Summary of Contents for Sinovision HDCRGB102
-
Page 1: User Manual
USER MANUAL HDMI To Component+VGA Converter HDCRGB102... - Page 2 A/V device use more convenient ,more comfortable, more productive and more cost-efficient. The HDCRGB102 Converter use a single HDMI source，accessing to single VGA+SPDIF sink or single YPbPr+SPDIF sink. The Converter allows one HDMI device to be converted easily to one VGA+SPIDF or one YPbPr+SPIDF monitor or projector.
- Page 3 The accessories with the machines lists as picture： 1、5V Power Adaptor 2、one pc of Manual Power Adaptor Physical Connection Showing Picture： Figure 1.0 Front Panel Showing Picture Power：Power Led Status Light VGA/ YPbPr：VGA、YPbPr Signal input switch button) Figure 1.1 rear panel showing picture DC 5V: 5V DC-DC Power Interface HDMI Input: HDMI input YPbPr：...
- Page 4 Connect one cable from HDMI1.2 sink into the Converter input. Connect VGA+SPDIF or YPbPr+SPDIF from monitor or projector into Converter outputs. Connect 5V power supply to the HDCRBG0102 Converter. SPECIFICATIONS: HDCRGB102 HDMI resolution ………………………….............. HDMI 1.2a Input Video signal ………….…………………………..…………………….… 0.5~1.5Volts p-p Input DDC signal ……………………………………………………………….. 5Volts p-p (TTL) VGA or YPbPr output………………………………….Support up to UXGA and 1080I(60Hz)
- Page 5 socket. 5. Pls turn the power off when the machines is not used for long time. 6. Pls do not open the cover and do not touch the inside parts. 7. Pls use the original factory power adptor.
