Summary of Contents for Williams Sound PFM PRO
- Page 1 PFM PRO and PFM PRO RCH Personal Wireless FM Listening Systems USER Manual PFM PRO PFM PRO RCH MAN 199A...
-
Page 2: Table Of Contents
Please take the batteries to a retail or community collection point for recycling. Product Recycling: Please do NOT dispose of your Williams Sound equipment in the household trash. Please take the equipment to an electronics recycling center or return the product to the factory for proper disposal. -
Page 3: System Overview
Personal FM Wireless Listening Systems System Overview Thank you for purchasing a Personal FM Wireless Listening System from Williams Sound. Anyone needing auditory assistance to overcome background noise, reverberation, or distance from a sound source can benefit from a Personal FM Wireless Listening System. -
Page 4: Setting Up The Ppa T46 Transmitter
Personal FM Wireless Listening Systems Setting up the PPa t46 transmitter IMPORTANT: If Alkaline (non rechargeable) batteries are being installed, slide the battery selection switch in the battery compartment to the “Alkaline” position. See FIG 1 below. If installing NiMH (or rechargeable) batteries, slide the battery selection switch to the “NiMH”... -
Page 5: Setting Up The Ppa R37 Receiver
Personal FM Wireless Listening Systems 7. Attach the lapel clip microphone on a collar or lapel, as close to the speaker’s mouth as possible. If using an optional headset microphone, position the mic as close to the side of the mouth as possible without touching the mouth (See Figure 5). figure 5: lapel Microphone Placement A301 8. -
Page 6: Using The Chg 3502 Charger
Using the CHg 3502 Charger WARNING: Use this charger with Williams Sound NiMH rechargeable batteries only. DO NOT use non-rechargeable batteries, such as alkaline and carbon zinc, which may heat up and burst, causing possible injury and damage to the equipment. -
Page 7: Troubleshooting
Personal FM Wireless Listening Systems troubleshooting Sound Issues Static audio in the receiver • Make sure the Transmitter and Receiver are set to the same channel. • Make sure you are using fresh or fully recharged batteries. • Microphone cord and earphone cord serve as transmitting and receiving antennas. Try to keep the antennas in a vertical orientation. -
Page 8: Specifications Fm Transmitter Ppa T46
Personal FM Wireless Listening Systems Specifications FM Transmitter PPA T46 Dimensions: 4.1” L x 2.8” W x 1.1” D (104 mm x 71 mm x 28 mm) Weight: 2.6 oz (74 g), no batteries Color: Black/Silver Enclosure Material: Shatter-resistant PC/ABS plastic with textured scratch-resistant aluminum faceplate Battery Type options: Two (2) AA 1.5 V non-rechargeable Alkaline batteries (BAT 001-2), 75 mA nominal current drain, up to 30 hours battery life Two (2) AA 1.5 V NiMH rechargeable batteries (BAT 026-2), 75 mA nominal current drain, up to 20... -
Page 9: Specifications Fm Receiver Ppa R37
Personal FM Wireless Listening Systems Specifications FM Receiver PPA R37 Dimensions: 4.1” x 2.85” x 1.38” (104 x 72 x 35mm) Weight: 4.6oz (130g) with batteries. 2.6oz (73g) without batteries Color: Black Battery Type: (2) AA Alkaline or 2 x AA NiMH Battery Life: Two (2) AA non-rechargeable alkaline batteries (BAT 001), approx. -
Page 10: Lifetime Plus Limited Warranty
Effective January 1, 2014, Williams Sound warrants the FM Listening transmitter and receiver models PPA T46 and PPA R37 against defects in materials and workmanship under normal use and conditions for the useful lifetime of the product from date of purchase. -
Page 11: Notes
Personal FM Wireless Listening Systems notes... - Page 12 10300 Valley View Rd • Eden Prairie, MN 55344 800-328-6190 / 952-943-2252 • FAX: 952-943-2174 www.williamssound.com ©2015 Williams Sound • All Rights Reserved MAN 199A...
