- Page 1 AMC T7a STEREO TUNER HOME Entertainment Center INSTRUCTIONS FOR INSTALLATION AND OPERATION...
- Page 2 MENOS QUE SE HAYAN INSERTASO COMPLETAMENTE LAS LENG ETAS PARA EVITAR SU NOTE: Some AMC products are equipped with dual or multi-voltage transformers (which is indicated on the back panel). If you wish to change the voltage, please bring your unit to an authorised AMC service technician for internal conversion. ATTENTION: Quelques pi ces AMC sont munies de transformateurs double ou multi-voltage (indiqu au panneau arri re).
- Page 3 * In case of weak stations where the background noise becomes annoying and spoils the listener's enjoyment of the program, there provides a MONO button on T7a to lock the tuner in themonomodetoobtainconsistently quieter and cleaner sound.
-
Page 4: Rear Panel
REAR PANEL CONNECTIONS/FRONT PANEL CONTROLS REAR PANEL 1. AC LINE CORD 4. OUTPUT JACKS 2. FM ANTENNA TERMINAL 5. DIGITAL OUTPUT "(OPTION)" 3. AM ANTENNA TERMINAL FRONT PANEL 10 11 1. POWER SWITCH AND POWER 6. AUTO INDICATOR 7. TUNING 2. -
Page 5: Rear Panel Connections
In view of the exceptional sensitivity of antenna's aiming and tuning controls can AMC tuner circuits, you may find the reject the interference and yield cleaner ribbon-wire dipole antenna is all you need reception. for receipt of strong local stations. But it is (4) An outdoor antenna. -
Page 6: Output Jacks
Use shielded leading cable rather than plain "twinlead" wire, both to 5. DIGITAL OUTPUTS (OPTION) minimize interference and to preserve This is an option model for T7a . If your strong signals during years of weathering. AMC T7a has incorporated with Digital... -
Page 7: Front Panel Controls
FRONT PANEL CONTROLS 1. POWER SWITCH other stations that you want to store in the The AMC T7a is turned on by pressing the remaining presets. Incidentally, if you make a power switch. The small indicator above the mistake or change your mind, it is not switch will glow green. - Page 8 10KHz on the AM band and 200KHz on the FM band. In Europe Notes: When your T7a is not installed with and elsewhere the tuning step is 9KHz on AM RDS module, you will not find these RDS and 50KHz on FM.
-
Page 9: Remote Control
TAPE RC-006 A wireless remote control is provided with your T7a enabling you to operate from the comfort of your chair. For reliable operation there should be a clear line-of-sight path from the remote control to the front of the tuner. -
Page 10: Specifications
SPECIFICATIONS FM TUNER SECTION Input Sensitivity MONO 30 dB THD+N........11.3 dBf (1.0 uV/75 ohm) MONO 50 dB S/N..........15 dBf (1.5 uV/75 ohm) STEREO 50 dB S/N..........37 dBf (20 uV/75 ohm) STEREO 60 dB S/N..........47 dBf (60 uV/75 ohm) Capture Ratio (45 and 65 dBf)................<1.5 dB AM Rejection (45 and 65 dBf).................>60 dB Selectivity ALTERNATE CHANNEL.................65 dB Image Rejection.......................80 dB... -
Page 11: Safety Instruction
15. SERVICING stores, or National Fire Protection Association (Batterymarch Park, Quincy. MA 02269). The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel. AMC 21-3004... - Page 12 AMC Web: http://www.amchome.com PN: 21-4133...
