Operating Manual
BCSi-1 *
Barcode scanner
Doc.Nr.:60000340
MANUAL BCSI-1 REV 1.7 EN.DOC
19.12.08
A.J.
- 1 -

Advertisement

Table of Contents
loading

Related Manuals for GECMA BCSi-1 series

Summary of Contents for GECMA BCSi-1 series

  • Page 1 Operating Manual BCSi-1 * Barcode scanner Doc.Nr.:60000340 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 1 -...

  • Page 2: Table Of Contents

    List of Contents List of Contents........................2 Introduction ........................3 BCSi-1 * models available ....................4 Technical Data........................5 Certificates ........................7 Connections details......................8 Terminal Connections....................11 Available Barcode symbologys and default settings ..........12 Sample barcodes......................15 Programming BCSi......................17 Appendix A ........................21 ASCII Value Table ......................23 Barcode settings......................28 Safety Instructions ......................78 General Instructions ......................79 Drawings and certifications ..................79...

  • Page 3: Introduction

    Introduction The barcode scanner BCSi are designed to read all common barcodes 1D & 2D and to transmit these barcode data to an existing ASD (application supporting device) in hazardous or non-hazardous areas. The BCSi is freely positionable in front of the barcode. A interactive vibration feedback after a successful scan is offered by the BCSi (an advantage for loud environments).

  • Page 4: Bcsi-1 * Models Available

    BCSi-1 * models available Various models of BCSi-1 * can be supplied: -1 = C LP : Cable barcode scanner Low Power. Barcode scanner with cable connection and low intrinsically safe input power at the power line. The connection interface to the other existing application supporting devices is realized via serial intrinsically safe interface.

  • Page 5: Technical Data

    Technical Data For all BCSi versions: Housing type: Stainless steel 1.4301 / AISI 304 (or on request) Ingress protection: IP67 Operating temperature range: -20°C to +60°C (-4°F to 140°F), 15 to 95% rel. humidity, n. cond. Storage temperature: -20 °C - +35°C (-4°F to 95°F), 15 to 85% rel. humidity, n. cond. -20 °C - +60°C (-4°F to 140°F), 15 to 85% rel.
  • Page 6 Cable fixed mounted. Exchangeable by Gecma only. Note (for BCSi-C LP only): This variant is developed with internal energybuffer to provide the necessary power for the scanner electronic (duty cycle typ. 5%). A pre charging of typ. 16h for this internal buffer necessary before first operation.

  • Page 7: Certificates

    Certificates ATEX certification Product Zone 0 / EPL Ga Zone 20 / EPL Da BCSi-1 ATEX ignition protection Ex II 1G Ex ia op is Ga IIC Ex II 1D Ex iaD 20 T130°C Operating/storage T° Ta: -20°C ... +60°C Ta: -20°C ...

  • Page 8: Connections Details

    Connections details BCSi-C LP: When the distance between the supply line (X91-1) and the data lines (X91-3 and X91-4) at the associated apparatus comply to the clearance / creepage distances and separation on the standard IEC/EN 60079-11: Supply voltage: X91-1, Intrinsically safe ia: Contact 1: Contact 2: ≤...
  • Page 9 When the distance between the supply line (X91-1) and the data lines (X91-3 and X91-4) at the associated apparatus not comply to the clearance / creepage distances and separation on the standard IEC/EN 60079-11: Supply voltage / Data: X91-1, X91-3, X91-4, Intrinsically safe ia: Contact 1: Contact 2: Contact 3:...
  • Page 10 Data Lines: X91-3, X91-4, Intrinsically safe ia: Contact 3: RXD (input) Contact 4: TXD (output) ≤ 25 V ≤ not important ≤ not important ≤ negligible ≤ negligible ≤ 5,4 V ≤ 11,4 mA ≤ 14,1 mW ≤ 0,3 mH ≤...

  • Page 11: Terminal Connections

    BCSi-RF 10 / BCSi-RF100: Charging voltage: X92, Intrinsically safe ia: Contact inside: Contact outside: GND ≤ 10,8 V ≤ not important ≤ not important ≤ negligible ≤ negligible ≤ negligible ≤ negligible ≤ negligible ≤ negligible ≤ negligible Recommended max. cable length 5m (16,4ft). Pay attention to the values listed in corresponding standards.

  • Page 12: Available Barcode Symbologys And Default Settings

    Available Barcode symbologys and default settings To ensure best barcode reading results we recommend to enable the used barcode only. For flexibility we recommend to disable as few as possible unused barcodes. To enable or disable a barcode refer associated chapter at “Programming BCSi”. Symbology Barcode parameter Default...
  • Page 13 Code 32 Prefix Disable Set Length(s) for Code 39 2 to 55 Code 39 Check Digit Verification Disable Transmit Code 39 Check Digit Disable Code 39 Full ASCII Conversion Disable Code 93 Code 93 Disable Set Length(s) for Code 93 4 to 55 Code 11 Code 11...

  • Page 14: Code 128

    Australian Postal Enable Dutch Postal Enable Transmit US Postal Check Digit Enable RSS (Red. Sp. Symb.) RSS 14 Enable RSS Limited Enable RSS Expanded Enable Convert RSS to UPC/EAN Disable Composite Composite CC-C Disable Composite CC-A/B Disable Composite TLC-39 Disable UPC Composite Mode Always Linked UCC/EAN Code 128 Emulation Mode for UCC/EAN...

  • Page 15: Sample Barcodes

    Sample barcodes EAN-13/JAN 13 Code 128 Code 39 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 15 -...
  • Page 16 Data Matrix Gecma BCSi Barcode Scanner with vibration feedback Gecma BCSi Barcode Scanner with vibration feedback available as cable and RF version Maxicode Gecma barcodescanner available as cable and RF version MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 16 -...

  • Page 17: Programming Bcsi

    Programming BCSi Presettings done by Gecma Components GmbH (indicated by “*”). Don’t scale or modify the barcodes. We recommend to program “Set Default Parameter” only. Changes/adjustments are under owner’s responsibility. Set Default Parameter Scan this bar code to return all parameters to the default values...
  • Page 18 Decoding Illumination Selecting Enable Illumination causes the decoder to flash illumination on every image capture to aid decoding. Select Disable Illumination to prevent the decoder from using decoding illumination. Enabling illumination usually results in superior images. The effectiveness of the illumination decreases as the distance to the target increases.

  • Page 19: Data>

    Prefix/Suffix Values A prefix and/or one or two suffixes can be appended to scan data for use in data editing. To set a value for a prefix or suffix, scan a prefix or suffix bar code below, then scan a four-digit number (i.e., four bar codes from Appendix A, Numeric Bar Codes) that corresponds to that value.
  • Page 20 <DATA> <SUFFIX 2> <DATA> <SUFFIX 1> <SUFFIX 2> <PREFIX> <DATA> <PREFIX> <DATA> <SUFFIX 1> <PREFIX> <DATA> <SUFFIX 2> <PREFIX> <DATA> <SUFFIX 1> <SUFFIX 2> MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 20 -...

  • Page 21: Appendix A

    Appendix A Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriately numbered bar code(s). MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 21 -...
  • Page 22 Cancel To correct an error or change a selection, scan the bar code below. Cancel MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 22 -...

  • Page 23: Ascii Value Table

    ASCII Value Table ASCII Value Table Full ASCII Code 39 ASCII Value Keystroke Encode Char 1000 CTRL 2 1001 CTRL A 1002 CTRL B 1003 CTRL C 1004 CTRL D 1005 CTRL E 1006 CTRL F 1007 CTRL G 1008 CTRL H/BACKSPACE 1009 CTRL I/HORIZONTAL TAB...
  • Page 24 ASCII Value Table Full ASCII Code 39 ASCII Value Keystroke Encode Char 1025 CTRL Y 1026 CTRL Z 1027 CTRL [ 1028 CTRL \ 1029 CTRL ] 1030 CTRL 6 1031 CTRL - 1032 Space Space 1033 1034 “ 1035 1036 1037 1038...
  • Page 25 ASCII Value Table Full ASCII Code 39 ASCII Value Keystroke Encode Char 1052 1053 1054 1055 1056 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 The keystroke in bold is sent only if the Function Key Mapping is enabled.
  • Page 26 ASCII Value Table Full ASCII Code 39 ASCII Value Keystroke Encode Char 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 ‘ 1097 1098 1099 1100 1101 1102 1103 1104 1105 The keystroke in bold is sent only if the Function Key Mapping is enabled.
  • Page 27 ASCII Value Table Full ASCII Code 39 ASCII Value Keystroke Encode Char 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126 The keystroke in bold is sent only if the Function Key Mapping is enabled. Otherwise, the unbold keystroke is sent.

  • Page 28: Barcode Settings

    Barcode settings UPC/EAN Enable/Disable UPC-A To enable or disable UPC-A, scan the appropriate bar code below. * Enable UPC-A Disable UPC-A Enable/Disable UPC-E To enable or disable UPC-E, scan the appropriate bar code below. * Enable UPC-E Disable UPC-E MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J.
  • Page 29 Enable/Disable UPC-E1 UPC-E1 is disabled by default. To enable or disable UPC-E1, scan the appropriate bar code below. UPC-E1 is not a UCC (Uniform Code Council) approved symbology. Enable UPC-E1 * Disable UPC-E1 Enable/Disable EAN-8/JAN-8 To enable or disable EAN-8/JAN-8, scan the appropriate bar code below. * Enable EAN-8/JAN-8 Disable EAN-8/JAN-8 MANUAL BCSI-1 REV 1.7 EN.DOC...
  • Page 30 Enable/Disable EAN-13/JAN-13 To enable or disable EAN-13/JAN-13, scan the appropriate bar code below. * Enable EAN-13/JAN-13 Disable EAN-13/JAN-13 Enable/Disable Bookland EAN To enable or disable Bookland EAN, scan the appropriate bar code below. Enable Bookland EAN * Disable Bookland EAN MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J.
  • Page 31 Decode UPC/EAN/JAN Supplementals Supplementals are bar codes appended according to specific format conventions (e.g., UPC A+2, UPC E+2, EAN 13+2). Six options are available. • If Decode UPC/EAN/JAN Only With Supplementals is selected, UPC/EAN/JAN symbols without supplementals are not decoded. •...
  • Page 32 Enable 378/379 Supplemental Mode Enable 978 Supplemental Mode Enable Smart Supplemental Mode UPC/EAN/JAN Supplemental Redundancy With Autodiscriminate UPC/EAN/JAN Supplementals selected, this option adjusts the number of times a symbol without supplementals is decoded before transmission. The range is from two to thirty times. Five or above is recommended when decoding a mix of UPC/EAN/JAN symbols with and without supplementals, and the autodiscriminate option is selected.
  • Page 33 Transmit UPC-A Check Digit The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-A check digit. It is always verified to guarantee the integrity of the data.
  • Page 34 Transmit UPC-E1 Check Digit The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-E1 check digit. It is always verified to guarantee the integrity of the data.
  • Page 35 UPC-E Preamble Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble. Select the appropriate option to match the host system.
  • Page 36 UPC-E1 Preamble Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E1 preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble. Select the appropriate option to match the host system.
  • Page 37 Convert UPC-E1 to UPC-A Enable this to convert UPC-E1 decoded data to UPC-A format before transmission. After conversion, the data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit). When disabled, UPC-E1 decoded data is transmitted as UPC-E1 data, without conversion. Convert UPC-E1 to UPC-A (Enable) * Do Not Convert UPC-E1 to UPC-A (Disable) EAN-8/JAN-8 Extend...
  • Page 38 UCC Coupon Extended Code When enabled, this parameter decodes UPC-A bar codes starting with digit ‘5’, EAN-13 bar codes starting with digit ‘99’, and UPCA/EAN-128 Coupon Codes. UPCA, EAN-13, and EAN-128 must be enabled to scan all types of Coupon Codes. Use the Decode UPC/EAN Supplemental Redundancy parameter to control autodiscrimination of the EAN128 (right half) of a coupon code.

  • Page 39: Code 128

    Code 128 Enable/Disable Code 128 To enable or disable Code 128, scan the appropriate bar code below. * Enable Code 128 Disable Code 128 Enable/Disable UCC/EAN-128 To enable or disable UCC/EAN-128, scan the appropriate bar code below. * Enable UCC/EAN-128 Disable UCC/EAN-128 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08...
  • Page 40 Enable/Disable ISBT 128 ISBT 128 is a variant of Code 128 used in the blood bank industry. Scan a bar code below to enable or disable ISBT 128. If necessary, the host must perform concatenation of the ISBT data. * Enable ISBT 128 Disable ISBT 128 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08...
  • Page 41 Code 39 Enable/Disable Code 39 To enable or disable Code 39, scan the appropriate bar code below. * Enable Code 39 Disable Code 39 Enable/Disable Trioptic Code 39 Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges. Trioptic Code 39 symbols always contain six characters.
  • Page 42 Convert Code 39 to Code 32 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable converting Code 39 to Code 32. Code 39 must be enabled for this parameter to function. Enable Convert Code 39 to Code 32 * Disable Convert Code 39 to Code 32 Code 32 Prefix...
  • Page 43 Set Lengths for Code 39 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Code 39 to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 44 Code 39 – Length Within Range Code 39 – Any Length Code 39 Check Digit Verification When this feature is enabled, the decoder checks the integrity of all Code 39 symbols to verify that the data complies with specified check digit algorithm. Only Code 39 symbols which include a modulo 43 check digit are decoded.
  • Page 45 Transmit Code 39 Check Digit Scan a bar code below to transmit Code 39 data with or without the check digit. Code 39 Check Digit Verification must be enabled for this parameter to function. Transmit Code 39 Check Digit (Enable) * Do Not Transmit Code 39 Check Digit (Disable) Code 39 Full ASCII Conversion Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII character set.
  • Page 46 Code 93 Enable/Disable Code 93 To enable or disable Code 93, scan the appropriate bar code below. Enable Code 93 * Disable Code 93 Set Lengths for Code 93 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.
  • Page 47 Code 93 – One Discrete Length Code 93 – Two Discrete Lengths Code 93 – Length Within Range Code 93 – Any Length Code 11 Code 11 To enable or disable Code 11, scan the appropriate bar code below. Enable Code 11 * Disable Code 11 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08...
  • Page 48 Set Lengths for Code 11 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Code 11 to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 49 Code 11 Check Digit Verification This feature allows the decoder to check the integrity of all Code 11 symbols to verify that the data complies with the specified check digit algorithm. This selects the check digit mechanism for the decoded Code 11 bar code.
  • Page 50 Transmit Code 11 Check Digits This feature selects whether or not to transmit the Code 11 check digit(s). Code 11 Check Digit Verification must be enabled for this parameter to function. Transmit Code 11 Check Digit(s) (Enable) * Do Not Transmit Code 11 Check Digit(s) (Disable) Interleaved 2 of 5 (ITF) Enable/Disable Interleaved 2 of 5 To enable or disable Interleaved 2 of 5, scan the appropriate bar code below, and select an Interleaved 2...
  • Page 51 Set Lengths for Interleaved 2 of 5 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for I 2 of 5 to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 52 I 2 of 5 – Length Within Range I 2 of 5 – Any Length I 2 of 5 Check Digit Verification When this feature is enabled, the decoder checks the integrity of all I 2 of 5 symbols to verify the data complies with either the specified Uniform Symbology Specification (USS), or the Optical Product Code Council (OPCC) check digit algorithm.
  • Page 53 Transmit I 2 of 5 Check Digit Scan the appropriate bar code below to transmit I 2 of 5 data with or without the check digit. Transmit I 2 of 5 Check Digit (Enable) * Do Not Transmit I 2 of 5 Check Digit (Disable) Convert I 2 of 5 to EAN-13 Enable this parameter to convert 14-character I 2 of 5 codes to EAN-13, and transmit to the host as EAN-13.
  • Page 54 Discrete 2 of 5 (DTF) Enable/Disable Discrete 2 of 5 To enable or disable Discrete 2 of 5, scan the appropriate bar code below. Enable Discrete 2 of 5 * Disable Discrete 2 of 5 Set Lengths for Discrete 2 of 5 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.
  • Page 55 D 2 of 5 – One Discrete Length D 2 of 5 – Two Discrete Lengths D 2 of 5 – Length Within Range D 2 of 5 – Any Length Codabar (NW - 7) Enable/Disable Codabar To enable or disable Codabar, scan the appropriate bar code below. Enable Codebar * Disable Codebar MANUAL BCSI-1 REV 1.7 EN.DOC...
  • Page 56 Set Lengths for Codabar The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Codabar to any length, one or two discrete lengths, or lengths within a specific range. •...
  • Page 57 CLSI Editing When enabled, this parameter strips the start and stop characters and inserts a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Enable this feature if the host system requires this data format. Symbol length does not include start and stop characters. Enable CLSI Editing * Disable CLSI Editing NOTIS Editing...
  • Page 58 Enable/Disable MSI To enable or disable MSI, scan the appropriate bar code below. Enable MSI * Disable MSI Set Lengths for MSI The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for MSI to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 59 MSI – One Discrete Length MSI – Two Discrete Lengths MSI – Length Within Range MSI – Any Length MSI Check Digits With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional.
  • Page 60 Transmit MSI Check Digit(s) Scan a bar code below to transmit MSI data with or without the check digit. Transmit MSI Check Digit(s) (Enable) * Do Not Transmit MSI Check Digit(s) (Disable) MSI Check Digit Algorithm Two algorithms are possible for the verification of the second MSI check digit. Select the bar code below corresponding to the algorithm used to encode the check digit.

  • Page 61: Postal Codes

    Postal Codes US Postnet To enable or disable US Postnet, scan the appropriate bar code below. * Enable US Postnet Disable US Postnet US Planet To enable or disable US Planet, scan the appropriate bar code below. * Enable US Planet Disable US Planet MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08...
  • Page 62 UK Postal To enable or disable UK Postal, scan the appropriate bar code below. * Enable UK Postal Disable UK Postal Transmit UK Postal Check Digit Select whether to transmit UK Postal data with or without the check digit. * Transmit UK Postal Check Digit Do Not Transmit UK Postal Check Digit MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08...
  • Page 63 Japan Postal To enable or disable Japan Postal, scan the appropriate bar code below. * Enable Japan Postal Disable Japan Postal Australian Postal To enable or disable Australian Postal, scan the appropriate bar code below. * Enable Australian Postal Disable Australian Postal MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J.
  • Page 64 Dutch Postal To enable or disable Dutch Postal, scan the appropriate bar code below. * Enable Dutch Postal Disable Dutch Postal Transmit US Postal Check Digit Select whether to transmit US Postal data with or without the check digit. * Transmit US Postal Check Digit Do Not Transmit US Postal Check Digit MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08...
  • Page 65 RSS (Reduced Space Symbology) The variants of RSS are RSS 14, RSS Expanded, and RSS Limited. The limited and expanded versions have stacked variants. Scan the appropriate bar code below to enable or disable each variant of RSS. RSS-14 * Enable RSS 14 Disable RSS 14 RSS Limited * Enable RSS Limited...
  • Page 66 RSS Expanded * Enable RSS Expanded Disable RSS Expanded Convert RSS to UPC/EAN This parameter only applies to RSS-14 and RSS Limited symbols not decoded as part of a Composite symbol. Enable this to strip the leading '010' from RSS-14 and RSS Limited symbols encoding a single zero as the first digit, and report the bar code as EAN-13.
  • Page 67 Composite Composite CC-C Scan a bar code below to enable or disable Composite bar codes of type CC-C. Enable CC-C * Disable CC-C Composite CC-A/B Scan a bar code below to enable or disable Composite bar codes of type CC-A/B. Enable CC-A/B * Disable CC-A/B MANUAL BCSI-1 REV 1.7 EN.DOC...
  • Page 68 Composite TLC-39 Scan a bar code below to enable or disable Composite bar codes of type TLC-39. Enable TLC39 * Disable TLC39 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 68 -...
  • Page 69 UPC Composite Mode UPC symbols can be “linked” with a 2D symbol during transmission as if they were one symbol. There are three options for these symbols: • Select UPC Never Linked to transmit UPC bar codes regardless of whether a 2D symbol is detected. •...
  • Page 70 2D Symbologies Enable/Disable PDF417 To enable or disable PDF417, scan the appropriate bar code below. * Enable PDF417 Disable PDF417 Enable/Disable MicroPDF417 To enable or disable MicroPDF417, scan the appropriate bar code below. Enable MicroPDF417 * Disable MicroPDF417 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J.
  • Page 71 Code 128 Emulation When this parameter is enabled, the BCSi transmits data from certain MicroPDF417 symbols as if it was encoded in Code 128 symbols. Transmit AIM Symbology Identifiers must be enabled for this parameter to work. If Code 128 Emulation is enabled, these MicroPDF417 symbols are transmitted with one of the following prefixes: ]C1 if the first codeword is 903-907, 912, 914, 915 ]C2 if the first codeword is 908 or 909...
  • Page 72 Data Matrix To enable or disable Data Matrix, scan the appropriate bar code below. * Enable Data Matrix Disable Data Matrix Maxicode To enable or disable Maxicode, scan the appropriate bar code below. * Enable Maxicode Disable Maxicode MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J.
  • Page 73 QR Code To enable or disable QR Code, scan the appropriate bar code below. * Enable QR Code Disable QR Code MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 73 -...
  • Page 74 Redundancy Level The decoder offers four levels of decode redundancy. Select higher redundancy levels for decreasing levels of bar code quality. As redundancy levels increase, the decoder’s aggressiveness decreases. Select the redundancy level appropriate for the bar code quality. Redundancy Level 1 The following code types must be successfully read twice before being decoded: Code Type Code Length...
  • Page 75 * Redundancy Level 1 Redundancy Level 2 Redundancy Level 3 Redundancy Level 4 MANUAL BCSI-1 REV 1.7 EN.DOC 19.12.08 A.J. - 75 -...
  • Page 76 Security Level The decoder offers four levels of decode security for delta bar codes, which include the Code 128 family, UPC/EAN, and Code 93. Select increasing levels of security for decreasing levels of bar code quality. There is an inverse relationship between security and decoder aggressiveness, so choose only that level of security necessary for any given application.
  • Page 77 Intercharacter Gap Size The Code 39 and Codabar symbologies have an intercharacter gap that is typically quite small. Due to various bar code-printing technologies, this gap can grow larger than the maximum size allowed, preventing the decoder from decoding the symbol. If this problem occurs, scan the Large Intercharacter Gaps parameter to tolerate these out-of-specification bar codes.

  • Page 78: Safety Instructions

    Only use this device for the approved purpose. Conversions and modifications to the device are inadmissible. The housing is only to be opened by the company Gecma Components GmbH. The first two digits of the serial number located at the nameplate identify the year of manufacture Assembly The national assembly and installation regulations are to be observed.

  • Page 79: General Instructions

    We do not assume liability for misprints and errors in this operating manual. The housings shall only be opened by personnel of Gecma Components GmbH. Should you have any questions or suggestions please feel free to contact us any time: GeCma Components GmbH Heisenbergstraße 26 –...
