TABLE OF CONTENTS RECEIVING THE AIR CONDITIONER ....................................3 HANDLING AND TESTING THE AIR CONDITIONER ..............................3 HOW TO READ MODEL NUMBERS ....................................3 TECHNICAL INFORMATION ......................................4 Sequence of Operation ............................................4 Heating................................................4 Cooling ................................................4 Standard and Optional Component Operation .....................................4 Thermostat ..............................................4 Remote Access Control (optional) .......................................4 Head Pressure Control (optional) ........................................4 Contactor (460V Units only) ..........................................4 Overload (460V Units only) ...........................................4...
RECEIVING THE AIR CONDITIONER Inspect the air conditioner. Check for concealed damage that may have occurred during shipment. Look for dents, scratches, loose assemblies, evidence of oil, etc. Damage evident upon receipt should be noted on the freight bill. Damage should be brought to the attention of the delivering carrier -- NOT to Pentair Equipment Protection -- within 15 days of delivery.
TECHNICAL INFORMATION SEQUENCE OF OPERATION The air conditioner comes standard with two internally mounted thermostats or remote access control. There are two modes of operation; heating and cooling. During heating and cooling modes the evaporator fan will be running. HEATING When the enclosure temperature is below the heating thermostat setpoint, power is applied to the heaters.
PHASE MONITOR This product is equipped with Phase/Voltage Protection. Please verify correct phasing and voltage before operating. Note the fans may still operate if phasing is incorrect, but the compressor will not, so the unit will not cool. Illuminated light on Phase Monitor indicates phase is correct. If the light is not illuminated, disconnect power from the unit and swap any two power leads at the terminal block.
INSTALLATION INSTRUCTIONS 1. Inspect the air conditioner and verify correct functionality before mounting the air conditioner. See HANDLING AND TESTING THE AIR CONDITIONER on page 3. 2. Using the mounting gasket kit provided with the unit, install gaskets to the air conditioner, see Figure 1.
REMOTE ACCESS CONTROL (OPTIONAL) INTRODUCTION The Remote Access Control is a parametric controller for the complete management of air conditioners. All settings are pre-programmed at the factory. Cooling/heating set-points, cooling/heating differential and high /low temperature alarm set-points can be adjusted by the user. Alarms are outputted through a relay contact and also can be accessed through an Ethernet connection utilizing SNMP, EtherNet/IP and Modbus TCP.
DISPLAYING AND CHANGING PROGRAM VARIABLES Access: To view and/or change parameters, press and hold the Prg and Sel buttons for greater than 5 seconds. Press the up or down arrow buttons until “22” is displayed, then press Sel button. When “S-P” is displayed, press Sel.
ALARM INPUT CONNECTION The Remote Access Control can accept a dry contact/switch input via the two 18 AWG white wires located at the back of the air conditioner. This input is associated with the controller display alarm mnemonic TP (door open and/or smoke detected).
USING THE PC INTERFACE TOOL The PC Interface Tool gives the user the ability to communicate with the air conditioner unit to read/write parameters using either Ethernet or USB connections. USB COMMUNICATION MODE NOTE: Before connecting unit to the PC, make note of the comm ports present. After the unit is connected to the PC, a new comm port will be added to the list.
ETHERNET COMMUNICATION MODE From Tools menu select Use Ethernet • • When Use Ethernet is checked, Comm Port selection is disabled, Device IP and Community boxes are shown and Ethernet communication can be used. Enter unit’s IP Address and Community string in Device IP and Community boxes at the bottom of the PC Interface •...
INSTALLATION INSTRUCTIONS WITH REMOTE ACCESS CONTROL 1. Inspect the air conditioner and verify correct functionality before mounting the air conditioner. See HANDLING AND TESTING THE AIR CONDITIONER on page 3. 2. Using the mounting gasket kit provided with the unit, install gaskets to the air conditioner, see Figure 2.
MAINTENANCE COMPRESSOR The compressor requires no maintenance. It is hermetically sealed, properly lubricated at the factory and should provide years of satisfactory operating service. Under no circumstances should the access fitting covers be loosened, removed or tampered with. Breaking of seals on compressor access fittings during warranty period will void warranty on hermetic system. Recharging ports are provided for the ease and convenience of reputable refrigeration repair service personnel for recharging the air conditioner.
CONDENSER AND EVAPORATOR AIR MOVERS Impeller motors require no maintenance. All bearings, shafts, etc. are lubricated during manufacturing for the life of the motor. If one of the condenser impeller motors (ambient impellers) should fail, it is not necessary to remove the air conditioner from the cabinet or enclosure to replace the blower.
4000/6000 BTU UNIT CHARACTERISTICS Part Number G280416GXXX G280426GXXX G280616GXXX G280626GXXX G280446GXXX G280646GXXX Dimensional Data Height 28.55/725.2mm 28.55/725.1 mm 28.55/725.2mm Width 16.97/431.1mm 16.97/431.1mm 16.97/431.1mm Depth 11.10/281.9mm 10.10/256.6mm 10.10/256.6mm 10.10/256.6mm Unit Weight 82 lbs/37 kg 84 lbs/38 kg 84 lbs/38 kg 84 lbs/38 kg Unit Protection Type 12/4/4X/3R Type 12/4/4X/3R...
TROUBLE SHOOTING BASIC AIR CONDITIONING TROUBLE SHOOTING CHECK LIST - THERMOSTAT VERSION 1. Check manufacturer’s nameplate located on the unit for correct power supply. 2. Turn on power to the unit. The evaporator (Enclosure or “COLD” air) impeller should come on. Is there airflow? YES, proceed to step 3.
8. Make sure the coils are clean. Then check evaporator “air in” and “air out” temperatures. If the temperatures are the same: » Possible loss of refrigerant Repair or Replace » Possible bad valves in the compressor defective part 9. To check for a bad thermostat, turn power to the unit off. Remove the upper access panel and place both thermostat wires onto one terminal (replace upper access panel for safety).
BASIC AIR CONDITIONING TROUBLE SHOOTING CHECK LIST - REMOTE ACCESS CONTROL VERSION 1. Check manufacturer’s nameplate located on the unit for correct power supply. 2. Turn on power to the unit. The controller will display a start up sequence then revert to the normal temperature display mode.
Page 35
7. The compressor and the condenser (Ambient or “HOT” air) impeller(s) should turn on. Is there adequate airflow? YES, proceed to step 8. NO, possible problem: » Open motor winding(s) » Stuck impeller(s) Repair or Replace » Obstructed wheel(s) defective part »...
SYMPTOMS AND POSSIBLE CAUSES - REMOTE ACCESS CONTROL VERSION SYMPTOM POSSIBLE CAUSE Clogged fins on coil(s) Dirty filter Impellers not running Unit won’t cool Compressor not running Compressor runs, but has bad valves Loss of refrigerant Low line voltage at start. Should be +/-10% rated voltage. Compressor motor stuck Compressor tries to start but won’t run Bad contactor...
WARRANTY Pentair Equipment Protection warrants that the Goods manufactured by Pentair Equipment Protection will be free from defects in material and workmanship for a period of one (1) year from the date of shipment by Pentair Equipment Protection, subject to the following conditions and exclusions: A.
A. An RMA # will be issued by our Product Return Department in Anoka, MN at 763-422-2211. Buyer should have following information available at time of RMA request: 1. Complete Model Number, Serial Number and description of damaged unit being returned. 2.
