  • Page 1 Digital voice recorders of EM CARD 16 Operation manual...

  • Page 2: Table Of Contents

    CONTENTS ..................4 1. Purpose ................4 2. Main Features ..................4 3. Overlook .............5 4. Technical Characteristics ..............6 5. Recording Duration ..............6 6. Recorder's Battery Life ..............7 7. Operating the Recorder ................8 8. Readiness Test ................8 9. Record Playback ..........8 10. Use of Timers and Voice Activation...
  • Page 3 .............9 11. Configuring Voice Activation ............9 12. Setting Circular Recording ............10 13. Setting File Size Restrictions ............10 14. Setting Time and Date ....... 11 15. Changing Settings using Configuration File ..............11 16. Battery Charging ..............12 17. Card Formatting ..............12 18.

  • Page 4: Purpose

    1. Purpose The recorders of the EM-Card series are professional devices intended for making high quality record of voice messages onto microSD memory card in wav format. The format is supported by all flash players on the PC and any other playback devices. 2.

  • Page 5: Technical Characteristics

    LED indicator is used for indication, its color being green, orange or red. Green color indicates, the operation has been successfully completed; and the red one indicates, an error has occurred. The Recorder has a Switch, its position being either ON or OFF. When the Switch is in OFF position, all the functions of the Recorder are off.

  • Page 6: Recording Duration

    5. Recording Duration Recording time depending on the recording format and memory card capacity, without taking into account resource batteries. 2 Gb 4 Gb 8 Gb 16 Gb 32 Gb 8 bit, 16kHz 136h 272h 544h 1088h 8 bit, 8kHz 136h 272h 544h...

  • Page 7: Operating The Recorder

    7. Operating the Recorder Recording The Recorder switches to operation mode after the Switch has been shifted from OFF to ON. After it has switched to record mode, green LED of the Recorder makes two series of flashes. During recording, the series of flashes are repeated at regular intervals; the second series follows the first one in 4s, then comes the first in 8s again.

  • Page 8: Readiness Test

    Before removing battery or microSD card, shift the toggle switch to OFF position and wait till green LED flashes once, which means recording has stopped and the Recorder quitted record mode. Failure to do so can lead to abnormal termination of recording and loss of all the data on the memory card.

  • Page 9: Configuring Voice Activation

    10.2 If in the Recorder settings, voice activation is active and all the timers are off, after the Recorder switches to operation mode, it starts sound level testing. As soon as the sound level is beyond the one specified in the settings, recording starts. It lasts for the time specified in the mode settings.

  • Page 10: Setting File Size Restrictions

    size specified. At each deleting old files, the Recorder frees space in the amount at least to record one file of the maximum size specified. If the restrictions of maximum and minimum file size are off, while circular recording, the size of the file being recorded equals 100 Mb.

  • Page 11: Changing Settings Using Configuration File

    15. Changing Settings using Configuration File All the Recorder's settings are made using the CONFIG.INI configuration file. This is a text configuration file, which the Recorder can automatically save in the memory card. Any word processor on your PC can be used to open the CONFIG.INI file, make changes to it and save it and then, having inserted memory card into the Recorder, you can start processing the configuration file, and the settings specified in the file will be saved by the Recorder.

  • Page 12: Card Formatting

    Recorder makes red flashes, as described in Section 7. 18. Technical Support Technical support is available by e-mail: support@ts-market.com We are constantly working to improve the software and documentation. You can always download the latest version of the software for free and get information on products on our website:...
