Summary of Contents for Gilras GCP-7000
- Page 1 User’s Manual Chart Projector GCP-7000...
-
Page 2: Important Notice
GILRAS reserves the right to make changes in its products or product specifications at any time and without prior notice, and is not required to update this documentation to reflect such changes. -
Page 3: Table Of Contents
Chart Projector GCP-7000 -------------------------------------------------------------------------- CONTENTS Introduction ......................4 1.1. Outline of product ....................4 1.2. Classifications ....................4 Safety Information ....................5 2.1. Introduction ......................5 2.2. Safety Symbols ....................6 2.3. Environmental factors ..................7 2.4. Safety Precautions .....................8 Features…......................10 Notes for Using the Instrument ................11 Configurations ....................... - Page 4 ------------------------------------------------------------------------ Chart Projector GCP-7000 Types of Chart (Type C is Standard) ..............19 Maintenance and Repair..................20 9.1. Lamp Replacement ..................20 9.2. Fuse Replacement ..................22 10. Specifications ......................23 11. Service Information ....................24...
-
Page 5: Introduction
1.1. Outline of product GILRAS GCP-7000 is an automatic chart projector which provides 41 different charts including red/green and polarized filters for the eye optometry. Users can select the desired charts instantaneously by cordless remote controller. Charts move quickly and quietly. -
Page 6: Safety Information
------------------------------------------------------------------------ Chart Projector GCP-7000 2. Safety Information 2.1. Introduction Safety is everyone’s responsibility. The safe use of this equipment is largely dependent upon the installer, user, operator, and maintainer. It is imperative that personnel study and become familiar with this entire manual before attempting to install, use, clean, service or adjust this equipment and any associated accessories. -
Page 7: Safety Symbols
Chart Projector GCP-7000 -------------------------------------------------------------------------- 2.2. Safety Symbols The International Electrotechnical Commission (IEC) has established a set of symbols for medical electronic equipment, which classify a connection or warn of any potential hazards. The classifications and symbols are shown below. Save these instructions I and O on the power switch represent ON and OFF respectively. -
Page 8: Environmental Factors
------------------------------------------------------------------------ Chart Projector GCP-7000 2.3. Environmental factors Avoid the following environments for operation or storage: Where the equipment is exposed to water vapor. Don’t operate an equipment with a wet hand. Where the equipment is exposed to direct sunlight. Where the temperature changes extremely. -
Page 9: Safety Precautions
The equipment must be operated only by, or under direct supervision of a properly trained and qualified person. Customer maintenance of this equipment may only be performed as stated in the User’s Manual. Any additional maintenance may only be performed by GILRAS service technicians or other authorized persons. - Page 10 ------------------------------------------------------------------------ Chart Projector GCP-7000 The manufacturer is only responsible for effects on safety, reliability, and performance of this equipment when the following requirements are fulfilled: (1) The electrical installation in the respective room corresponds to the specifications stated in this manual and (2) This equipment is used, operated, and maintained according to this manual.
-
Page 11: Features
Aniseikonia tests. 34 Masks (vertical line, horizontal line, and single character) 2.5 ~ 8 m (8 ~ 26 feet) projection range Cordless Remote Control User Programmable (2 programs up to 30 charts each) Easily networked with GILRAS’s Digital Refractor... -
Page 12: Notes For Using The Instrument
Don’t use organic solution such as alcohol, thinner, benzene, etc. to clean the surface of this instrument. It may damage the instrument. When moving the GCP-7000, always make sure the power supply is off, and then lift the bottom of the unit with both hands. -
Page 13: Configurations
Chart Projector GCP-7000 ------------------------------------------------------------------------- Configurations 5.1. Main Body The GCP-7000 Chart Projector is mainly composed of the body, stand, screen and remote control. [Fig. 1 Front View with Remote Control] 1. IR receiving window 2. Projection lens 3. Stand (table mount) -
Page 14: Main Body Cont
------------------------------------------------------------------------ Chart Projector GCP-7000 5.2. Main Body cont. [Fig. 3 Rear View] 5. Tilting Adjustment 6. Fuse Holder & 110/220 Voltage selector 7. AC Power Inlet 8. Power On/Off Switch 9. CAN (Controller Area Network) -
Page 15: Accessories
Chart Projector GCP-7000 ------------------------------------------------------------------------- 5.3. Accessories [Fig.4 Accessories] 1. Screen 2. T wrench(5mm) 3. lamp 4. fuse 5. Batteries (2 size AA) 6. Power cable 7. Dust Cover 8. Screen Screw... -
Page 16: Installation
------------------------------------------------------------------------ Chart Projector GCP-7000 6. Installation 6.1. Position of Chart Projector The single tube projector must be installed at the same distance from the screen as the patient. [Fig. 6 Installation without mirrors] Install chart projector at desired position within 2.5~8m (8~26 feet). -
Page 17: How To Obtain Correct Letter Size And Focus (Zooming Type Only)
Chart Projector GCP-7000 ------------------------------------------------------------------------- 6.2. How to obtain correct Letter Size and focus (Zooming Type only) Install chart projector at desired position of 2.5~8m (8~26 feet) Measure the distance from patient to screen Refer to the test scale shown in the Appendix A Have someone hold the test scale at the screen Project the 20/400(6/120, 0.05) alphabet “C”... -
Page 18: Input And Use Of Program
------------------------------------------------------------------------ Chart Projector GCP-7000 7. Input and Use of Program 7.1. How to input user's program Step 1. Press the “LIGHT” button once. Results: The light goes out. Step 2. Press the “PGM 1” button three times. Results: The light will come on and the chart projector will display the first chart of the default program. -
Page 19: How To Use Your Stored Programs
Chart Projector GCP-7000 ------------------------------------------------------------------------- 7.2. How to use your stored programs. Step 1. Press “ PGM 1 ” or “PGM 2” to select the program of your choice. Step 2. Use the “Program ►” or “Program ◄” to scroll through your stored... -
Page 20: Types Of Chart (Type C Is Standard)
------------------------------------------------------------------------ Chart Projector GCP-7000 8. Types of Chart (Type C is Standard) [Fig. 7 Types of Chart]... -
Page 21: Maintenance And Repair
Chart Projector GCP-7000 ------------------------------------------------------------------------- Maintenance and Repair 9.1. Lamp Replacement Turn off power and disconnect the power cord. Allow the projector to cool down for about 5 minutes before replacing the lamp. Using the cross screwdriver remove the five screws from the bottom of the cover. - Page 22 ------------------------------------------------------------------------ Chart Projector GCP-7000 Screw-A [Fig. 8 Lamp assembly]...
-
Page 23: Fuse Replacement
Chart Projector GCP-7000 ------------------------------------------------------------------------- 9.2. Fuse Replacement Turn off power, and disconnect the power cord. Pull out the plastic cover at the lower part of power socket, to replace the fuse. WARNING Do not touch the projector with wet hands. (Risk of electric shock) -
Page 24: Specifications
------------------------------------------------------------------------ Chart Projector GCP-7000 10. Specifications 41charts -34 mask, Red/green& Polarization Charts Filters Distance of projection 2.5~8m(Optional: 8m screen) Chart Rotation Speed Average 0.15 sec Chart magnification 30X (When 5m distance) Power saving Automatic Lamp Off (10 min) Program 2 programs with a maximum of 30 charts each... -
Page 25: Service Information
11. Service Information Repair: If the problem is not solved in spite of the settlement according to the contents of chapter 9, please contact to GILRAS’s agent with the information on the following items. Name of Equipment Type : GCP-7000 Typical No.
