Kalse INSTRUCTION MANUAL Instruction Manual

ANALOG MULTITESTER
INSTRUCTION MANUAL
KF-32
FOR SAFETY MEASUREMENTS!!
To prevent an electrical shock hazard to the operator and/or damage to the
instruments, read this instruction manual carefully before using the
instrument. WARNINGS with the symbol on the instrument and this
instruction manual are highly important.
Important Symbols :
The symbol listed in IEC 61010-1 and ISO 3864 means "Caution (refer
to instruction manual)".
WARNING
The symbol in this manual advises the user of an electrical shock hazard
that could result in serious injury or even death.
CAUTION
The symbol in this manual advises the user of an electrical shock hazard
that could cause injury or material damages.
WARNING
Do not measure High Power Line (High Energy Circuits). High Power Line
is very dangerous and sometimes includes High Surge Voltage that
could cause explosive short in the instrument and could result in serious
injury to the operator. This instrument is for Low Power Line
measurement. Even in the Low Power Line, pay careful attention when
measuring high voltage line.
INTRODUCTION
Thank you for purchasing KAISE "KF-32 ANALOG MULTITESTER". To obtain
the maximum performance of this instrument, read this Instruction Manual
carefully, and take safe measurement.
1. UNPACKING AND INSPECTIONS
Confirm if the following items are contained in the package in good condition.
If there is any damage or missing items, ask your local dealer for replacement.
1. Analog Multitester 1 pce. 4. Battery (1.5V R6P)
1 set
2. Test Lead (100-64) 5. Instruction Manual
3. Carrying Case (1020) 1 pce.
2. SPECIFICATIONS
2-1. GENERAL SPECIFICATIONS
1. DISPLAY•FAnalog Meter (Pivot-type 42ƒÊA)
2. METER PROTECTION•FOverload Protection by diode
3. CIRCUIT PROTECTION•F0.75A/250V fuse protection for mA, resistance, and continuity
ranges against over voltage up to 250V AC of commercial power supply.
4. RANGE SELECTION•FManual-ranging
5. POWER SUPPLY•F1.5V R6P (AA) battery x 1
6. FUSE•F0.75A/250V (5.2ƒÓ•~20mm) x 1
7. DIMENSIONS & WEIGHT•F136(H)•~90(W)•~30(D)mm, Approx. 215g
8. ACCESSORIES•F100-64 Test Lead, 1020 Carrying Case, 1.5V R6P (AA) battery x 1,
F15 Spare Fuse (0.75A/250V) x 1 (inside the case), Instruction Manual
9. OPTIONAL ACCESSORIES•F810-02 Temperature Probe, 100-41 Test Lead Kit,
100-62 Test Lead Set, 940 Alligator Clip
- 1 -
2-2. MEASUREMENT SPECIFICATION
Measurement Items Measurement Range
DC Voltage (DC.V) 0.3V/3V/12V/30V/120V/300V/1200V
AC Voltage (AC.V) 12V/30V/120V/300V/1200V
DC Current (DC.mA/A) 60ƒÊA/3mA/30mA/600mA/12A •@
Resistance ( ƒ¶ ) 5kƒ¶/500kƒ¶/5Mƒ¶ (•~1/•~1 00/•~1k)
Temperature ( •Ž ) •|50•Ž to •{250•Ž
•¦ 2
Continuity ( ) Buzzer at approx. 30Ħ or less
Internal Resistance : DC Voltage 20kĦ/V , AC Voltage 10kĦ/V
•¦NO TE 1 : Continuous measurement in 12A DC range is restricted up to 1 minute.
More than 1 minute interval is necessary for the next measurement.
•¦NO TE 2 : Temperature measurement requires the optional 810-02 temperature probe.
3. SAFETY PRECAUTIONS
Correct knowledge of electric measurements is essential to avoid unexpected
danger such as operator's injury or damage to the instrument. Read the following
precautions carefully for safety measurements.
3-1. WARNINGS
WARNING 1. Checks of the Instrument and Test Leads
Before measurement, check if there are no damage to the instrument and the test
leads. Dust, grease and moisture must be removed.
WARNING 2. Prohibition of High Power Line Measurement
Do not measure High Power Line (High Energy Circuits) such as Distribution
Transformers, Bus Bars and Large Motors. High Power Line sometimes includes
High Surge Voltage that could cause explosive short in the instrument and could
result in shock hazard. Generally, shock hazard could occur when the current
between the circuit, that involves more than 30V AC or 42.4V DC, and ground
goes up to 0.5mA or more.
WARNING 3. Warning for High Voltage Measurement
Even for Low Power Circuits of electric/electronic appliances, such as heating
elements, small motors, line cords and plugs, High Voltage Measurements are
very dangerous. To avoid electric shock hazard, pay careful attention not to touch
any part of the circuit.
WARNING 4. Warning for Dangerous Voltage Measurement
For dangerous high voltage measurement, strictly observe the warnings below
(see Fig. 1).
Do not hold the instrument in your hands.
•œ
Keep safety distance from the circuit to be measured and the test leads not to
•œ
touch the dangerous voltage.
Attach black and red alligator clips to the test lead pins.
•œ
Shut down the power of the circuit when connecting test leads to the circuit to
•œ
be measured.
After finishing the measurement, shut down the power of the circuit again and
•œ
discharge the all capacitors. Then, detach alligator clips (test leads) from the
circuit.
Black
DC.V AC. V
1200 OFF 1200
0 Ħ
300 300
120 120
30 30
1 pce.
12 12
12A 3 • ~1k
0.3
1 pce.
• ~ 100
60 ƒÊ A TEMP
3 • ~ 1
DC.
30 Bz
mA /A 600 ƒ¶ •Ž
12A COM
In case of live-line measurement, strictly observe the warnings below :
(see Fig. 2)
Do not hold the instrument in your hands.
•œ
Keep safety distance from the circuit to be measured not to touch the
•œ
dangerous voltage.
•œ Black test lead : Attach black alligator clip and connect to •| (earth) side of the circuit.
Red test lead : Connect to •{ (positive) side of the circuit.
•œ
Black
DC.V AC. V
1200 OFF 1200
0 Ħ
300 300
120 120
30 30
12 12
12A 3 • ~1k
0.3
• ~ 100
60 ƒÊ A TEMP
3 • ~ 1
DC.
30 600 Bz ƒ¶ •Ž
mA /A
12A COM
- 2 -
WARNING 5. Warning for 12A DC Measurement
Set RANGE Switch to 600/12A position and insert red test lead to 12A terminal.
1.
Tolerance
(Insert black test lead to •|COM terminal.)
2. 12A DC range is not fuse-protected. Do not measure any current that might
•}3% full scale
exceed 12A to avoid electric shock hazard and serious damage to the instrument.
•}4% full scale
Do not measure any voltage in 12A DC range. Do not measure •{/•| terminals
3.
•}3% full scale
•¦ 1 of car battery directly (fig. 3). Do not measure household wall socket (fig. 4).
•}3% f .s. length
•}3% f .s. length
DC.V AC. V
OFF
1200 1200
300 300 0
120 120
30 30
12 12
12A 3 • ~1k
0.3
• ~ 100
60 ƒÊ A
TEMP
3 • ~ 1
DC.
30 Bz
mA /A 600 ƒ¶ •Ž
12A COM
DC.V AC. V
OFF
1200 1200
0
300 300
120 120
30 30
12 12
12A 3 • ~1k
0.3
• ~ 100
60 ƒÊ A
TEMP
3 • ~ 1
DC.
30 Bz
mA /A 600 ƒ¶ •Ž
12A COM
WARNING 6. Correct Selection of Range Switch
Always confirm that RANGE Switch is set to the correct position. Do not measure
any voltage except in the DC.V and AC.V ranges.
WARNING 7. Maximum Input Observance
Do not measure any elements that might exceed the specified maximum input
values of each measurement ranges.
WARNING 8. Test Lead Detachment
Detach test leads from the measuring circuit before changing RANGE Switch to
another position or removing rear case for battery or fuse replacement.
3-2. GENERAL WARNINGS AND CAUTIONS
WARNING 1. Children and the persons who do not have enough knowledge
about electric measurements must not use this instrument.
WARNING 2. Do not measure the electricity in naked of barefooted to
protect yourself from electrical shock hazard.
WARNING 3. Be careful not to get hurt with the sharp test lead pins.
CAUTION 1. Away the instrument from hot and humid conditions like in
the car. Do not apply hard mechanical shock or vibration.
CAUTION 2. Do not polish the case or attempt to clean it with any cleaning
fluid like gasoline or benzine. If necessary, use silicon oil or
antistatic fluid.
CAUTION 3. Remove the battery when the instrument is out of use for a
long time. The exhausted battery might leak electrolyte and
corrode the inside.
Alligator
Clips
Red
4. NAME ILLUSTRATION
Fig. 1
Meter Pointer
Zero Adjustment
Screw
RANGE Switch
12A Terminal
Red
Fig. 2
4-1. RANGE Switch
Set RANGE Switch to an appropriate measurement range. When measuring
uncertain voltage or current, firstly set the switch to the highest range enabling to
measure an approximate value. Then, change the switch to an appropriate range.
Notes for the appropriate range selection
Voltage and Current :
Resistance : Place the pointer around the center of Ħ scale.
Red
Black
•œ
Ħ
•œ
Car Battery
Fig. 3
4-2. Meter Scale (How to read)
Household
Wall Socket
Ħ
Red
Black
Fig. 4
1. DC/AC Scale : AC/DC Voltage, DC Current
Select appropriate scale from "0 - 6", "0 - 12", or "0 - 30" according to the selected
measurement range applying the certain multiple.
Multiply the scale value by the measurement range value.
3. TEMP (•Ž) Scale : Temperature
Read the scale value directly.
4-3. Meter Mirror (How to see the pointer)
The mirror to help the correct reading avoiding the reading error. Read the
meter scale from the position that the meter pointer and its image in the
mirror overlap each other. This position is directly above the meter pointer.
Meter scale must be read viewing the pointer from directly above, but the
clearance between the pointer and the meter scale often causes reading
error if the point of view is moved off to the side.
4-4. Zero Adjustment Screw
Use to take zero adjustment in Voltage and Current measurements. Check if the
meter points to "0" line on the left side of DC/AC scale before starting the
measurement. If it is not on the line, turn Zero Adjustment Screw until the meter
points to "0". This adjustment is necessary for accurate reading.
4-5. 0Ħ Adjustment Knob
Use to take 0Ħ adjustment in Resistance and Temperature measurements. Refer
Meter Mirror to "5-5. Resistance Measurement (ƒ¶)" and "5-6. Temperature Measurement (•Ž )"
for details.
Meter Scale
4-6. Input Terminals•ETest Leads
Insert black test lead to •| COM terminal, and insert red test lead to •{ or 12A terminal.
NOTE : Insert red test lead to 12A terminal for 12A DC measurement. For the
DC.V AC. V 0Ħ Adjustment Knob
other measurements, connect it to •{ terminal.
OFF
1200 1200
0
300 300 Ħ
(on the side)
120 120
30 30
5. MEASUREMENT PROCEDURES
12 12 •{ Terminal
12A 3 • ~1k
0.3
• ~ 100
60 ƒÊ A 5-1. PREPARATION FOR USE
TEMP
•|COM Terminal
3 • ~ 1
DC.
30 Bz
600 ƒ¶ •Ž
mA /A
12A
COM
1. INSTRUCTION MANUAL
Read INSTRUCTION MANUAL carefully to understand the specification and
functions properly. "3. SAFETY PRECAUTIONS" is very important for safety
Test Leads
measurement.
Fig. 5
- 3 -
Place the pointer right side of the meter scale (between
the center and the maximum scale).
WARNING
Before starting the measurement, confirm that the RANGE Switch is set to
the correct position. Do not measure any voltage except in the DC.V and AC.V
ranges to avoid electric shock hazard and serious damage to the instrument.
To avoid electric shock hazard or serious damage to the instrument, detach
test leads from the measuring circuit before changing RANGE Switch to
another position.
Ħ scale
DC/AC scale
Common use for;
DC Voltage (DC.V)
AC Voltage (AC.V)
DC Current (DC.mA/A)
TEMP(•Ž) scale
(V, ƒÊA, mA, A)
1
Examples : 0.3V DC range : Read "0 - 30" scale multiplying by .
100
120V DC range : Read "0 - 12" scale multiplying by 10.
60ƒÊA DC range : Read "0 - 6" scale multiplying by 10.
600mA DC range : Read "0 - 6" scale multiplying by 100.
Examples : •~1 range : Read the scale value directly.
•~100 range : Multiply the scale value by 100.
•~1k range : Multiply the scale value by 1,000.
(•Ž)
- 4 -
Fig. 6
