Summary of Contents for Sager 6630

  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 15: Table Of Contents

    Preface Contents Notice .................I System Map: Left View ..........1-11 FCC Statement .............II System Map: Right View ..........1-12 Instructions for Care and Operation ......IV System Map: Bottom View ..........1-13 Power Safety .............. VI Windows XP Start Menu & Control Panel ....1-14 Battery Precautions ...........VII Video Features .............1-15 Cleaning ..............
  • Page 16 Preface Audio Features .............2-13 Battery FAQ ..............3-12 8 Channel Sound Support .........2-14 Drivers & Utilities Adding a Printer ............2-15 USB Printer ..............2-15 What to Install ..............4-1 Parallel Printer ............2-15 Module Driver Installation ..........4-1 Service Packs ...............4-3 Power Management Authorized Driver Message .........4-4 Overview ................3-1 Version Conflict Message ...........4-4 Advanced Configuration and Power Interface ....3-1...
  • Page 17 Preface Bluetooth ..............4-10 Upgrading The Computer Port Replicator ............4-10 Overview ................6-1 When Not to Upgrade ..........6-2 BIOS Utilities Removing the Battery ............6-3 Overview ................5-1 Upgrading the Hard Disk Drive ........6-4 The Setup Utility ............5-2 Upgrading the Optical (CD/DVD) Device ....6-6 Entering Setup ............5-2 Upgrading the System Memory (RAM) ......6-7 Setup Screens ..............5-2...
  • Page 18 Preface Troubleshooting RJ-45 LAN Jack ............A-3 Security Lock Slot ............A-3 Overview ................8-1 Serial Port ..............A-3 Basic Hints and Tips ............8-2 S/PDIF-Out Jack ............A-4 Backup and General Maintenance .........8-3 7-Pin S-Video-Out Jack ..........A-4 Viruses ................8-4 USB 2.0/1.1 Ports ............A-4 Upgrading and Adding New Hardware/Software ..8-5 Optional Port Replicator Ports and Jacks .....A-5 Power ................8-7 DC-In Jack ..............A-5...
  • Page 19 Preface Specifications Processor ............... C-2 Core Logic ..............C-2 Memory ................. C-2 Security ................. C-2 BIOS ................C-2 LCD ................C-2 Video Adapter ............... C-3 Storage ................C-3 Audio ................C-3 Keyboard & Pointing Device ........C-3 Interface ................ C-4 Card Reader ..............
  • Page 20 Preface XVIII...

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Model & Design Differences

    Quick Start Guide Model & Design Differences This notebook series includes two different model types (Model A or Model B) based upon their specification details (see Table 1 - 1 below). The series also includes three different designs which vary slightly in color and appearance.

  • Page 23: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 24: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows XP) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals. System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the Microsoft Win- dows XP (Home &...

  • Page 25: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter (Note: If you have included the Port Replicator in your purchase option see...

  • Page 26: System Map: Top View With Lcd Panel Open

    Quick Start Guide System Map: Top View with LCD Panel Open Optional Built-In PC Camera Speakers Wireless Device Power Button Operation Aboard Hot Key Buttons Aircraft Keyboard The use of any portable TouchPad and Buttons electronic transmission de- Built-In Microphone vices aboard aircraft is usu- LED Indicators ally prohibited.

  • Page 27: Led Indicators

    Quick Start Guide LED Indicators The LED indicators display helpful information about the current status of the computer. Table 1 - 2 - LED Indicators Icon Color Description Green Number Lock Activated Green Caps Lock Activated Green Scroll Lock Activated Green The Computer is On Blinking Green...

  • Page 28: Hot Key Buttons & Keyboard

    Quick Start Guide Hot Key Buttons & Keyboard The keyboard has a numerical keypad for easy numer- ic data input, and features function keys to allow you These buttons give instant access to the functions indi- to change operational features instantly (see Figure 1 cated in the table below.
  • Page 29 Quick Start Guide Function Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down (see “Func- tion Keys” on page 2 - Function Function Fn + Esc Help & System Info Fn + F8 Decrease LCD Brightness Fn + F1...

  • Page 30: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views LED Indicators Serial Port Mini-IEEE 1394 Port 1 * USB Port DC-In Jack Battery Figure 1 - 4 - Front & Rear Views Mini-IEEE 1394 The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. 1 - 10 System Map: Front &...

  • Page 31: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 5 - Left View Security Lock Slot Optical Device Drive Bay (see page RJ-11 Modem Jack S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack Changing DVD Regional Codes Line-In Jack Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives.

  • Page 32: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 6 - Right View ExpressCard Slot (see page 7-in-1 Card Reader 2 * USB 2.0 Ports Vent/Fan Intake RJ-45 LAN Jack 7-Pin S-Video-Out 7-Pin S-Video-Out Jack Jack The 7-pin S-Video Out Jack requires an adapter cable (7-pin S-Video plug to 4-pin S-Video External Monitor Port jack adapter) in order to connect to a standard S-Video cable.

  • Page 33: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Vent/Fan Intake Battery Hard Disk Bay Cover The CPU is not a user ser- CPU/RAM Bay Cover viceable part. Opening this compartment, or accessing the CPU in any way, may vi- olate your warranty.

  • Page 34: Windows Xp Start Menu & Control Panel

    Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 35: Video Features

    Quick Start Guide Video Features Your computer has built-in Intel (Intel 945GM) video. You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is in- stalled. For more detailed video information see “Intel Video Driver Controls”...

  • Page 36: Display & Graphics Properties

    Quick Start Guide Display & Graphics Properties Figure 1 - 9 - Display & Graphics Properties Power Settings Power Settings in Display Settings can affect display brightness, contrast etc. (see “Power Settings” on page B - 12). 1 - 16 Video Features...

  • Page 37: Display Devices & Options

    Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the external monitor port, a TV to the 7-pin S-Video-Out jack.

  • Page 38: Power Management Features

    Quick Start Guide Power Management Features The Power Options control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Stand by or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel tab).

  • Page 39: Features & Components

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 7-in-1 Card Reader • ExpressCard Slot •...

  • Page 40: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives (see “Storage” on page C - 3) with a height of 9.5 mm.

  • Page 41: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 42: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.

  • Page 43: Dvd Regional Codes

    Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 44: 7-In-1 Card Reader

    Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 45: Expresscard Slot

    Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g. cover in the Express- CompactFlash card reader.

  • Page 46: Function Keys

    Features & Components Function Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn Application Note key is held down. In addition to the basic function key combinations; visual indica- tors are available when the hot key driver is installed (see “Hot Key”...
  • Page 47 Features & Components Fn/Hot Key Function Fn + Esc Help & System Info Figure 2 - 6 on page 2 - 8 Hot Key Note Fn + F1 TouchPad Toggle The Help menu will dis- play the function key features, current Battery Fn + F3 Mute Toggle Life, Power State and...

  • Page 48: Recording Audio

    Features & Components Recording Audio audio record hot key button allows you to record audio from either the built- in microphone, or from a microphone connected to the microphone-in jack. To record on the computer, setup the audio recording options in Windows as follows (see Figure 2 - 7 on page 2 - 11).
  • Page 49 Features & Components Figure 2 - 7 Audio Setup for Recording (Windows XP) Function Keys 2 - 11...

  • Page 50: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an exter- nal mouse your operat- ing system may be able...

  • Page 51: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel, or from the Realtek HD Audio Manager Adjustment icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus).

  • Page 52: Channel Sound Support

    Features & Components 8 Channel Sound Support If you wish to configure your system for 8 channel sound support, then the following ports should be used as outputs. Connect the system cables to the following audio 8 Channel Sound jacks: Support Double-click the Realtek •...

  • Page 53: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- USB Printer...
  • Page 54 Features & Components 2 - 16...

  • Page 55: Power Management

    Power Management Chapter 3: Power Management OS Note Overview Power management To conserve power, especially when using the battery, your computer uses the ACPI functions will vary power management system. Power management conserves power by controlling in- slightly depending on dividual components of the computer (the monitor and hard disk drive) or the whole your operating system.

  • Page 56: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Port Replicator AC/DC Adapter AC/DC Adapter You will be provided Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ with AC/DC DC adapter will damage the computer and its components.

  • Page 57: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shutdown er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Stand by/Hibernate/ ways shut your comput- er down by choosing the Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and...

  • Page 58: Power Schemes

    Power Management Power Schemes You can set your computer to conserve power through individual components by Resuming means of Power Schemes. You can also adjust the settings for each scheme to set Operation the monitor to turn off after a specified time, and the computer's hard disk motor to turn off if the hard disk drive has not been accessed for a specified period of time (if Press Sleep/Re-...
  • Page 59 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experienc- ing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the com- puter is powered from an AC power source.

  • Page 60: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart Stand by/Hibernate where you left off. This system features Stand by and Hibernate sleep mode levels or Shutdown Error (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - see “Hibernate”...

  • Page 61: Stand By

    Power Management Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed.

  • Page 62: Configuring The Power Button

    Power Management Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hiber- Sleep Button nate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter). If you are in a power sav- You may also configure ing mode set to save power through individual components (e.g.

  • Page 63: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery New Battery Warning Always completely discharge, then fully charge, a new battery (see “Battery FAQ” When the battery is criti- on page 3 - 12 for instructions on how to do this).

  • Page 64: Recharging The Battery With The Ac/Dc Adapter

    Power Management Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you need to remove the battery for any reason, see “Removing the Battery”...

  • Page 65: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 66: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t Caution turn off the computer by yourself even when you see a message that indicates the Danger of explosion if battery is critically low, just let the computer use up all of the battery power and shut battery is incorrectly re-...

  • Page 67: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM contains the drivers and utilities necessary for vantage of some newer hardware components for the proper operation of the computer.
  • Page 68 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 69: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regarding installation of the appropriate Service Pack for your Windows XP Service Pack 2 Windows OS. Make sure you have installed the appro- priate Service Pack before installing all the drivers. Make sure you install Windows XP Service Pack 2 (or a Windows XP version which includes Service Pack 2) before installing any drivers.

  • Page 70: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Drivers If you receive a message telling you that the driver you If you wish to update/reinstall individual drivers it are installing is not authorized (Digital Signature Not may be necessary to uninstall the original driver.To do Found), just click Yes or Continue Anyway to ignore this go to the Control Panel in the Windows OS and the message and continue the installation procedure.

  • Page 71: Driver Installation

    Drivers & Utilities Driver Installation Make sure you tick the “Show Install Menu next time you start Windows when CD is Inserted” This section covers driver and utility installation in- tickbox to come back to the Driver Installation structions for Windows XP Home & Professional edi- screen (otherwise click Start (menu) >...

  • Page 72: New Hardware Found

    Drivers & Utilities New Hardware Found Service Pack Installation If you see the message “New Hardware Found” Make sure you install the appropriate service pack for (Found New Hardware Wizard) during the installa- your operating system before installing any drivers tion procedure (other than when outlined in the driver (see “Service Packs”...

  • Page 73: Winxp Driver Installation Procedure

    Drivers & Utilities WinXP Driver Installation Procedure IAA (Intel Application Accelerator) Note: This driver is only required (and will only ap- Chipset pear in the Driver Installation menu) if you have en- abled AHCI mode for SATA hard disks - see “Setting 1.

  • Page 74: Video (Vga)

    Drivers & Utilities Video (VGA) 1. Double-click VGA. 1. Double-click Lan. Navigate (Browse..) to Click Start (menu) > Run... and navigate D:\Drivers\VGA\Setup.exe and click OK. (Browse...) to D:\Drivers\Lan\Setup.exe and 2. Click Next > Yes. click OK. 3. Click Finish to restart the computer. 2.

  • Page 75: Modem

    Drivers & Utilities Modem TouchPad 1. Double-click Modem. 1. Double-click TouchPad. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse...) to (one of the following) (Browse..) to D:\Drivers\Modem\HXFSetup.exe D:\Drivers\Touchpad\SETUP.EXE and click D:\Drivers\Modem\Setup.exe and click OK. 2.

  • Page 76: Card Reader/Expresscard

    Drivers & Utilities Card Reader/ExpressCard PC Camera 1. Double-click CardReader. See the introduction in “PC Camera” on page 7 - and check the installation procedure. Click Start (menu) > Run... and navigate Wireless LAN (Browse...) to See the introduction in “Intel WLAN Module”...

  • Page 77: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Configuration: The Setup utility malfunction. To correct If your computer has never been set up, or you are making important changes to the mistakes, return to Set- up and restore the Set- system (e.g.

  • Page 78: The Setup Utility

    BIOS Utilities The Setup Utility The Insyde H20 Setup Utility tells the system how to configure itself and manage Setup Menus basic features and subsystems (e.g. port configuration). Setup menus Entering Setup shown in this section are for reference only. Your To enter the Insyde H20 Setup Utility, turn on the computer and quickly press F2 computer’s menus will during the startup process.

  • Page 79: Main Menu

    BIOS Utilities Main Menu Figure 5 - 1 InsydeH20 Setup Utility M M a a i i n n Advanced Security Power Boot Exit Main Main Menu Select the current Insyde EFI Version R1.00.P03_0_GI02 default language used H8 Version 04.0P.02 by the EFI.

  • Page 80: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 2 InsydeH20 Setup Utility Advanced Menu Main Advanced Security Power Boot Exit Advanced Configures Boot Settings. Boot Configuration IDE Configuration Video Configuration Select Boot Device <> Select Screen Select Item Enter Select SubMenu F9 = Setup Defaults F10 = Save and Exit...

  • Page 81: Boot Configuration (Advanced Menu)

    BIOS Utilities Boot Configuration (Advanced Menu) Use this menu to configure the Number Lock mode at startup (boot). AHCI Mode IDE Configuration (Advanced Menu) If you want to use AHCI Configure either a CD Device or HDD on the computer’s IDE Channel/SATA port/ mode, you must enable PATA port from this menu.

  • Page 82: Setting Up Ahci Sata Mode

    BIOS Utilities Setting Up AHCI SATA Mode Before setting up your Serial ATA hard disk in AHCI mode you will need to prepare the following: An operable computer with a floppy drive, running the Windows XP OS. The Device Drivers & Utilities + User’s Manual CD-ROM. An external USB floppy disk drive.
  • Page 83 BIOS Utilities 10. Insert the Microsoft Windows OS CD into the CD/DVD drive of the notebook computer, and attach the external USB floppy disk drive to one of the notebook computer’s USB ports. 11. Select Exit Saving Changes from the Exit menu and click OK to exit the BIOS and reboot the computer.

  • Page 84: Security Menu

    BIOS Utilities Security Menu InsydeH20 Setup Utility Main Advanced Security Power Boot Exit Security Security Menu Install or Change the The changes you make password. Supervisor Password : Not Installed here affect the access to User Password Not Installed the Setup utility itself, and also access to your Set Supervisor Password Set User Password...

  • Page 85: Set User Password (Security Menu)

    BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the Setup utility. This will not affect access to the computer OS (only the Setup utility). Many menu items in the Setup Password Warning utility cannot be modified in user mode.

  • Page 86: Power Menu

    BIOS Utilities Power Menu InsydeH20 Setup Utility CST Support for Main Advanced Security Power Boot Exit Power WinXP with Service These items control Pack 1 various CPU parameters. Advanced CPU Control If you wish to install Win- dows XP with Service Pack 1, then disable CST Support from this menu before installing...

  • Page 87: Boot Menu

    BIOS Utilities Boot Menu InsydeH20 Setup Utility Boot Sequence Main Advanced Security Power Boot Boot Exit Order Disables or enables PXE boot to LAN. PXE Boot to LAN <Disabled> To move device names up and down the boot FUJITSU MHV2040BH sequence order, select PHILIPS CD-RW/DVD-ROM SCB5265 the device name and...

  • Page 88: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 7 InsydeH20 Setup Utility Exit Menu Main Advanced Security Power Boot Exit Exit Exit system setup and save your changes. Exit Saving Changes Exit Discarding Changes Load Optimal Defaults Discard Changes Select Boot Device <>...

  • Page 89: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...

  • Page 90: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 91: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.

  • Page 92: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (as outlined in...
  • Page 93 Upgrading The Computer Slide the hard disk of arrow Lift the hard disk up in the direction of arrow Reverse the process to install a new hard disk drive. Figure 6 - 3 HDD Removal Upgrading the Hard Disk Drive 6 - 5...

  • Page 94: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws Remove the hard disk bay cover Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device.

  • Page 95: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 96 Upgrading The Computer Remove the bay cover Figure 6 - 6 CPU/RAM Bay Cover Removed Contact Warning Be careful not to touch Gently pull the two release latches on the sides of the memory socket in the the metal pins on the direction indicated by the arrows ( &...
  • Page 97 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 8 RAM Module Removal Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.

  • Page 98: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- Warranty er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may The CPU is not a user damage the processor or mainboard.

  • Page 99: Modules & Options

    Modules & Options Chapter 7: Modules & Options Wireless Device Overview Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.

  • Page 100: Pc Camera

    Modules & Options PC Camera Before installing the PC Camera driver, make sure that the optional PC Camera is Taking Still Pictures on. Use the Fn + F10 key combination (see “Function Keys” on page 1 - 9) to tog- gle power to the PC Camera module.

  • Page 101: Pc Camera Driver Installation

    Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on (click Cancel if you see a “ New Hardware Found ” message ) , and then insert the Device Drivers & Utilities Stand by/Hibernate + User’s Manual CD-ROM into the CD/DVD drive. or Shutdown Error 2.

  • Page 102: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows (see Figure 7 - 1 on page 7 - Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 103 Modules & Options Figure 7 - 1 Audio Setup (Windows XP) PC Camera 7 - 5...

  • Page 104: Bisoncap

    Modules & Options BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- You may pre-allocate the Cam menu (it is recommended that you set the capture file before the capture file size for the capture file...

  • Page 105: Eliminating Screen Flicker

    Modules & Options Eliminating Screen Flicker If you find that the video screen in the BisonCap application is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).

  • Page 106: Pc Camera Hot Keys

    Modules & Options PC Camera Hot Keys You can use the PC Camera Hot keys to run the BisonCap program, to take still pictures and to Zoom the camera in and out (if you have installed the hot key Snapshot Folder and PC Camera drivers - see “Hot Key”...

  • Page 107: Intel Wlan Module

    Modules & Options Intel WLAN Module If you have included an Intel 3945ABG (802.11a/b/g) PCIe WLAN module in your Wireless Device purchase option, you will have the appropriate software CD provided for your mod- Operation Aboard ule. Aircraft Before installing the Intel 3945ABG (802.11a/b/g) PCIe WLAN driver, make sure The use of any portable electronic transmission de- that the Wireless LAN module is on.

  • Page 108: Intel Wlan Driver Installation

    Modules & Options Intel WLAN Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. User Guide 2. Double-click Wlan. Insert the Device Driv- ers &...

  • Page 109: Bluetooth Module

    Modules & Options Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth mod- Wireless Device ule is on. Use the Fn + F12 key combination (see “Function Keys” on page 1 - Operation Aboard to toggle power to the Bluetooth module. Make sure you install the drivers in the Aircraft order indicated in Table 4 - 1, on page 4 -...
  • Page 110 Modules & Options User Guide View the BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Corpora- tion BlueSoleil - Main Window control panel. Click BlueSoleil User Guides in the Contents tab, and click to select the appropriate User Guide from the panel on the right.

  • Page 111: Port Replicator

    Modules & Options Port Replicator If you have included the Port Replicator in your purchase option, the device will al- Port Replicator low you to easily attach the notebook to standard, non-portable devices e.g. a printer AC/DC Adapter or monitor. Note the sidebar warning on the power supply. You will be provided with AC/DC...

  • Page 112: Port Replicator Setup Instructions

    Modules & Options Port Replicator Setup Instructions: Turn the computer OFF. Attach the Port Replicator’s external monitor cable to the external monitor port on the right of the computer. Attach the Port Replicator’s power cable to the DC-In jack at the rear of the computer.

  • Page 113: Port Replicator Network (Lan) Driver (Winxp)

    Modules & Options Port Replicator Network (LAN) Driver (WinXP) 1. Attach the Port Replicator as per the instructions in “Port Replicator Setup Instructions:” on page 7 - 14 2. Insert the provided Port Replicator CD into the computer’s CD/DVD drive. 3.
  • Page 114 Modules & Options 7 - 16...

  • Page 115: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 116: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 117: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 118: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 119: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 120 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 121: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 122 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...

  • Page 123: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + F4 (see screen. “Sleep Button” on page 3 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9. If you’re connected to an external monitor, make sure it’s plugged in and turned on.

  • Page 124: Boot Password

    Troubleshooting Boot Password Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

  • Page 125: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel in the heard or the volume is Windows taskbar, or use the key combination Fn + F5 and F6 (see “Audio Features”...

  • Page 126: Keyboard

    Troubleshooting Keyboard Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. (see “LED Indicators” on page 1 - appear when typing. Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.

  • Page 127: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press the sleep (Fn the screen goes dark. + F4) key combination, or press the power button if no LEDs are lit. The system never goes Power Options features are not enabled.

  • Page 128: Modules

    Troubleshooting Modules Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicator and/or function key indicator to see if the Bluetooth modules WLAN/Bluetooth module is on or off (see “LED Indicators” on page 1 - 7).

  • Page 129: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 130: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.

  • Page 131: Mini-Ieee 1394 Port

    Interface (Ports & Jacks) Item Description Mini-IEEE 1394 Port This port allows a high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). Mini-IEEE 1394 Port The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. RJ-11 Modem Jack This port connects to the built-in modem.

  • Page 132: S/Pdif-Out Jack

    Interface (Ports & Jacks) Item Description S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Jack allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’ surround sound. 7-Pin S-Video-Out Jack Connect your television to your computer and view DVDs, VCDs or anything else your computer can display.

  • Page 133: Optional Port Replicator Ports And Jacks

    Interface (Ports & Jacks) Optional Port Replicator Ports and Jacks Item Description DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer. External Monitor (VGA) This port allows you to connect an external monitor, or Flat Panel Display, to get dual video Port or simultaneous display on the LCD and external monitor/FPD (see “Display Devices”...

  • Page 134: Usb 2.0/1.1 Ports

    Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).

  • Page 135: Intel Video Driver Controls

    Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Intel Video Driver Installation Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 6.

  • Page 136: B - 2 Dynamic Video Memory Technology

    Intel Video Driver Controls Dynamic Video Memory Technology ® Intel DVMT 3.0 automatically and dynamically allocates as much (as configured DVMT Notes in the BIOS - see Page 5 - 5) system memory (RAM) as needed to the video system (the video driver must be installed - see page 1).

  • Page 137: Intel Graphics Properties

    Intel Video Driver Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Graphics Taskbar Icon Media Accelerator Driver for Mobile control panel. You can also access the Open Display Properties > Settings > Advanced (see page 15).
  • Page 138 Intel Video Driver Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Click Information (button) to obtain useful in- formation about the graphics properties of the computer, and see the Support tab in Help Menus Information to get weblinks to the latest information on the Intel Website.

  • Page 139: Display Devices

    Intel Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel display or Function Key TV as your display device. The following are the display options: Combination The built-in LCD. You can use the Fn + F7 An external monitor connected to the external monitor port.

  • Page 140: Attaching Other Displays

    Intel Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external monitor Intel Display Note port on the right of the computer. Note that the notebook Attach your external monitor to the external monitor port (or TV to the 7-pin S- is the default Primary Video-Out jack), and turn it on.

  • Page 141: Display Modes

    Intel Video Driver Controls Display Modes Single Display Only one of your attached displays is used. Intel(R) Dual Display Clone This mode will drive multiple displays with the same content. Each device may be configured independently for different resolutions, refresh rates, color quality etc. Use this feature to display the screen through a projector for a presentation.
  • Page 142 Intel Video Driver Controls To Enable Intel(R) Dual Display Clone Mode Attach your external monitor to the external monitor port (or TV to the 7-pin S-Video-Out jack), and turn it on. Go to the Graphics Properties control panel (see “Intel Graphics Properties” on page B - 3) and click Display Devices.
  • Page 143 Intel Video Driver Controls To Enable Extended Desktop Mode: Attach your external monitor to the external monitor port (or TV to the 7-pin S-Video-Out jack), and turn it on. Display Settings Go to the Graphics Properties control panel (see “Intel Graphics Properties” Extended Desktop on page B - 3) and click Display Devices.
  • Page 144 Intel Video Driver Controls To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port (or TV to the 7-pin S-Video-Out jack), and turn it on. Display Settings Click Start, point to Settings (or click Control Panel) and click Control Panel (if Extended Desktop you are in Category View choose Appearance and Themes).

  • Page 145: Tv Settings

    Intel Video Driver Controls TV Settings If you are using a TV as a display device adjust the display settings as follows: Function Key Combination Attach your TV to the 7-pin S-Video-Out jack and turn it on. Go to the Graphics Properties control panel (see “Intel Graphics Properties”...

  • Page 146: Power Settings

    Intel Video Driver Controls Power Settings Click the Power Settings button in Display Settings (tab) to set the display options based on power status of the computer. Intel Display Power Saving Technology If this option is enabled, the system will adjust LCD brightness and contrast in order to save power (when the notebook LCD is the only display device and the system is battery powered).

  • Page 147: Specifications

    Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details.

  • Page 148: Processor

    Specifications Feature Specification Intel® Core® Processor’s are Supplied as Options for Both Model A & Model B Computers Processor Intel® Core™ Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache & 667MHz FSB T2300/ T2400/ T2500/ T2600/ T2700 1.66/ 1.83/ 2.0/ 2.16/ 2.33 GHz Intel®...

  • Page 149: Video Adapter

    Specifications Feature Specification Video Adapter Intel 945GM Integration Dynamic Video Memory Technology DVMT 3.0 - Supports up to 224MB of Video Memory (dynamically allocated from system memory where needed) Supports Analog Monitor Pixel Resolution up to QXGA 2048 * 1536 Integrated High Quality 3D Graphics Engine Supports DirectX 9.0 Supports Two Displays...

  • Page 150: Interface

    Specifications Feature Specification Interface Three USB 2.0 Ports One RJ-11 Modem Jack One Serial Port One RJ-45 LAN Jack One External Monitor Port One Mini-IEEE 1394 Port One Headphone-Out Jack (7.1 CH) One 7-Pin S-Video-Out Jack (supports HDTV) One Microphone-In Jack (7.1CH) One DC-in Jack One Line-In Jack (7.1CH) One S/PDIF Out Jack (7.1CH)

  • Page 151: Battery

    Specifications Feature Specification Power Full Range AC/DC Adapter 19V, 3.42A, 100~240V, 47~63Hz Full Range AC/DC Adapter 20V, 4.5A (90 Watts), 100~240V, 50~60Hz (Supplied for the Optional Port Replicator Only) Battery For Model A Computers Only For Model B Computers Only 6 Cell Smart Lithium-Ion Battery Pack, 4400mAH 6 Cell Smart Lithium-Ion Battery Pack, 4000mAH (48.8W)
  • Page 152 Specifications C - 6...

Table of Contents
