THE TRANSCRIPTOR SKELETON UNIVERSAL TURNTABLE
THE TRANSCRIPTOR SKELETON UNIVERSAL TURNTABLE EMPLOYS A
LOW SPEED SYNCHRONOUS MOTOR ON A SPRING-SUSPENSION MOTOR
BOARD. THE PLATTER IS DRIVEN BY A RUBBER BELT PROVIDING THE
BEST INSULATION AGAINST VIBRATION AND RUMBLE. IN ORDER TO
ELIMINATE ANY MECHANICAL OR ELECTRICAL SHOCK TO THE
EQUIPMENT, THE ON-OFF SWITCHING IS ACCOMPLISHED BY MEANS OF A
MAGNETICALLY ACTUATED REED SWITCH WHICH ASSURES LONG
TROUBLE-FREE LIFE.
TRANSCRIPTOR SKELETON UNIVERSAL TURNTABLE:
Platter: 12" (305mm) Diameter, Cast and Machined.
Aluminum Alloy, with 5 silver-plated weights,
approximately 6.5 pounds.
Main Bearing: Slim section ball-ended ground and polished
Motor:
Power:
Wow & Flutter:
Speeds:
Rumble:
Dimensions:
SPECIFICATIONS
steel, supported on a hardened steel thrust
plate. Bushing coated with P.T.F.E.
(Polytetrafluoroethylene) A material having a
lower co-efficient of friction than any other
solid.
10 Pole Synchronous, Split-Phase, 720 R.P.M.
117 Volt A.C., 60 HZ .038 A
.05%
1
33 / and 45 r.p.m.
3
NIL
1
18" wide x 15 / " deep, x 7" high.
2
