Summary of Contents for iSys Minimod HD
- Page 1 MINIMOD HD Single DVB-T HDMI Modulator USER MANUAL...
-
Page 2: Table Of Contents
Congratulations on your purchase of the Minimod HD Single DVB-T HDMI Modulator This ‘state of the art’ product, is an encoder. The video and audio inputs are taken from an HDMI connection from the source device. The RF output is selectable and configured as a DVB-T modulator. -
Page 3: Safety Considerations
1 SAFETY CONSIDERATIONS 1.1 Connecting to the mains supply This product has to be connected to the mains supply. If there is the slightest doubt concerning the type of connection available on the installation, please contact your supplier of electricity. Before carrying out maintenance operation or modification of the installation, the modulator has to be disconnected. -
Page 4: Description Of The Different Elements
2 - Description of the different elements 2.1 Back of unit explained RF OUT: RF output RF IN: RF input loop through LTE: activates LTE filter USB: USB connectivity for upgrades/cloning HDMI: HDMI input DC: 12vDC input 2.2 Top of unit explained Lock Button Menu/OK: 1 x press menu, 2 x press OK Left: backward selection... -
Page 5: Operating Instructions
3. Operating Instructions You can connect your distribution system using either the HDMI or RF inputs: 3.1 Connecting to HDMI input You can connect your HDMI source device such as SKY receiver, BluRay player or Apple TV into the HDMI input of the modulator. 3.2 Connecting to RF Input You can connect Freeview digital terrestrial services into the RF input. -
Page 6: Setting Up Constellation, Fec, Guard Interval, Rf Level
6.2 Setup Constellation, FEC, FFT, Guard Interval, RF Level, Audio Bit Rate, Audio Format set up.. Press ‘Menu/OK’ button and then use the buttons to select the desired function. buttons to select the correct value. When your selections are complete, press ‘Menu/OK’ twice to save the setting 6.3 Channel ‘NAME’... -
Page 7: Saving Configuration To Usb
‘Menu/OK’ button The upgrade procedure will finish after approximately 10 seconds. CAUTION DO NOT turn the Minimod HD OFF while undergoing the firmware update procedure as this may seriously damage the device. 7. DECLARATION OF CONFORMITY We, Antiference LIMITED herewith declare that the modulator Minimod HD complies with all... -
Page 8: Specifications
8.0 Specifications 8.1 Encoder Processor Processor Frequency Host CPU: 200MHz 32Bit RISC Security Processor: 200MHz 32Bit Audio Processor: 200MHz 32Bit Memory DDRII 16Bit 512Mbit x 1 Embedded Flash NOR Flash 32Bit x 1 Video Video Encoder ISO/IEC 11172-2 MPEG ISO/IEC 13818-2 MPEG2 MP@HL ISO/IEC 14496 MPEG4 compliant Support SP@L3 to ASP@L5 ISO/IEC 14496-10 AVC,... -
Page 9: Modulation Specifications
8.0 Specifications 8.2 Modulation Audio Audio Encoder MPEGI layer1/2, MPEGII Layer II AAC LC, HE-AAC v1/V2 (2- CH) Output Frequency 174~233MHZ(VHF III), Range 470 - 858 [MHz](UHF) Output Impedance 50[W] Input Impedance 50[W] (loop to output) Forward Error 1/2,2/3,3/4, 5/6, 7/8 Correction Guard Interval 1/4,1/8,1/16,1/32... -
Page 10: Rear Panel Specifications
8.0 Specifications 8.3 Rear Panel RF Input Impedance:50 [W] (Loop to Output) Input type: F-type female RF Output Impedance:50 [W] Output type: F-type female USB Connector Number: 1 (software upgrade) ON/OFF (Long Term Evolution Cut Off Frequency: 790MHZ Filtering switch HDMI Input Number: 1, High Definition Media Interface HDMI... -
Page 11: Power And Size Specifications
8.0 Specifications 8.5 Power and size Power Power Supply Unit Adapter Input: 100-240V AC Output: DC 12V/2.0A Power Consumption <10W Size Overall Dimensions (W)164mm x (D)104mm x (H) 41mm Construction Casework Metal cabinet with ventilation holes Printed Circuit Board 2 layer PCB structure... - Page 12 www.antiference.co.uk...
