Low-Boy Oil Furnace
NOTE: Read the entire instruction manual before starting the installation.
SAFETY CONSIDERATIONS.....................................................................................................................................................................................2
INTRODUCTION..........................................................................................................................................................................................................2
LOCATION ...................................................................................................................................................................................................................3
AIR FOR COMBUSTION AND VENTILATION ................................................................................................................................................3
DUCT WORK RECOMMENDATIONS ................................................................................................................................................................4
INSTALLATION...........................................................................................................................................................................................................4
VENTING INSTRUCTIONS ..................................................................................................................................................................................4
PRE-INSTALLATION VENT SYSTEM INSPECTION.......................................................................................................................................5
MASONRY CHIMNEY ..........................................................................................................................................................................................5
HORIZONTAL VENTING......................................................................................................................................................................................5
OIL BURNER ..........................................................................................................................................................................................................6
OIL CONNECTIONS ..............................................................................................................................................................................................6
BAROMETRIC DRAFT CONTROL......................................................................................................................................................................6
ELECTRICAL ..........................................................................................................................................................................................................6
FILTERS...................................................................................................................................................................................................................6
OPERATIONAL CHECKOUT.....................................................................................................................................................................................6
START-UP ...............................................................................................................................................................................................................6
RECOMMENDED INSTALLATION PRACTICES AND COMBUSTION CHECK .........................................................................................7
FAN ADJUSTMENT CHECK ................................................................................................................................................................................7
LIMIT CONTROL CHECK ....................................................................................................................................................................................7
FOR YEAR-ROUND AIR CONDITIONING ........................................................................................................................................................7
HEATING.................................................................................................................................................................................................................7
COOLING ................................................................................................................................................................................................................8
CONSTANT BLOWER SWITCH ..........................................................................................................................................................................8
CARE AND MAINTENANCE ....................................................................................................................................................................................8
GENERAL................................................................................................................................................................................................................8
OIL BURNER ..........................................................................................................................................................................................................8
HEAT EXCHANGER AND FLUE PIPE...............................................................................................................................................................9
BLOWER OILING AND REMOVAL .................................................................................................................................................................11
KEEPING FILTERS CLEAN................................................................................................................................................................................11
Form: IM-P08L-03
Installation Manual
TABLE OF CONTENTS
Cancels: NEW
Printed in U.S.A.
ama
7-00
PO8LAA
Catalog No. 63PO-8LI
Advertisement
Table of Contents
Related Manuals for GAMA PO8LAA
Summary of Contents for GAMA PO8LAA
-
Page 1: Table Of Contents
Installation Manual Low-Boy Oil Furnace PO8LAA NOTE: Read the entire instruction manual before starting the installation. TABLE OF CONTENTS SAFETY CONSIDERATIONS.....................................2 INTRODUCTION..........................................2 LOCATION ...........................................3 AIR FOR COMBUSTION AND VENTILATION ..............................3 DUCT WORK RECOMMENDATIONS ................................4 INSTALLATION...........................................4 VENTING INSTRUCTIONS ....................................4 PRE-INSTALLATION VENT SYSTEM INSPECTION............................5 MASONRY CHIMNEY ......................................5... -
Page 2: Safety Considerations
INTRODUCTION The model PO8LAA furnaces are available in sizes 105,000 Btuh through 155,000 Btuh input capacities. The furnace is shipped as a packaged unit, complete with burner and controls. It requires a line voltage (115 vac) connection to control box, a thermostat hook-up as shown on wiring diagram, oil line connection(s), adequate duct work, and connection to a properly sized vent. -
Page 3: Location
LOCATION WARNING: This furnace is not water tight and is not designed for outdoor installation. This furnace shall be installed in such a manner as to protect electrical components from water. Outdoor installation would lead to a hazardous electrical condition and to premature furnace failure. WARNING: Do not use this furnace as a construction heater. -
Page 4: Duct Work Recommendations
2. One sq. in. per 4000 Btuh of total input rating when air is brought in through vertical ducts. 3. One sq. in. per 2000 Btuh of total input rating when air is transferred through horizontal ducts. When ducts are used to supply air, they must be of the same cross-sectional area as free area of openings to which they connect. The minimum dimension of rectangular air ducts must not be less than 3 in. -
Page 5: Pre-Installation Vent System Inspection
OIL-FIRED APPLIANCES SHALL BE CONNECTED TO FLUES HAVING SUFFICIENT DRAFT AT ALL TIMES TO ENSURE SAFE AND PROPER OPERATION OF APPLIANCE. For additional venting information, refer to ANSI/NFPA 211 (Chimney, Fireplaces, Vents, and Solid Fuel Burning Appliances) and/or CSA B139 (Installation Code). -
Page 6: Oil Burner
PROCEDURE 5—OIL BURNER This furnace is supplied with a high-pressure atomizing retention head type burner (for use with not heavier than grade 2 fuel oil). The air tube length, from face of mounting plate to extreme face of end cone, should be as shown in Table 3. Table 3–Oil Burner Air Tube Length UNIT SIZE LENGTH (IN.) -
Page 7: Recommended Installation Practices And Combustion Check
PROCEDURE 2—RECOMMENDED INSTALLATION PRACTICES AND COMBUSTION CHECK In order to obtain optimum performance from oil burner, the following setup procedures must be followed: 1. A test kit (Bacharach No. 5022 kit or equivalent) to measure smoke, stack draft, over-fire CO , and stack temperatures MUST be used in order to obtain proper air band setting. -
Page 8: Cooling
60 Sec 90 Sec 120 Sec 150 Sec DELAY OFF DIP SWITCH SETTINGS A95115 Fig. 1–Fan Off Time DIP Switch Settings (Black Box Represents Switch Position) PROCEDURE 7—COOLING The blower speed may be field adjusted to deliver required airflow for cooling application (see Table 5). PROCEDURE 8—CONSTANT BLOWER SWITCH This furnace is equipped with a constant low-speed blower option. -
Page 9: Heat Exchanger And Flue Pipe
The procedure for nozzle installation and/or replacement is outlined in Oil Burner Instruction Manual which came with the furnace. For ease of maintenance the oiling procedure for burner motor, as outline in burner manual, should be performed at the same time. After replacement of nozzle, burner should be adjusted in accordance with Combustion Check section of the instruction. - Page 10 FLUE BOX PARTITION PANEL CLEANOUT CLEANOUT COVER PORT COVER GASKET CLEANOUT COVER CLAMP BRACKET WING CLAMP INSULATION A96311 Fig. 3–Reinstalling Cleanout Port Covers A96398 Fig. 4–Removing Combustion Chamber 7. Remove top partition. 8. Place field-fabricated cardboard on metal tray beneath collector box to prevent debris form entering blower compartment.. 9.
-
Page 11: Blower Oiling And Removal
24. Readjust burner for proper operation. Check limit operation as outlined in Operational Checkout, Procedure 4–Limit Control Check section. PROCEDURE 4—BLOWER OILING AND REMOVAL Periodic oiling of blower motor may be necessary. Check for instructions on inside of blower access panel. If it is ever necessary to remove blower from furnace: 1. - Page 12 CLEAN-OUT PORTS SUPPLY RETURN DUCT DUCT ″ ⁄ 3″ 1″ 1″ INSULATION PARTITION PANEL ELECTRICAL CONNECTIONS FILTER INSULATION INTERMEDIATE PANEL OIL INLET A96309 Dimensions (In.) UNIT SIZE UNIT DIMENSIONS DUCT SUPPLY FLUE RETURN OPENING DIAMETER DUCT Width Depth Height 036105 17-1/4 25-1/4 048125...
-
Page 13: Barometric Damper Locations
BAROMETRIC DAMPER LOCATIONS FIG. A FIG. B FIG. C FIG. D GOOD LOCATIONS WRONG FIG. G FIG. H WRONG WRONG FIG. K WRONG FIG. L FIG. J POOR WRONG BAD LOCATIONS A95117 Fig. 6–Barometric Damper Locations —13—... - Page 14 LEGEND BLACK ø FACTORY SET 115 VAC 1 60HZ POWER SUPPLY L1(H) L2(N) BLUE (FUSED DISCONNECT ON HOT LEG) PRINTED CIRCUIT HEATING SPEED BROWN BOARD WIRING GREEN 105-- MED (M) LINE V LOW SPEED HEAT CIRCULATION BLOWER FACTORY WIRING ORANGE CONNECTION 125-- MED (M) 24 V...
- Page 15 —15—...
- Page 16 impo8l03 —16— © 2000 CAC/BDP P.O. Box 70, Indianapolis, IN 46206 Catalog No. 63PO-8LI...
