AEM SM42 AA36-ECF Installation And Operation Manual

Optical beam smoke detector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SPECIAL NOTICE
This product is now licensed to Anodyne Electronics Manufacturing (AEM) from Northern
Airborne Technology (NAT). AEM is responsible for all matters related to this product, including
sales, support and repair services.
Please note the transition to convert product manuals and supporting documentation is an
ongoing process and is being addressed on an 'as needed' basis.
All references to NAT product part numbers (and associated images) are equivalent to AEM
product part numbers.
Contact info:
Anodyne Electronics Manufacturing Corp.
#15-1925 Kirschner Road
Kelowna B.C. Canada
V1Y 4N7
Email:
support@aem-corp.com
Toll Free: 1-888-763-1088
Phone: 1-250-763-1088
Fax: 1-250-763-1089
www.aem-corp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM42 AA36-ECF and is the answer not in the manual?

Questions and answers

Related Manuals for AEM SM42 AA36-ECF

Summary of Contents for AEM SM42 AA36-ECF

  • Page 1 SPECIAL NOTICE This product is now licensed to Anodyne Electronics Manufacturing (AEM) from Northern Airborne Technology (NAT). AEM is responsible for all matters related to this product, including sales, support and repair services. Please note the transition to convert product manuals and supporting documentation is an ongoing process and is being addressed on an ‘as needed’...
  • Page 2 REV 5.00 April 15, 2012 Anodyne Electronics Manufacturing Corp. 15-1925 Kirschner Road Kelowna, BC, Canada. V1Y 4N7 Telephone (250) 763-1088 Facsimile (250) 763-1089 Website: www.aem-corp.com © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
  • Page 3 © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved This publication is the property of AEM and is protected by Canadian copyright laws. No part of this document may be reproduced or transmitted in any form or by any means including electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AEM.
  • Page 4 The status of this installation and operation manual is controlled by issue shown on the title page. The status of each section is controlled by revision shown in the footer of each page. All revisions affecting sections of this manual have been incorporated into the latest issue. AEM MANUAL REVISIONS Section Revision Number...

  • Page 5: Table Of Contents

    AA36-ECF Tie Line Adapter SM42 Installation and Operation Manual Table of Contents Section Title Page Description Introduction Purpose of Equipment Features Specifications 1.4.1 Electrical Specifications 1.4.2 Physical Specifications 1.4.3 Environmental Specifications Installation Introduction Unpacking and Inspection 2.2.1 Warranty Installation Procedures 2.3.1 Warnings 2.3.2...

  • Page 6: Description

    Introduction This manual contains information on the AA36-ECF Tie Line Adapter. All derivatives will be covered by manual supplements, which can be obtained from AEM as required. Information in this section consists of purpose of equipment, features and specifications. Purpose of Equipment The AA36-ECF interfaces a NAT ICS tie line to non-bidirectional tie line intercom systems.

  • Page 7: Physical Specifications

    Noise Level >60 dB down from rated output (without signal) Isolation from ICS Input >35 dB Adjust Trimpot 40 dB of range Bi-directional Signals AEM ICS Tie Line: Signal Level 340 mVrms Input impedance 1800 Output Impedance Freq. response <3 dB from 350 Hz to 6000 Hz Distortion <10 % @ rated output.

  • Page 8: Installation

    Verify that all items are present before proceeding and report any shortage immediately to your supplier. 2.2.1 Warranty All Anodyne Electronics Manufacturing Corp. (AEM) products are warranted for 2 years. See the website www.aem-corp.com/warranty for complete details. Installation Procedures 2.3.1 Warnings Do not bundle any lines from this unit with transmitter coax lines.

  • Page 9: Cabling And Wiring

    2.3.5 Setting ICS OUT The signal level measured on the ICS tie line from the AEM audio controller/intercom system is typically 340 mVrms, which is fed into the NAT ICS TIE on the AA36-ECF. The OUTPUT ADJ trimpot on the AA36-ECF is factory set to provide 500 mVrms 10% signal at ICS OUT, measured across a 5 kOhm load, but can be adjusted to give the desired output.

  • Page 10: Pax Mute Function

    Maintenance of the AA36-ECF is ‘on condition’ only. Periodic maintenance of this product is not required. Accessories Required But Not Supplied Installation kit p/n AA36-IKC (crimp) is required to complete the installation. Each kit consists of the following: AA36-IKC 25-pin D-min Female Crimp Kit (AEM Part No. D25SL-IKC) Quantity Description AEM Part #...

  • Page 11: Installation Drawings

    AA36-ECF Tie Line Adapter SM42 Installation and Operation Manual Installation Drawings DRAWING REV. DESCRIPTION TYPE AA36\ECF\403-0 1.00 ICS TIE Line Adapter Interconnect AA36\ECF\405-0 1.00 ICS TIE Line Adapter Connector Map AA36\ECF\922-0 1.00 ICS TIE Line Adapter Mechanical installation Section 2.0 ends following the above documents April 15, 2012 Rev: 5.00 Page 2-4 ENG-FORM: 805-0100.DOTX...

  • Page 15: Operation

    AA36-ECF Tie Line Adapter SM42 Installation and Operation Manual Section 3.0 Operation Introduction Information in this section consists of the functional and operational procedures for the AA36-ECF Tie Line Adapter. General The AA36-ECF interfaces a NAT ICS tie line to non-bidirectional tie line intercom systems. Configuration The AA36-ECF Tie Line Adapter has no normal user operational aspects.
