PNI PORTAMATIC 475 Twin Trigger 20 Owner's Manual

Thin flooring stapler for 1/4” - 7/16” tongue and groove engineered and solid wood flooring
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
"PNI is a proud Member of these Industry Associati ons"
OWNER'S MANUAL
PORTAMATIC® 475 Twin Trigger 20
Thin Flooring Stapler For 1/4" - 7/16" Tongue and Groove
Engineered and Solid Wood Flooring
(PATENT PENDING)
CAUTION
- Read important safety instructi ons AND operati on
instructi ons BEFORE operati ng your Pneumati c Tool.
Your new Pneumati c Tool is capable of dependable performance
throughout its lifeti me. To take full advantage of these capabiliti es
you should thoroughly understand the proper method and technique
of its operati on. Therefore, we suggest you read this manual before
operati ng, and that you save it for future reference.
PO Box 1257, Wilmington, NC 28402
910-283-9791 • 800-634-9281 • Fax 910-283-6264
FORM P/N 475701 (4/22/2008)
Home Page: www.porta-nails.com E-mail: info@porta-nails.com
