Hyundai H-CSP124 Instruction Manual

12´ subwoofer for sealed type box (closed)

H-CSP124

12 SUBWOOFER FOR SEALED TYPE BOX (CLOSED)

Instruction manual

12 (30 c )

Table of Contents

Need help?

Do you have a question about the H-CSP124 and is the answer not in the manual?

Page 1 H-CSP124 12 SUBWOOFER FOR SEALED TYPE BOX (CLOSED) Instruction manual 12 (30 c )
Page 2: Important Safeguards
Description The set of subwoofer includes: subwoofer Important safeguards The owner s manual contains important operating and maintenance instructions for your safety. It is necessary to refer the manual. Do not install the subwoofer where it may be subjected to excessive heat moisture, dust or where it will be kicked repeatedly, brushed or bumped. Make absolutely sure that the terminals for the subwoofer are connected to the proper outputs from the music source.
Page 3: Mounting The Subwoofer
Mounting the subwoofer Installation kits are available from your dealer or local stereo shop to help make your installation easy. These kits also give your installation a clean, custom appearance. Questions about installations methods please consult a professional auto sound dealer/installer for assistance. This subwoofer is intended for the sealed type box (closed).
Page 4 Specification Loudspeaker one woofer: 30 cm (12 ) carbon kevlar cone Magnet 100 Oz magnet Peak output power 1000 W Rated output power 500 W Impedance 2x4 hm Sensitivity 90 dB Frequency response 25-3000 Hz Diameter of voice coil 65 mm 28.97 Hz 2 Ohm 4.539...
Page 6 . .).
Page 7 : 30 (12 ) 1000 25-3000 28.97 4.539 0.566 0.503 57.615 Xmax 31.117 312 x 248 355 355 235...
