HD Color Camera
CSDS60CM3
Instruction Manual
Thank you for purchasing our product.
Before using this HD Color Camera, please read through this Instruction
Manual carefully in order to use this product correctly and safely.
After reading, keep this instruction manual near the equipment so that you
can refer to, whenever you need it.
1． INTRODUCTION ·················································································· 1
2． FEATURES ···························································································· 1
3． COMPONENT ······················································································· 2
4． OPTIONAL PARTS··············································································· 2
5． EXPLANATION OF BACK ·································································· 3
6． CONNECTION ······················································································ 5
7． FUNCTION ···························································································· 6
8． BEFORE THINKING IT TO BE TROUBLE ········································ 8
9． SPECIFICATION··················································································· 9
10． APPEARANCE ···················································································· 14
TABLE OF CONTENTS
Printed On Recycled Paper．
D4168926B
Advertisement
Table of Contents
Related Manuals for Teli CSDS60CM3
Summary of Contents for Teli CSDS60CM3
-
Page 1: Table Of Contents
HD Color Camera CSDS60CM3 Instruction Manual Thank you for purchasing our product. Before using this HD Color Camera, please read through this Instruction Manual carefully in order to use this product correctly and safely. After reading, keep this instruction manual near the equipment so that you can refer to, whenever you need it. -
Page 2: Attention For Safety
ATTENTION FOR SAFETY ・This instruction manual contains important information for the operator (user) and/or people in the vicinity to avoid injuries or property damages. ・Prior to use, read this instruction manual after understanding the meaning of figure sign. ［ ［ ［ ［ Explanation of Indications］ ］ ］ ］ Indication Explanation This mark indicates the user that improper use may cause death or serious... - Page 3 ［ ［ ［ ［ Handling Precaution］ ］ ］ ］ WARNING ●Immediately cease use of the equipment in the event of abnormality or malfunction If abnormal conditions are present, such as smoke, a burning smell, ingress of water or foreign matter, or if the equipment is dropped or malfunctions, fire or electric shock may result.
- Page 4 ［ ［ ［ ［ Handling Precaution］ ］ ］ ］ CAUTION ●Observe the following when installing the equipment ・Do not cover the equipment with a cloth, etc. ・Do not place the equipment in a narrow location where heat is likely to accumulate. Otherwise, heat will accumulate inside the equipment, fire may result.
- Page 5 ［ ［ ［ ［ Guarantee］ ］ ］ ］ The period of guarantee is 12 months after the product delivery. If any trouble because of responsibility of our company occurred during the period, we repair it free of charge according to [Service]. But in the case of following, guarantee becomes inapplicable.
- Page 6 CASES FOR INDEMNITY ●In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions. ●In the case of indirect, additional, consequential damages (loss of business interests, suspension of business activities) are incurred as result of malfunction or non-function of the equipment, we shall be exempted from responsibility for such damages.
- Page 7 RESTRICTION FOR USE ●Should the equipment be used in the following conditions or environments, give consideration to safety measures and inform us of such usage: 1.：Use of the equipment in the conditions or environment contrary to those specified, or use outdoors.
- Page 8 Usage Precautions ●Handle carefully Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause malfunctions. Further, do not damage connected cables, since this may cause wire breakage. ●Environmental operating conditions Do not use the product in locations where the ambient temperature or humidity exceeds the specifications.
- Page 9 ●Maintenance Turn off power to the equipment and wipe it with a dry cloth. If it becomes severely contaminated, gently wipe the affected areas with a soft cloth dampened with diluted neutral detergent. Never use alcohol, benzene, thinner, or other chemicals because such chemicals may damage or discolor the paint and indications.
- Page 10 环保使用期限标识，是根据电子信息产品污染控制管理办法以及，电 子信息产品污染控制标识要求(SJ/T11364-2006)、电子信息产品环保 使用期限通则，制定的适用于中国境内销售的电子信息产品的标识。 电子信息产品只要按照安全及使用说明内容，正常使用情况下，从生 产月期算起，在此期限内，产品中含有的有毒有害物质不致发生外泄 或突变，不致对环境造成严重污染或对其人身、财产造成严重损害。 中华人民共和国 产品正常使用后，要废弃在环保使用年限内或者刚到年限的产品时， 环保使用期限 请根据国家标准采取适当的方法进行处置。 另外，此期限不同于质量/功能的保证期限。 The Mark and Information are applicable for People's Republic of China only. ＜产品中有毒有害物质或元素的名称及含量＞ 有毒有害物 有毒有害物质 质 质 质 或元素 有毒有害物 有毒有害物 或元素 或元素 或元素 部件名称 部件名称 部件名称 部件名称 六价铬 铬 铬 铬 六价...
-
Page 11: Introduction
1． ． ． ． INTRODUCTION This HD color camera is a unit type camera utilized 1/3 inch sensor. A picture output is DVI-D, so that you can get high-speed and high-resolution picture. Because this camera can connect a monitor directly, it is suitable for use of observation. 2．... -
Page 12: Component
3． ． ． ． COMPONENT (1) Camera body ································································· × 1 (2) Accessories ・Intentional Manual(Japanese) ····································· × 1 ・Intentional Manual(English) ····································· × 1 ※No application software attached to this camera. ※No DVI-D cable and Mini-USB cable for camera control attached to this camera. 4．... -
Page 13: Explanation Of Back
5． ． ． ． EXPLANATION OF BACK ① ② ③ ④ Rear panel ① DVI-D connector Picture output connector ・Connector model (Camera side) XM4M-2432-1312 (OMRON) ・Pin assignment Pin No. Function TX2- TX2+ TX2/4 Shield TX4-(N.C.) TX4+(N.C.) DDC Clock DDC Data 2 3 4 N.C. - Page 14 ② Camera control connector ・Connector model (Camera side) UX60SC-MB-5ST(80) (HIROSE ELECTRIC) ・Pin assignment Pin No. Function POWER USB D- USB D+ N.C. USB_GND ③ OPWB (One Push White Balance)switch This is a switch for OPWB. About the white balance, please confirm 7th clause. ④...
-
Page 15: Connection
6． ． ． ． CONNECTION Please connect this camera like chart below. (Please refer to our business charge for detail.) (1) In the picture output DVI-D cable Monitor Progressive CSDS60CM3 Power adapter (2) In the camera control DVI-D cable Monitor Mini-USB cable Progressive... -
Page 16: Function
7． ． ． ． FUNCTION Each following functions are possible to control by PC from though the camera control connector. (1) Output pixels It is possible to change two kinds of output pixels. (Factory setting：1280(H)×720(V)) ・1280(H)× 1024(V) (Aspect ratio 5：4) ・1280(H)×... - Page 17 (7) Electronic shutter There are 2 modes of MANU(manual) and AUTO. (Factory setting：AUTO) ・MANU mode It is possible to select the shutter speed with 9 phases. When you make the speed early, it is possible to take in a lot of light and easy to come to watch a gloomy subject.
-
Page 18: Before Thinking It To Be Trouble
8． ． ． ． BEFORE THINKING IT TO BE TROUBLE When a trouble occurred during use, please check the following points. If the trouble did not still dissolve, Please refer to store of the purchase or our business charge. Symptom Check matter ・Please confirm the connection of the DC cable. -
Page 19: Specification
9． ． ． ． SPECIFICATION ［ ［ ［ ［ Electronic Specification］ ］ ］ ］ (1) Image sensor 1/3 type CMOS sensor ・Total pixels 1384(H)×1076(V) ・Valid pixels 1329(H)×1049(V) ・Valid number of output pixels 1280(H)×1024(V) or 1280(H)×720(V) (Factory setting：1280(H)×720(V)) ・Pixel size 3.63µm(H)×3.63µm(V) ・Scanning area 1/3 type (2) Scanning system... - Page 20 (13) Mirror mode ・Horizontal turn ON/OFF change (Fatory setting：OFF) ・Vertical turn ON/OFF change (Fatory setting：OFF) (14) Electronic line ON/OFF change (Fatory setting：OFF) ・Number Vertical, Horizontal each 2 lines ・Type Fill/Translucent change ・Width 1 pixel/2 pixels change ・Color Changeable ・Setting range ：0～1279 1280(H) ×...
- Page 21 ［ ［ ［ ［ Internal sync specification］ ］ ］ ］ (1) Pixel clock rate 108.000MHz±100ppm (2) Scanning rate Video out Horizontal Vertical 1280(H)×1024(V) 63.981kHz 59.132Hz 1280(H)× 720(V) 45.918kHz 59.021Hz ［ ［ ［ ［ Electronic shutter specification］ ］ ］ ］ (1) Shutter system Rolling shutter (2) Shutter speed ON/OFF change (Fatory setting：AUTO)
- Page 22 ［ ［ ［ ［ Ambient condition］ ］ ］ ］ Temperature ： 0°C ～ 40°C (1) Performance assurance ： 10% ～ 90% (no condensation) Humidity Temperature ： 0°C ～ 40°C (2) Operation assurance ： 90% or less (no condensation) Humidity Temperature ： -20°C ～ 60°C (3) Storage assurance ：...
- Page 23 ［ ［ ［ ［ Spectral Sensitivity Characteristic］ ］ ］ ］ ※ The lens characteristics and light source characteristics is not reflected in table. ※ It includes an IR cut filter characteristic. Relative response curves Gb,Gr Wave length[nm] D4168926B...
-
Page 24: Appearance
10． ． ． ． APPEARANCE D4168926B... - Page 25 ＮＯＴＥ ＮＯＴＥ ＮＯＴＥ ＮＯＴＥ D4168926B...
- Page 26 ＮＯＴＥ ＮＯＴＥ ＮＯＴＥ ＮＯＴＥ D4168926B...
- Page 27 ＮＯＴＥ ＮＯＴＥ ＮＯＴＥ ＮＯＴＥ D4168926B...
- Page 28 (International Business Department) Phone : +81-42-589-8771 : +81-42-589-8774 : http://www.toshiba-teli.co.jp/ Distributor • This product must be classified for disposal according to the laws of each country and municipal laws. • Information contained in this document is subject to change without prior notice.
