: Parameter Description <all> Show all information.
  • Page 82 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router been detected. dcContinuityFault Indicates vendor-dependent conditions that interfere with span powering such as short and open circuits. snrMarginAlarm Indicates that the SNR margin has dropped below the alarm threshold. loopAttenuationAlarm Indicates that the loop attenuation exceeds the alarm threshold.

  • Page 83: Displaying Pmintl

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Curr1DayTimeElap Curr1DayES Count of Errored Seconds (ES) in the current 1-day interval. (seconds) Curr1DayES Count of Errored Seconds (ES) in the current 1-day interval. (seconds) Curr1DaySES Count of Severely Errored Seconds (SES) in the current 1-day interval.

  • Page 84: Displaying Maint

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Table 4-33 pmintl Field Definition Field Definition Port ID Show the Dynamix DC-16S/SA port no. MoniSecs The amount of time in the 1-day interval which the performance monitoring information is actually counted.(There is no this item if selected “15min”.)

  • Page 85: Configuring Maint

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Argument List: Parameter Description <all> Show all information. < port no.> 1 ~ 16. Indicate the Dynamix DC-16S/SA port no. <c/r> (stuc/stur) , UnitID of SHDSL span. Table 4-34 maint Field Definition...

  • Page 86: Configuring User Account

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Describe how to configure the maintenance operations on Dynamix DC-16S/SA. Command: config maint <port no.> <c/r> Argument List: Parameter type Parameter data-type and Description field <port no.> 1 ~ 16 Indicated Dynamix DC-16S/SA port <c/r>...

  • Page 87: Modifying User Account

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Note: There are three privilege levels. administrator: own the strongest power of system. operator: could configure SHDSL setting and read system configuration, but can’t change system settings, such as user accounts, time…...

  • Page 88: Displaying The Information Of User Account

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Displaying the Information of User Account Describes how to view the information of existing user account. Command: show user Table 4-38 user Field Definition Field Definition User name User name (System login name).

  • Page 89: Configuration Backup And Restore

    Configuration File “sf_user.cfg” The configuration “sf_user.cfg” is for SHL ports, bridge and SNMP settings. As soon as you restore it in Dynamix DC-16S/SA, it can be applied the next time Dynamix DC-16S/SA is booted. Control Files used in TFTP Operation In TFTP operation, you may require some specific files to achieve authentication functions.

  • Page 90: Configuration Backup

    Configuration Backup This section describes how to back up your configuration settings form Dynamix DC-16S/SA to computer. The following procedures will help you to back up configuration: Step 1: Open a terminal emulation interface in order to execute CLI.

  • Page 91: Configuration Restore

    Yes or No <y/n>? System is restarting now.Wait….. Configuration Restore Describes how to restore your configuration settings from computer to Dynamix DC-16S. The following procedures will help you to restore configuration: Step 1: Open the hyber terminal interface in order to execute CLI.

  • Page 92: Dynamix Dc-16S/Sa Upgrade

    System is restarting now.Wait….. Dynamix DC-16S/SA upgrade This section describes how to upgrade the software of your Dynamix DC- 16S/SA. Step 1: Let your PC connect with the UPLINK port of Dynamix DC- 16S/SA by using an Ethernet cable. User Manual...
  • Page 93 TFTP. Step 5: Log in CLI by using a RS-232 cable and type the command” sysip” to access the IP address of Dynamix DC-16S/SA. (this step can be skipped if the IP address of Dynamix DC-16S/SA has been available).

  • Page 94: Problems With Configuration

    67) If the above corrective action doesn’t work, contact technical support. Problems with SNMP Describes how to solve the problem of getting information from Dynamix DC- 16S to SNMP manager server. Table 7-3 Troubleshooting the SNMP server Problems...

  • Page 95: Problems With Password

    The Dynamix DC-16S/SA will only accept one telnet DC-16S session at a time. Ping the Dynamix DC-16S/SA from your computer. If you are able to ping the Dynamix DC-16S/SA but are still unable to telnet, contact the distributor. If you cannot ping the Dynamix DC-16S/SA, check the IP address in the Dynamix DC-16S/SA and your computer.

  • Page 96: Table A-2 Null Modem Cable Pin Assignment (For Pc To Cid Port Connection)

    Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router ------- ------- Note: Connector type is DB9 male Table A-2 Null modem cable pin assignment (for PC to CID port connection) DB9 female DB9 female Table A-3 Dynamix DC-16S/SA uplink port pin assignment Pin no.
  • Page 97 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Glossary STU-C SHDSL Transmission Unit—central office. STU-R SHDSL Transmission Unit—remote. BRAS Broadband Remote Access Server. Device that terminates remote users at the corporate network or Internet users at the Internet Service Provider (ISP) network, such as the NetSpeed FireRunner product that provides firewall, authentication, and routing services for remote users.
  • Page 98 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router ESS is a generic term with various meanings depending on the signal standards domain in which it’s being used. Ethernet One of the most popular base band LANs in widespread use. It is a carrier service multiple access collision detect (CSMA/CD) system using coaxial cable and developed by Xerox, Intel, and Digital Equipment Corporation.
  • Page 99 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Lprs (Loss of Power failures) Lprs is a generic term with various meanings depending on the signal standards domain in which it’s being used. MDF (Main Distribution Frame) Hardware component in the CO, which provides an interface between outside lines (subscriber lines and trunks) and the switching equipment.
  • Page 100 Dynamix DC – 16 S/SA 16 ports SHDSL DSLAM modem/router Unit of information from an upper-layer protocol that defines a service request to a lower-layer protocol. Signal Noise Ratio (SNR) This is a DSL transmission parameter, measured in dB, which indicates the Signal-to- Noise (S/N) ratio at a receiver point.
