Measurement Operation

DC and AC Voltage Measurement

WARNING: To avoid harm to you or damage to
!
the Meter from electric shock, please do not
attempt to measure voltages higher than 1000V
although readings may be obtained.
The DC Voltage ranges are: 200mV, 2V, 20V, 200V and
1000V.
The AC Voltage ranges are: 2V, 20V, 200V and 750V.
To measure DC or AC Voltage, perform the following
steps:
1. Insert the red test lead into the HzV Ω Ω Ω Ω Ω
and the black test lead into the COM input terminal.
XPro - Operation Manual
14
black red
terminal
