SOHOConnect Series
FSD-8080/FSD-1600
8/16-port 10/100Mbps Ethernet Switch
FSD-8080 User's Manual
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSD-8080 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Soho FSD-8080

  • Page 1 SOHOConnect Series FSD-8080/FSD-1600 8/16-port 10/100Mbps Ethernet Switch FSD-8080 User's Manual...
  • Page 2: Fcc Warning

    Revision The information in this manual is subject to change without notice. User's manual for PLANET SOHOConnect Series Switch Model: FSD-8080/FSD-1600 Rev: 2.1 (March. 2000) Part No. EM-FSD80-2 SOHOConnect Series...
  • Page 3: Table Of Contents

    Introduction..............1 Features ................ 3 CHAPTER 2................ 5 ........... 5 ARDWARE ESCRIPTION Front Panel ..............5 Rear Panel ..............7 Hardware Installation............ 8 Configuration ..............9 Switch Operation............11 CHAPTER 3...............17 ............17 ROUBLESHOOTING APPENDIX A ..............19 : ...............19 PECIFICATIONS FSD-8080/1600 User's Manual...
  • Page 4 This page is intentionally left blank SOHOConnect Series...
  • Page 5: Chapter 1

    Introduction The FSD-8080/1600, 8/16-port 10/100Mbsp Ethernet Switch is designed to allow simultaneous transmission of multiple packets FSD-8080/1600 User's Manual...
  • Page 6 via an internal high-speed data channel. This means that it can partition a network more efficiently than bridges or routers in most environments. In the following sections, the term “Switch” will represent Planet’s FSD switch, and “switch” for third part Ethernet switches. This Switch is a highly reliable network switch and is the ideal device for bridging Ethernet to Fast Ethernet workgroups or networks.
  • Page 7: Features

    Full/Half-Duplex capability on every TX ports, total bandwidth is up to 200Mbps/port ♦ Support up to 4K Uni-cast address, Layer 2 address resolution-Self Learning ♦ Broadcast storm control ♦ IEEE802.3x compliant full-duplex flow control ♦ Half-duplex flow control FSD-8080/1600 User's Manual...
  • Page 8 ♦ Runt and CRC Filtering eliminates erroneous packets to optimize the network bandwidth ♦ Provide external power supply ♦ LED indicators for simple diagnostics and management ♦ Port#1 provides an extra port for MDI and MDI-X mode PC or hub uplink. ♦...
  • Page 9: Chapter 2

    Before connecting any network device to the hub, read this chapter carefully. Front Panel The unit front panel provides a simple interface monitoring the Switch. It includes a power indicator for each port. FSD-1600 Figure 1. Front Panel of FSD-8080...
  • Page 10 SOHOConnect Series...
  • Page 11: Rear Panel

    COL indicator will briefly blink Rear Panel The rear panel of the Switch indicates a DC-jack power socket, which accepts exactly DC 12V, 1A power from the output of the AC adapter connected to your local AC power outlet. And one FSD-8080/1600 User's Manual...
  • Page 12: Hardware Installation

    100~240VAC Power inlet for FSD-1600. Figure 2. Rear Panel of FSD-8080/1600 Hardware Installation 1. Place the Switch on a smooth surface 2. Connect the output cord of power supply to the DC-jack. 3. Connect hub or PC to one port of the Switch using Category 3/4/5 UTP/STP cabling.
  • Page 13: Configuration

    Plug one end of the Category 3 UTP Cable into “Uplink” port of the Switch, and the other end of this cable into any port of the 10Mbps Ethernet hub. The cable length between these 2 connecting points should not exceed 100 meters. FSD-8080/1600 User's Manual...
  • Page 14 Figure 3. 100Mbps File server to Hubs Connection 10Mbps Hub to 100Mbps Hub Plug one end of the Category 5 UTP Cable into one port of the Switch, and the other end of this cable into “Uplink” port of the 100Mbps Fast Ethernet Hub.
  • Page 15: Switch Operation

    Ethernet Switch. Learning When one packet comes in from any port. The Ethernet Switch will record the source address, port no. and the other related information in address table. These information will be used to FSD-8080/1600 User's Manual...
  • Page 16 decide either forwarding or filtering for future packets. Forwarding & Filtering When one packet comes from some port of the Ethernet Switch, it will also check the destination address besides the source address learning. The Ethernet Switch will lookup the address table for the destination address.
  • Page 17 This confines network traffic to its respective domain, reducing the overall load on the network. The Switch performs “Store-and-forward” therefore, no error packets occur. More reliably, it reduces the re-transmission rate. No packet loss will occur. FSD-8080/1600 User's Manual...
  • Page 18 Auto-Negotiation The STP ports on the Switch have built-in "Auto-Negotiation." This technology automatically sets the best possible bandwidth when a connection is established with another network device (usually at Power On or Reset). This is done by detect the modes and speeds at the second of both device is connected and capable of.
  • Page 19 This page is intentionally left blank FSD-8080/1600 User's Manual...
  • Page 21: Chapter 3

    Chapter 3 Troubleshooting This chapter contains information to help you solve problems. If the Switch is not functioning properly, make sure the Switch was set up according to instructions in this manual. The Link LED is not Lit Solution: Make sure the switch configuration is consistent with the connecting device Check the cable connections.
  • Page 22 The address table may contain older information than of the address table of that node. Please power down to refresh the address information. SOHOConnect Series...
  • Page 23: Specifications

    Appendix A Specifications: General (Ethernet) Standards: IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100 Base-TX Fast Ethernet ANSI/IEEE Std 802.3 N-way auto-negotiation IEEE 802.3 Frame types: Transparent IEEE 802.3 MAC layer frame size: 64 - 1518 Bytes Protocol: CSMA/CD Data Transfer Rate: Ethernet: Fast Ethernet: 10Mbps (half duplex)
  • Page 24 General (Ethernet) Storage Temperature -20 ~ 70 degree C Humidity 10% ~ 90% non-condensing Dimensions 220 x 130 x 29 mm 220 x 130 x 44 mm FCC Class A, CE Mark Class A Performance Transmission Store-and-forward Method Filtering Address 4 K entries / device Table Packet...
