Summary of Contents for EyESonic DS-7200HFHI-ST series

  • Page 1: User Manual

    User Manual www.eyesoniccctv.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS DVR Pre-Installation ............................2 DVR Installation .............................. 2 Hard Disk Installation ............................. 2 Front Panels ..............................5 Rear Panels ..............................12 Peripheral Connections ..........................15 Wiring of Alarm Input ........................... 15 Wiring of Alarm Output ........................15 Alarm Connection ............................
  • Page 3: Dvr Pre-Installation

    DVR Pre-Installation The DS-7200HFHI-ST&SE&SL, DS-7300HFHI-ST&SL and DS-8100HFHI-ST&SL series DVR is highly advanced surveillance equipment that should be installed carefully. Please take into consideration the following precautionary steps before installation of the DVR. 1. Keep all liquids away from the DVR. 2.
  • Page 4 As the installation steps of HDD are similar among different models, here we take the steps of the DS-7200HFHI-SE as an example. Steps: 1. Remove the cover from the DVR by unfastening the screws on the back and side. 2. Connect one end of the data cable to the motherboard of DVR and the other end to the HDD. 3.
  • Page 5 5. Re-install the cover of the DVR and fasten screws. www.eyesoniccctv.com...
  • Page 6: Front Panels

    Front Panels Front Panel of DS-7204HFHI-SE & DS-7200HFHI-SL Front Panel of DS-7208HFHI-SE Description of Front Panel Name Function Description Power indicator turns yellow when the power switch on the real POWER panel is turned on. Status indicator blinks red when data is being read from or written to STATUS HDD.
  • Page 7 Name Function Description Switch between the numeric or letter input and functions of the SHIFT composite keys. (Input letter or numbers when the light is out; Realize functions when the light is red.) Enter numeral “1”; 1/MENU Access the main menu interface. Enter numeral “2”;...
  • Page 8 Name Function Description The ENTER button is used to confirm selection in any of the menu modes. It can also be used to tick checkbox fields. ENTER In Playback mode, it can be used to play or pause the video. In single-frame Playback mode, pressing the button will advance the video by a single frame.
  • Page 9 Name Function Description Switch between the numeric or letter input and functions of the SHIFT composite keys. (Input letter or numbers when the light is out; Realize functions when the light is red.) Enter numeral “1”; 1/MENU Access the main menu interface. Enter numeral “2”;...
  • Page 10 Name Function Description In PTZ control mode, it can control the movement of the PTZ camera. The ENTER button is used to confirm selection in any of the menu modes. It can also be used to tick checkbox fields. ENTER In Playback mode, it can be used to play or pause the video.
  • Page 11 Name Function Description Input numbers and characters in Edit mode. Switch between different channels in Playback mode. The light of the button is blue when the corresponding channel is recording; it is red when the channel is in network transmission status;...
  • Page 12 Name Function Description Edit text fields. When editing text fields, it will also function as a Backspace button to delete the character in front of the cursor. On checkbox fields, pressing the button will tick the checkbox. EDIT/IRIS+ In PTZ Control mode, the button adjusts the iris of the camera. In Playback mode, it can be used to generate video clips for backup.
  • Page 13: Rear Panels

    Rear Panels DS-7204HFHI-SL DS-7208HFHI-SL DS-7204HFHI-SE DS-7204HFHI-ST DS-7208HFHI-SE and DS-7208HFHI-ST Item Description VIDEO IN HD-SDI interface for video input. AUDIO IN RCA connector AUDIO OUT RCA connector DB15 connector for VGA output. Display local video output and menu. HDMI HDMI video output connector. USB Port Universal Serial Bus (USB) port for additional devices.
  • Page 14 DS-7300HFHI-SL DS-7300HFHI-ST DS-8100HFHI-SL DS-8100HFHI-ST Item Description VIDEO IN HD-SDI interface for video input. VIDEO OUT BNC connector for video output. AUDIO IN RCA connector USB Port Universal Serial Bus (USB) port for additional devices. HDMI HDMI video output connector. DB15 connector for VGA output. Display local video output and menu.
  • Page 15 Item Description pins of PTZ receiver respectively. D+, D- pin connects to Ta, Tb pin of controller. For cascading devices, the first DVR’s D+, D- pin should be connected with the D+, D- pin of the next DVR. Connector for alarm input. Connector for alarm output.
  • Page 16: Peripheral Connections

    Peripheral Connections Wiring of Alarm Input The alarm input is an open/closed relay. To connect the alarm input to the device, use the following diagram. If the alarm input is not an open/close relay, please connect an external relay between the alarm input and the device.
  • Page 17: Rs-485 And Controller Connection

    3. Connect pluggable block back into terminal block. RS-485 and Controller Connection For DS-7200HFHI-SL, DS-7200HFHI-SE & DS-7200HFHI-ST To connect PTZ to the DVR: 1. Disconnect pluggable block from the RS-485 terminal block. 2. Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange part.
  • Page 18: Termination Switch Operation

    2. Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange part. Ensure signal cables are in tight. 3. Connect Ta on controller to D+ on terminal block and Tb on controller to D- on terminal block. Fasten stop screws.
  • Page 19: Specifications

    Specifications Table 1 Specification for DS-7200HFHI-SL Model DS-7204HFHI-SL DS-7208HFHI-SL H.264 Video compression 4-ch 8-ch HD-SDI video input HD-SDI interface (800 mVp-p, 75 Ω) Video/Audio 1080I60, 1080I50, 1080P30, 1080P25, 720P60, 720P50, 720P30, Supported HD-SDI input 720P25 camera types G.711u Audio compression Audio in / 1-ch, RCA (2.0 Vp-p, 1 KΩ) Two-way audio in...
  • Page 20: Table 2 Specification For Ds-7200Hfhi-Se

    (W × D × H) Weight 1 kg / 2.2lb (without hard disks) Table 2 Specification for DS-7200HFHI-SE Model DS-7204HFHI-SE DS-7208HFHI-SE Video compression H.264 4-ch 8-ch HD-SDI video input HD-SDI interface (800 mVp-p, 75 Ω) Supported HD-SDI 1080I60, 1080I50, 1080P30, 1080P25, 720P60, 720P50, 720P30, Video/Audio camera types 720P25...
  • Page 21: Table 3 Specification For Ds-7200Hfhi-St

    hard disk) -10 º C ~+55 º C (14 º F ~ 131 º F) Working temperature 10% ~ 90% Working humidity 19-inch rack-mounted 1U Chassis Stand-alone 1U chassis chassis 315× 230× 45 mm 445× 290× 45mm Dimensions (12.3× 9.0× 1.8 inch) (17.3×...
  • Page 22: Table 4 Specification For Ds-7300Hfhi-Sl

    NFS, iSCSI, UPnP™ 2 SATA interfaces SATA Hard disk Up to 4 TB capacity for each disk Capacity 1; 10M / 100M / 1000M self-adaptive Ethernet interface Network interface 1; standard RS-485 serial interface, half-duplex Serial interface External 2 × USB2.0 USB port interfaces Alarm in / out...
  • Page 23: Table 5 Specification For Ds-7300Hfhi-St

    64 Kbps Audio bitrate Support Dual-stream Video, Video & Audio Stream type 4-ch 8-ch 16-ch Synchronous playback 1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF Playback resolution Remote connection Network TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, management Network protocols NFS, iSCSI, UPnP™...
  • Page 24: Table 6 Specification For Ds-8100Hfhi-Sl

    QCIF / QVGA Main stream: 1/16 fps ~ Real time frame rate Frame rate Sub-stream: 1/16 fps ~ Real time frame rate 32 Kbps-10 Mbps Video bitrate 2-ch, RCA (Linear, 1KΩ, for VGA output and CVBS output Audio output respectively) 64 Kbps Audio bitrate Dual-stream...
  • Page 25: Table 7 Specification For Ds-8100Hfhi-St

    Model DS-8104HFHI-SL DS-8108HFHI-SL DS-8116HFHI-SL 1-ch, RCA (2.0 Vp-p, 1 KΩ) Two-way audio in 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, HDMI / VGA output 1024 × 768 / 60 Hz 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 ×...
  • Page 26 H.264 Video compression 4-ch 8-ch 16-ch HD-SDI video input HD-SDI interface (800 mVp-p, 75 Ω) 1080I60, 1080I50, 1080P30, 1080P25, 720P60, 720P50, 720P30, Supported HD-SDI Video/Audio 720P25 camera types input G.711u Audio compression 4-ch 8-ch 16-ch Audio input RCA (2.0 Vp-p, 1 KΩ) 1-ch, RCA (2.0 Vp-p, 1 KΩ) Two-way audio in 1920 ×...
  • Page 27 (W × D × H) Weight (without hard ≤8Kg disks or DVD-R/W) www.eyesoniccctv.com...
  • Page 28: Hdd Storage Calculation Chart

    HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K 256K 112M 320K 140M 384K 168M 448K...
  • Page 29: Accessing By Web Browser

    Accessing by Web Browser Logging In You can get access to the device via web browser. Open web browser, input the IP address of the device and then press Enter. The login interface appears. Input the user name and password, and click the Login button. ...
  • Page 30: Recording

    Name Description Play Control Bar Play control operations are supported. Pan, tilt, zoom operations are supported, as well as preset editing and calling. PTZ Control PTZ function can only be realized if the connected camera supports PTZ control. Video Parameters Brightness, contrast, saturation and hue of the image can be edited.
  • Page 31: Playback

    1) Configure All Day or Customize Record:  If you want to configure the all-day recording, please check the All Day checkbox.  If you want to record in different time sections, check the Customize checkbox. Set the Start Time and End Time.
  • Page 32: Log

    3. Select the date from the calendar and click Search. 4. Click the Play button to play the video file searched on the current date. 5. Use the buttons on the toolbar to operate in playback mode. Button Description Button Description Play/Pause Stop...
  • Page 33: Menu Operation

    Menu Operation Menu Structure The menu structure of the DS-7200HFHI-SL&SE&ST DVR is shown below: The menu structure of the DS-7300HFHI-ST&SL & DS-8100HFHI-ST&SL DVR is shown below: Startup and Shutdown Proper startup and shutdown procedures are crucial to expand the service time of the DVR. To start the DVR: Check the power supply is plugged into an electrical outlet.
  • Page 34: Live View

    Power indicator LED on the front panel should be yellow. To shut down the DVR: Steps: 1. Enter the Shutdown menu. Menu > Shutdown 2. Select the Shutdown button. 3. Click the Yes button. 4. Turn off the power switch on the rear panel when the note appears (supported by DS-7200HFHI-SE and DS-7200HFHI-SL series).
  • Page 35: Instant Recording

    Purpose: Two kinds of record types are introduced in the following section, including Instant Record and All-day Record. And for other record types, you may refer to the user manual for detailed information. After rebooting all the manual records enabled are canceled. Instant Recording On the live view window of each channel, there is a quick setting toolbar which shows on the bottom of the window when you click on it.
  • Page 36: Playback

    Playback Play back the record files of a specific channel in the live view menu.  OPTION 1: Choose a channel under live view using the mouse and click the button in the shortcut operation menu. Only record files recorded during the last five minutes on this channel will be played back. ...
  • Page 37: Backup

    Just check the channel or channels if you want to switch playback to another channel or execute simultaneous playback of multiple channels. Backup Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or USB DVD writers. To export recorded files: 1.
  • Page 38 www.eyesoniccctv.com...
  • Page 39 INN OVATIVE CUSTOMIZ ED CC T V SOLUTION S www.eyesoniccctv.com...
