Summary of Contents for ROBAND CEADO ES300
- Page 1 CEADO JUICE EXTRACTOR INSTRUCTION AND MAINTENANCE MANUAL ES700 ES500 ES300 Distrubuted in Australia by Roband Australia Pty Ltd...
-
Page 2: Juice Extractor
JUICE EXTRACTOR This is a commercial juice extractor for the preparation of fruit and vegetable juices with automatic pulp ejection. Like all appliances, it should be used with particular care to avoid injury to personnel and damage to the appliance. It is essential to read these instructions carefully before using the appliance and to follow the safety recommendations. - Page 3 JUICE EXTRACTOR Main parts (Fig. 1 - Fig. 2) Motor housing Basket Bowl Pulp retainer* Spout Grating disc Juicer cover Start button Locking arm ON-OFF (I-O) button Food pusher Motor shaft Feed chute Drive disc Pulp container * Not standard equipment on all models Fig.
- Page 4 Model ES300 with feed chute ø 50 mm Model ES700 with double feed chute ø 50 - ø 75 mm ø 50 mm Fig. 3 Model ES500 with feed chute ø 75 Model ES500S with feed chute ø 50 mm ø...
- Page 5 Always work under safe conditions: do not use the appliance with wet hands or feet. Do not use outdoors. Keep the original package for possible future use. It is the most suitable protection against damage during transport. In case of fire use CO 2 extinguishers. Do not use water or powder extinguishers. Never place the appliance in water! Do not clean with the use of a Water Jet.
-
Page 6: Installation
INSTALLATION Comply with the safety recommendations indicated above and hereafter when installing the appliance . Make sure that the mains voltage is as indicated on the rating label of the appliance and that the electrical system is grounded and equipped with a switch. Install the appliance in a DRY, PROTECTED place, far from water sprays or splashes, heat sources, open flames and inflammable substances. - Page 7 Place a container under the spout of the bowl. Turn the appliance on by pushing the ON-OFF button in the “ON” position. Turn on the motor by pushing the start button. With the motor in action put fruit and/or vegetables in the feed chute. Use the food pusher to gradually push down the fruit and/or vegetables towards the spinning grating disc at the bottom of the feed chute without exerting excessive pressure (see Fig.
-
Page 8: Cleaning And Maintenance
Fig. 6 CLEANING AND MAINTENANCE Suggestions: to reduce the cleaning procedures to a minimum we suggest placing a biodegradable plastic bag inside the pulp container, folding the top of the bag over the edge of the pulp container (see Fig. 5). By using this method, once you have finished using the appliance, you can put the waste directly in a composting or waste bin. - Page 9 To disassemble these components, unhook the locking arm and remove in this order; food pusher, juicer cover, basket, pulp retainer*, and bowl (Fig. 8). Reassemble in the reverse order taking care to place the juice spout in the appropriate slot of the motor housing, place the pulp retainer in its correct place with the internal edge facing up (Fig.
-
Page 10: Preparation Of Fruit And Vegetables
For a periodic deep-cleaning you can disassemble the parts of the basket by unscrewing the nut under the basket (Fig. 9). To disassemble the parts of the basket, hold the basket still with one hand and unscrew the nut with a pipe wrench number 13 (Fig. 9). Pull the screw out of the basket. Wash all of the parts in warm water with dish soap, removing any residues with the brush provided. - Page 11 Screw Grating disc Internal edge turned Base Outer edge turned down Clutch disc Washer Fig. 9 Fig. 8 * Not standard equipment on all models.
-
Page 12: Troubleshooting
RECOMMENDATIONS FOR PROPER USE When you make juice from different types of ingredients with different consistencies it is a good idea to start with the softer ingredients and then subsequently use the harder ingredients. When you make juice from herbs or lettuce you should press them together to form compact balls, or mix them together with other ingredients to obtain a better result. - Page 13 Solution Problem Make sure the feed chute is empty. • Make sure it is plugged in. • Make sure the safety circuit breaker is closed. • Make sure the locking arm is correctly hooked onto the • juicer cover. The appliance does not turn Make sure the start button on the appliance is turned ON.
-
Page 14: Warranty
DISPOSAL Correct disposal of this product (waste electrical and electronic equipment) (Applicable in the European Union and other countries with separate collection systems) This product has been made from high-quality parts and materials, which can be re-used and recycled. Therefore, do not throw the product away with normal household waste at the end of its working life. - Page 15 Cod. 80412...
