Summary of Contents for Lumina SH-LED252
-
Page 1: User Manual
LED Color Bar 252 x 10MM (SKU: SH-LED252) User Manual Please read the instructions carefully before use... -
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions 2. Technical Specifications 3. Installation 4. How to setup the unit 5. How to control the fixture 6. DMX512 Configuration 7. DMX512 Connections 8. Troubleshooting 9. Fixture Cleaning Copyright© Sunhope Inc 2013... - Page 3 1. Safety Introductions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the fixture to another user, be sure that they also receive this instruction booklet. ...
-
Page 4: Technical Specifications
2. Technical Specifications • DMX-512 Protocol Compatible (2,3,4,,6,7 or 14 DMX Channels) • 252 pcs 10mm RGB LEDs(84 red,84 green,84 blue) • 4 Operating Modes - Master/Slave; Auto; Sound Active,DMX512 • 0-100% strobe,0-100% dimmer flicker free • 255 static colours and RGB colour mixing •... -
Page 5: How To Setup The Unit
4. How To Set The Unit 4.1 Control Panel 1. Mains input：Connect to supply mains power. 2. DMX input: For DMX512 link, use 3pin XLR plug cable to input DMX signal. 3. DMX output：For DMX512 link, use 3/5-pin XLR plug cable to link the next unit. 4. -
Page 6: Ch14
4.2 Main Function DMX 512 Address Setting 1. Tap the either the MENU, UP, or DOWN buttons until “ADDR” is displayed, press ENTER. 2. “ ” will now be displayed . Press the UP or DOWN buttons to indicate your desired address.( ) Leave the display on this address, and after a few seconds the address will be saved into memory. - Page 7 confirm and exit. This will let you set unit as a master or slave in a master/slave configuration. 1. Tap the either the MENU,UP button until “ ” is displayed, press ENTER. “ ” to “ ” will be displayed. 2.
-
Page 8: Green
displayed. 2. Tap the UP or DOWN buttons to scroll through stand alone shows and sound activated. 3. Select your desired speed by pressing the ENTER button to confirm and exit. Blackout or Standby mode. 1. Tap the either the MENU,UP button until “ ”... -
Page 9: How To Control The Fixture
button and the display will blink. Use UP and DOWN button to select the (GREEN 000)to (GREEN 255). Manual mode BLUE Dimmer : Press ENTER to Manu mode when the is shown on the display. Press ENTER button and the display will blink. Use UP and DOWN button to select the (BLUE 000)to (BLUE 255). -
Page 10: Dmx512 Configuration
6. DMX512 Configuration 2 channels Mode: Channel Value Function 0 - 255 MACROS/PROGRAMS S P E E D / S O U N D SENSITIVITY 0 - 255 CONTROL SLOW → FAST 3 channels Mode: Channel Value Function 0 - 255 0→100% GREEN 0 - 255... -
Page 11: Macros/Programs
6 channels Mode: Channel Value Function 0 - 255 0→100% GREEN 0 - 255 0→100% BLUE 0 - 255 0→100% MACROS/PROGRAMS STROBE 1-255 SLOW→FAST SPEED/SOUND SENSITIVITY CONTROL* 0-255 SLOW→FAST 7channels Mode: Channel Value Function 0 - 255 0→100% GREEN 0 - 255 0→100% BLUE 0 - 255... - Page 12 14 channels Mode: Channel Value Function RED 1 0 - 255 0→100% GREEN 1 0 - 255 0→100% BLUE 1 0 - 255 0→100% RED 2 0 - 255 0→100% GREEN 2 0 - 255 0→100% BLUE 2 0 - 255 0→100% RED 3 0 - 255...
-
Page 13: Dmx512 Connections
7. DMX512 Connections The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the input of the next fixture. -
Page 14: Troubleshooting
8. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The fixture does not work, no light 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. B. -
Page 15: Fixture Cleaning
9. Fixture Cleaning The cleaning of internal must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics. ...
