Introduction ······································································································ - 3 -
Section one Product Overview ·········································································· - 4 -
1.1 Product Features ······························································································ - 4 -
1.2 Specification ···································································································· - 4 -
Section Two Hardware Installation ···································································· - 6 -
2.1 Panel layout ····································································································· - 6 -
2.1.1 Front panel ············································································································· - 6 -
2.1.2 Rear panel ············································································································· - 7 -
2.2 System Requirements ························································································ - 7 -
2.3 Installation Environment ···················································································· - 7 -
2.4 Hardware Installation Steps ················································································ - 7 -
Section Three Quick Installation Guide ······························································· - 8 -
3.1 TCP/IP configuration ·························································································· - 8 -
3.2 Quick Setup wizard ·························································································· - 10 -
3.3 Operation mode ······························································································· - 16 -
Section four Configuration Guide ····································································· - 17 -
4.1 Login·············································································································· - 17 -
4.2 Wireless Setting ······························································································· - 17 -
4.2.1 Wireless Status ······································································································ - 18 -
4.2.2 Wireless Basic settings ···························································································· - 18 -
4.2.3 Repeater settings ··································································································· - 19 -
4.2.4 Virtual AP settings··································································································· - 20 -
4.2.5 WDS Settings ········································································································ - 20 -
4.2.6 Advanced Settings ·································································································· - 21 -
4.2.7 Access Control ······································································································· - 21 -
4.2.8 WPS Settings ········································································································ - 22 -
4.3 TCP/IP Setting ································································································· - 23 -
4.3.1 LAN Status ············································································································ - 23 -
Contents
Advertisement
Table of Contents
Related Manuals for Evolve WR153ND
Summary of Contents for Evolve WR153ND
-
Page 1: Table Of Contents
Contents Introduction ······································································································ - 3 - Section one Product Overview ·········································································· - 4 - 1.1 Product Features ······························································································ - 4 - 1.2 Specification ···································································································· - 4 - Section Two Hardware Installation ···································································· - 6 - 2.1 Panel layout ····································································································· - 6 - 2.1.1 Front panel ·············································································································... - Page 2 4.3.4 WAN Interface Setup ······························································································· - 25 - 4.4 Firewall ··········································································································· - 25 - 4.4.1 IP/Port Filtering ······································································································ - 25 - 4.4.2 MAC Filtering ········································································································· - 26 - 4.4.3 Port Forwarding ····································································································· - 27 - 4.4.4 URL Filtering ········································································································· - 28 - 4.4.5 DMZ ····················································································································...
-
Page 3: Introduction
WR153ND Router is a hybrid design product which combines Ethernet technology and wireless access into a single stand-alone unit. The device allows you to take advantages of both mobility and fast connection. All PCs whenever on wireless LAN or Ethernet LAN can share files, printers and other network resources. -
Page 4: Section One Product Overview
1.1 Product Features Complies with IEEE 802.11n, 802.11g, 802.11b standard for 2.4GHz Wireless LAN 1 10/100M WAN RJ45 port, 4 10/100M LAN RJ45 ports Supports Auto MDI/MDIX Supports Wireless Roaming, can move among different AP and no break ... - Page 5 1-11 (North America) Channels 1-13 (General Europe) 1-14 (Japan) BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) Transmission Technology 1*2.4GHz Dipole Antenna（1TX*1RX） Antenna Type Standard Access Point; Wireless WAN mode (Client Mode Wireless), Operation Mode WDS，WPS SSID Enable/Disable; MAC Address, IP and URL Filter；64/128/152-bit WEP Encryption Wireless Security WPA/WPA2/WPA-PSK/WPA2-PSK (AES/TKIP) Encryption...
-
Page 6: Section Two Hardware Installation
2.1 Panel layout 2.1.1 Front panel The front panel of the 11N Wireless Router consists of several LED indicators, which is designed to indicate connections. LED indicators: Led Name Action Description no power Power power on the router has a hardware error flashing the router is working properly wireless function is disabled... -
Page 7: Rear Panel
2.1.2 Rear panel 2.2 System Requirements Broadband Internet Access Service (DSL/Cable/Ethernet) One DSL/Cable modem that has an RJ45 connector (you do not need it if you connect the router to Ethernet) Each PC on the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45 connectors ... -
Page 8: Section Three Quick Installation Guide
After connecting the 11N Wireless Router into your network, you should configure it. This chapter describes how to configure the basic functions of your 11N Wireless Router. These procedures only take you a few minutes. You can access the Internet via the router immediately after successfully configured. - Page 9 1. Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC(s) 2. Power off the router and PC(s). Then turn on the router, and restart the PC(s). The built-in DHCP server will assign IP addresses for the PC(s). Now, you can run the Ping command in the command prompt to verify the network connection...
-
Page 10: Quick Setup Wizard
3.2 Quick Setup wizard With a Web-based (Internet Explorer or Netscape® Navigator) utility, the 11N 150bps Wireless Router is easy to configure and manage. The Web-based utility can be used on any Windows, Macintosh or UNIX OS with a web browser. Connect to the router by typing http://192.168.0.1 in the address field of web browser. - Page 11 The router supports three modes: gateway, bridge, wireless ISP. You can setup different modes to LAN and WLAN interface for NAT and bridging function. Click next, Time Zone Setting will appear. You can select the time zone what you need.
- Page 12 Click next, LAN Interface setup will appear. In this page, you can set IP address, Subnet Mask. IP Address - Enter the IP address of your router in dotted-decimal notation (factory default: 192.168.0.1). Subnet Mask - An address code that determines the size of the network. Normally use 255.255.255.0 as the subnet mask.
- Page 13 User Name and Password - Enter the User Name and Password provided by your ISP. If you choose " DHCP", the router will automatically receive the IP parameters from your ISP without needing to enter any parameters. If you Choose "PPTP", the Static IP settings page will appear, shown in the figure.
- Page 14 You can get IP Address Subnet Mask, server IP Address, User Name and Password from your ISP you Choose "Static IP", the Static IP settings page will appear, shown in figure. The IP parameters should have been provided by your ISP. IP Address - This is the WAN IP address as seen by external users on the Internet (including your ISP).
- Page 15 Mode- Default is AP, you can select Infrastructure Client or AP SSID - Enter a value of up to 32 characters. The default SSID is Noganet, but it is recommended strongly that you change your networks name (SSID) to a different value. Channel –This field determines which operating frequency will be used.
-
Page 16: Operation Mode
3.3 Operation mode Gateway：(default) In this mode, the device is supposed to connect to internet via ADSL/Cable Modem. The NAT is enabled and PCs in LAN ports share the same IP to ISP through WAN port. The connection type can be setup in WAN page by using PPPOE, DHCP client, PPTP client or static IP. Bridge: In this mode, all ethernet ports and wireless interface are bridged together and NAT function is disabled. -
Page 17: Section Four Configuration Guide
4.1 Login After you login successful, Browser will show administrator WEB. on the left is contents. it contains: Wireless setting, WAN Settings, LAN Settings, Network Security, System Services, Management, Status Show ect.. 4.2 Wireless Setting It contains Wireless Basic settings, Repeater settings, Virtual AP settings, WDS Settings, Advanced Settings, Access Control and WPS... -
Page 18: Wireless Status
4.2.1 Wireless Status This page shows the current status and some basic settings of the device. you can check system Information, Repeater Interface Information, WLAN Interface Information. 4.2.2 Wireless Basic settings This page is used to configure the parameters for wireless LAN clients which may connect to your Access Point. -
Page 19: Repeater Settings
WEP (Wired Equivalent Privacy), a basic encryption method, usually encrypts wireless data using a series of digital keys (64 bits or 128 bits in length). By using the same keys on each of your wireless network devices, you can prevent unauthorized wireless devices from monitoring your transmissions or using your wireless resources. -
Page 20: Virtual Ap Settings
4.2.4 Virtual AP settings This page shows and updates the wireless setting for multiple Aps 4.2.5 WDS Settings Wireless Distribution System uses wireless media to communicate with other APs, like the Ethernet does. To do this, you must set these APs in the same channel and set MAC address of other APs which you want to communicate with in the table and then enable the WDS. -
Page 21: Advanced Settings
4.2.6 Advanced Settings These settings are only for more technically advanced users who have a sufficient knowledge about wireless LAN. These settings should not be changed unless you know what effect the changes will have on your Access Point. 4.2.7 Access Control If you choose 'Allow Listed', only those clients whose wireless MAC addresses are in the access control list will be able to connect to your Access Point. -
Page 22: Wps Settings
4.2.8 WPS Settings WPS (Wi-Fi Protected Setting) can easily and quickly establish the connection between the wireless network clients and the device through an encrypted way. The users only enter PIN code or press RST/WPS button on the panel to configure it. In the “Wireless settings” menu, click “WPS settings” to enter the next screen. -
Page 23: Tcp/Ip Setting
4.3 TCP/IP Setting 4.3.1 LAN Status This page shows the current status and some basic settings of the device. you can check system Information, LAN Interface Information MAC Address - the physical address of the router, as seen from the LAN. The value can't be changed. -
Page 24: Wan Status
4.3.2 WAN Status This page shows the current status and some basic settings of the device. you can check system Information, WAN Interface Information. MAC Address - the physical address of the router, as seen from the LAN. The value can't be changed. IP Address - Enter the IP address of your router in dotted-decimal notation (factory default: 192.168.0.1). -
Page 25: Wan Interface Setup
4.3.4 WAN Interface Setup This page is used to configure the parameters for Internet network which connects to the WAN port of your Access Point. Here you can select the access method to static IP, DHCP, PPPoE or PPTP by click the item value of WAN Access type. -
Page 26: Mac Filtering
Internet through the Gateway. Use of such filters can be helpful in securing or restricting your local network. IP/Port filtering: If you choose 'White list', only those clients whose IP addresses are in the list will be able to connect to your Access Point. When 'Blacklist' is selected, these IP Addresses on the list will not be able to connect the Access Point. -
Page 27: Port Forwarding
4.4.3 Port Forwarding Entries in this table allow you to automatically redirect common network services to a specific machine behind the NAT firewall. These settings are only necessary if you wish to host some sort of server like a web server or mail server on the private local network behind your Gateway's NAT firewall. -
Page 28: Url Filtering
4.4.4 URL Filtering URL filter is used to deny LAN users from accessing the internet. Block those URLs which contain keywords listed below. URL Filtering : If you choose 'White list', only those URL Addresses are in the list will be able to connect to your Access Point. -
Page 29: Management
DMZ Host IP Address: input IP Address. for example 192.168.1.34. Click apply changes, complete set DMZ. 4.5 Management 4.5.1 QOS Note: If you add any QoS rules, the DoS function will have no effect. This page is used to help users configure the parameters of QoS. The Maximum Bandwidth provided by ISP----Indicate the network max bandwidth for up and down data stream Direction----Direction of data stream, Up stream means data go out the LAN, Downstream means go... -
Page 30: Ddns Setting
4.5.2 DDNS Setting Dynamic DNS is a service, that provides you with a valid, unchanging, internet domain name (an URL) to go with that (possibly ever changing) IP-address. DDNS. lets you assign a fixed host and domain name to a dynamic Internet IP Address. It is useful when you are hosting your own website, FTP server, or other server behind the router. -
Page 31: Time Zone Setting
4.5.3 Time Zone Setting You can maintain the system time by synchronizing with a public time server over the Internet. Current time: type the date and time. Time Zone Select: Select your local time zone from this pull down list. Enable NTP client update: select it, you can get the time from NTP. -
Page 32: Log
A "denial-of-service" (DoS) attack is characterized by an explicit attempt by hackers to prevent legitimate users of a service from using that service. Enable DoS Prevention: select it, you can modify DOS Prevention. Enable Source IP Blocking: you can input source IP Blocking time Click apply changes, DoS take effect. -
Page 33: Save/Reload Settings
4.5.7 Save/Reload settings This page allows you save current settings to a file or reload the settings from the file which was saved previously. Besides, you could reset the current configuration to factory default. 4.5.8 Password setup This page is used to set the account to access the web server of Access Point.
