Summary of Contents for Blaupunkt ProComponent PCw 1000
-
Page 2: Table Of Contents
Blaupunkt technical support ........ - Page 3 OU FOR CHOOSING LAUPUNKT Congratulations! You are the now the owner of an exceptional loudspeaker from the audio enthusiasts at Blaupunkt. Our engineering staff has spent considerable time refining our subwoofers in order to introduce great sound to the consumer at an affordable price.
- Page 4 AFETY ONCERNS We always recommend you have your Blaupunkt speakers professionally installed but the installation process is often so easy that the average consumer can achieve success with little trouble. Regardless of the person installing, you should be sure to review the following points before proceeding with the installation: READ THE MANUAL! Understanding the product and installation limitations before lifting a screwdriver.
-
Page 5: Installation Tools & Guidelines
NSTALLATION UIDELINES We strongly recommend that you have your Blaupunkt speakers professionally installed. If you choose to do your own installation please note the following important information: Before cutting any trim or metal make sure your final installation will clear all moving parts, factory cables, wires, and hoses. -
Page 6: System Design Guidelines
YSTEM ESIGN UIDELINES SYSTEM PLANNING The largest possible impact on any audio system (home or car) is the tonal quality of the loudspeakers, their respective placement, and their overall efficiency (loudness). A 4x20 watt amplifier and four dual-cone speakers is never going to make an impressive performance. -
Page 7: Subwoofer Enclosure Types
You need to make the choice based upon personal listening habits and requirements. Having “Multi-Box” design characteristics, your Blaupunkt subwoofer performs remarkably well in ALL installations, but is optimized for Sealed, Vented, and Single-Vented Band-Pass configurations due to its moderate Qts values. Below is a summary of these 5 popular enclosures. -
Page 8: Active & Passive Electrical Configurations
CTIVE AND PASSIVE ELECTRICAL CONFIGURATIONS At some point, the subwoofer speaker must be electrically connected to an audio amplifier, be it a dedicated bass-only amp or the amplifier built inside the radio. Clearly, the highest performance level will be from the outboard dedicated amp due to its typically higher power (e.g., 100 watt amp vs. -
Page 9: Basic Mathematics For Enclosure Construction
ASIC ATHEMATICS FOR NCLOSURE ONSTRUCTION AREA AND VOLUME CALCULATIONS Although many enclosures can now be purchased in prefabricated form, building your own enclosure is often fun, acoustically rewarding, or even a necessity to properly fit many vehicles. In order to build such a box there MUST be a basic understanding of mathematic principals or you will wind up wasting incredible amounts of time and money by making mistakes in the box design and assembly. - Page 10 LAUPUNKT AMPLE NCLOSURE IZES This page is offered ONLY as a “starting point” for box construction. Although our woofers work well in a wide range of box volumes, many people try to build boxes too large assuming they will get better bass response with such monstrous sized boxes.
-
Page 11: Final Subwoofer Enclosure Construction
A tremendous reference book useful for all.) ISBN: 1-882580-33-8 BLAUBOX WOOFER BOX DESIGN COMPUTER PROGRAM, Thomas Breithaupt, Blaupunkt div. Robert Bosch Corporation, 2800 S. 25th Avenue, Broadview, IL 60155. (This is a simple to use IBM PC computer program used to predict the frequency response of a subwoofer in 10 different enclosures including sealed, vented, and bandpass configurations. -
Page 12: Technical Specifications
- PC 1000, 10” S LAUPUNKT ECHNICAL PECIFICATIONS UBWOOFER PARAMETER VALUE POWER HANDLING 200 Watts rms 600 Watts peak SENSITIVITY 91 dB (2.83V/1m) 88 dB (1W/1m) FREQ. RESPONSE 20 - 200Hz 10.10 in. (256.5 mm) NOMINAL IMPEDANCE 4 ohms MAGNET WEIGHT 40 oz. - Page 13 - PC 1000, 10” S LAUPUNKT ECOMMENDED ESIGNS UBWOOFER SEALED BOX (Volume Total) (freq. @ -3dB) cu.ft. (L) (dB ref 1W) 0.4 (11.3L) 0.6 (17.0L) 0.8 (22.7L) 1.0 (28.3L) 1.4 (39.6L) VENTED BOX (Volume Total) (Port tuning Port Length Port Length (freq.
- Page 14 - PC 1200, 12” S LAUPUNKT ECHNICAL PECIFICATIONS UBWOOFER PARAMETER VALUE POWER HANDLING 200 Watts rms 600 Watts peak SENSITIVITY 92 dB (2.83V/1m) 89 dB (1W/1m) FREQ. RESPONSE 20 - 200Hz NOMINAL IMPEDANCE 4 ohms 12.03 in. (305.5 mm) MAGNET WEIGHT 40 oz.
- Page 15 - PC 1200, 12” S LAUPUNKT ECOMMENDED ESIGNS UBWOOFER SEALED BOX (Volume Total) (freq. @ -3dB) cu.ft. (L) (dB ref 1W) 0.5 (14.1L) 0.75 (21.2L) 1.0 (28.3L) 1.5 (42.5L) 2.0 (56.6L) VENTED BOX (Volume Total) (Port tuning Port Length Port Length (freq.
-
Page 16: Blaupunkt Technical Support
We shall not be liable for any incidental, consequential, special or punitive damages arising from the sale or use of any Blaupunkt car audio products, whether such claim is in contract or tort. - Page 17 Notre garantie s ’étend à tous les produits achetés à l ’intérieur de l ’Union Européenne.Vous en trouverez les conditions sur notre site Internet : www.blaupunkt.de. Vous pourrez aussi les obtenir en vous adressant à: Blaupunkt GmbH, Hotline CM/PSS 6, Robert Bosch Str. 200, D-31139 Hildesheim Per i prodotti acquistati nell’ambito dell’Unione Europea concediamo una garanzia di produttore.
- Page 18 URCHASE NFORMATION Purchase Date: Retailer: Address: City: State: Zip: Telephone: Installer: Vehicle: THER OTES – 82...
- Page 19 OTES – 83 –...
- Page 20 Copyright 2003 by the Robert Bosch Corporation No portion of this work may be reproduced in any form without the written consent of the Robert Bosch Corporation BLAUPUNKT is a registered trademark owned by Blaupunkt GmbH. Printed in China (MARCH 2003)
