Summary of Contents for Wellington WBC142
-
Page 1: Wine Cooler
Wine Cooler INSTRUCTION MANUAL Model: WBC142... -
Page 2: Table Of Contents
Content Hint for Castoff Disposal…………………………………………3 Hints on Safety & Warning………………………………………4 Know About Wine Cooler…………………………………..……6 Placement of Wine Cooler ………………………………………6 Level the Wine Cooler……………………………………….……7 Pay Attention to Room Temperature & Ventilation…………7 Ventilation……………………………………………………….… 7 Connect Wine Cooler with Power Source……………….……8 Set UP Temperature………………………………………………8 Placement of Beverage Bottle…………………………….……... -
Page 3: Hint For Castoff Disposal
Hint for Castoff Disposal Disposal of Waste Package The package is used to protect the wine cooler during the transportation. All the materials are harmless to environment and reusable. To know the current channel for disposal of castoff, please consult your professional dealers or the local administrative authority. -
Page 4: Hints On Safety & Warning
Hints on Safety & Warning Before Operation of Wine Cooler Please read the User Manual carefully! It contains some important information on placement, use and maintenance of wine cooler. Please keep all the data for future use or the next user of the wine cooler. Technical Safety The wine cooler contains a little cooling agent - R134a, which is harmless to the environment. - Page 5 defrost! Steam may enter the electric elements and cause short circuit. Danger of Electric Shock! Don’t remove frost or ice layers with sharp or keen-edged object. Otherwise, the cooling agent pipeline may be damaged. The ejected cooling agent may cause injury to eyes. Do not store products that contains combustible gas (such as: spray bottle) or explosive materials in the wine cooler.
-
Page 6: Know About Wine Cooler
GB-T 23777-2009 Wine Cooler International or other national or regional standards: UL 250 BULLETINS-2003 U.S.A. household fridge safety requirements IEC 61000-3-4-1998 Electromagnetic compatibility (EMC) - Limits - Limitation of emission of harmonic currents in low-voltage power supply systems for equipment with rated current greater than 16 A UL 250 BULLETINS2-2003 U.S.A. -
Page 7: Placement Of Wine Cooler
Placement of Wine Cooler The wine cooler should be placed in dry and ventilated room. The location of the wine cooler should not be irradiated by direct sunshine. The wine cooler should be far away from heating sources, such as: cooking stove or heating radiator. -
Page 8: Level The Wine Cooler
Handle Fixation Pin Screw Driver Level the Wine Cooler Place the wine cooler on the planned location and level it. The front screw leg is adjustable. -
Page 9: Pay Attention To Room Temperature & Ventilation
Pay Attention to Room Temperature & Ventilation The climate type is marked on the model nameplate. It indicates the room temperature range for operation of wine cooler. Climate Type Indoor Temperature Range +61°F to 90°F (+16°C to 32°C) +64°F to 100°F (+18°C to 38°C) +64°F to 109°F (+18°C to 43°C) Notice If the room temperature is lower than +61°F (+16°C), the wine cooler may not... -
Page 10: Set Up Temperature
The power socket should be in such as place, where is reachable conveniently. Please use a socket that’s installed according to the requirements. The wine cooler should be connected with 115V/60Hz AC power. Warning! In any case, please do not connect the wine cooler to the electronic energy saving power plug or the converter (such as: solar energy equipment, ship’s electric grid) that convert DC into 115V AC. -
Page 11: Placement Of Beverage Bottle
do not disassemble it for check by yourself. You should contact local after-sales service personnel for repair. If the temperature in the cooler is too low, it will display “L”. When the temperature in the cooler is too high, the screen will display “H” and will flash;... -
Page 12: Use Temperature Area In Chilling Cabinet
Effective Cubage Please see the model nameplate on the wine cooler for the description on effective cubage. Use Temperature Area in Chilling Cabinet Due to the air circulation in the wine cooler, some areas with different temperatures are generated: The upper area has the highest temperature The lower area has the lowest temperature Placement of Beverage Please store different wines according to the following sequence from up to... -
Page 13: Drinking Temperature
respectively 2-5 hours or 4-5 hours before you drink, so you can have the proper drinking temperature. On the contrary, the white wine can be placed on the table directly. The champagne should be stored in the wine cooler until you want to dink. Please make sure that the temperature of the wine is always lower than the ideal drinking temperature because when you drink the wine into glass, the temperature of the wine will increase 34 - 36°F (1 - 2°C) immediately! -
Page 14: Power-Off & Stop Using Of Wine Cooler
Power-off & Stop Using of Wine Cooler Turn off Wine Cooler Pull out the power plug, and the wine cooler will be turned off. Stop Using Wine Cooler If you’re not going to use the wine cooler for a long time: 1. -
Page 15: Operation Noise
·Try not to open the door too often, especially when the weather is wet or hot. Once you open the door, mind to close it as soon as possible. ·Every now and then check if the appliance is sufficiently ventilated (adequate air circulation behind the appliance). -
Page 16: Troubleshooting By Yourself
Troubleshooting By Yourself Before you call the after-sales service phone number, please check if you are able to remove the failures according to the following hints. Failures Possible Causes Remediation Measures Sometimes, the problem Temperature is quite can be removed if you different from setting just turn off power of the wine cooler for 5...
