USER MANUAL
FP1010 Standalone AD Display
Before connecting, operating or adjusting this product, please read these instructions
completely. Please keep this manual of future reference.
Product and brand names mentioned in this manual are trademarks of registered
trademarks of their respective holders.
Specification is subject to change without notice.
Version 08.1
Advertisement
Table of Contents
Summary of Contents for Samar FP1010
- Page 1 USER MANUAL FP1010 Standalone AD Display Version 08.1 Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual of future reference. Product and brand names mentioned in this manual are trademarks of registered trademarks of their respective holders. Specification is subject to change without notice. ...
- Page 2 ...
- Page 3 Important Information Please do not open or remove the cover plate because it may generate a high voltage shocking or other dangers. Please do not precede the maintenance or repairing of this unit by yourself. Carefully read the instruction manual before use, and keep the manual for future reference. Please read and comply with all warnings, cautions, and the manual thoroughly. You might lose your warranty if you modify or revise this item in such as manner not approved by this manual. AC cords enclosed in this product are for 110V or 220V. If any liquid or solid objects fall inside the cabinet, unplug the set immediately and have it checked by qualified service personnel before operating it again. Never add any attachments and/or equipments without approval of the manufacturer. Such additions can increase the risk of fire, electric shock, or other personal injury. Important Warnings and Safety Precautions Read instructions‐ all the safety and operating instructions should be read before the product is operated. Keep the safety and operating instructions for future reference. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short‐out parts that could result in fire or electric shock. Never spill liquid of any kind on the product. Do not remove/insert the plug into the socket with wet hands in order to prevent electric shock. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. Do not attempt to service this product by yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all services to qualified service personnel. The ...
- Page 5 Co tents 1. INTRODUCTION .................... 1 Product Description .................... 1 Product Features .................... 1 Package Contents .................... 2 Assembly and Connection .................. 2 Remote Control function .................. 4 3. ON SCREEN DISPLAY OPERATING INSTRUCTIONS .......... 5 Device Selection (Home Page) ................ 5 Function Selection .................... 6 Setup Screen ...................... ...
-
Page 6: Product Description
1. INTRODUCTION Product Description Thank you for choosing the Solid State Standalone AD Display and for your continued support and use of our products. This Standalone AD Display allows you to play back high quality still image for JPEG files as well as video files through 24/7 looping as required. Product Features The high efficiency decoder supports HD JPEG file decoding. High quality 2W speaker built‐in for superior audio effect. Support audio file format: AAC, MP3, WMA Support photo file format: BMP, JPEG Support video file format: MPEG‐1, MPEG‐2, MPEG‐4, H.264 BP, Flash Video (.flv). Firmware can be upgraded by using flash memory card. Power‐on play: automatically play. ‐1‐ ... -
Page 7: Package Contents
Package Contents Please check the package to make sure is contains the following items FP1010‐T AC Adapter User Manual Remote Controller Assembly and Connection Top View RS‐232 is reserved for special custom feature. ‐2‐ ... - Page 8 Front View Back View Option: Motion sensor. ‐3‐ ...
-
Page 9: Remote Control Function
2. Remote Control function No Key name Description Monitor Remote Control Unit 1 Mute LEFT / RIGHT For navigation key / 2 MENU/ EXIT Confirm / Exit function 3 Output No function ◄/▲/►/▼/ For navigation key / 4 Confirm function 5 Previous file 6 No function 7 Setup Into setup screen Adjust volume up / 8 VOL + / ‐ down 9 Motion No function 10 Next file ... -
Page 10: Device Selection (Home Page)
3. ON SCREEN DISPLAY OPERATING INSTRUCTIONS Device Selection (Home Page) Turn on device power without memory card loaded. "Device Selection" will be seen on screen. Click arrow key◄/▲/►/▼of remote control to select "Flash" icon and use enter key to enter / confirm the selection into "Function Select" screen. You may also use keypad operation other than object control on touch screen. menu represent "enter" or "select" volume up / down represent arrow keys exit represent "back" or "exit" Default different functions under different mode. ‐5‐ ... -
Page 11: Function Selection
Function Selection Select and enter "Setup" icon to get into setup mode. To get into setup mode screen while memory card is loaded; turn off the power, press and hold the menu key on keypad then reboot. Setup Screen Please turn off the power after setup completed. Load the memory card and reboot to play back. ‐6‐ ... - Page 12 System Setup – Brightness & Contrast Level 1 Level 2 Function System Setup Brightness & Contrast Brightness: 30%‐90% Slideshow Setup Time Setup Contrast: 30%‐70% Volume Setup Version Adjust brightness and Touch Calibrate contrast value. Please use arrow key ◄/▲/►/▼as movement, Select icon, then use enter key as confirmation for adjustment. ...
-
Page 13: Volume Setup
Slideshow Setup – Interval Setup Level 1 Level 2 Function System Setup Interval Setup Slideshow Setup Effect Setup Fast/Medium/Slow/Very Slow Volume Setup To adjust the interval timing Touch Calibrate for slideshow. Slideshow Setup – Effect Setup Level 1 Level 2 Function ... -
Page 14: Touch Calibrate
Touch Calibrate Level 1 Level 2 Function System Setup Slideshow Setup Volume Setup The function is not available. Touch Calibrate ‐9‐ ... - Page 15 MEMO ...
