Summary of Contents for Dirty hand 101172
-
Page 1: Portable Power Generator
800 RATED WATTS/900 MAXIMUM WATTS PORTABLE POWER GENERATOR MODEL # 101172 Operation Manual This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Part # 101189 Rev B... - Page 2 For Service or Questions Call 1-877-487-8275 720-287-5182 www.dirtyhandtools.com Dirty Hand Tools® is a brand of 1100 W 120th Ave, Suite 600 Westminster, CO 80234 • 720-287-5182...
-
Page 3: Table Of Contents
Table of Contents Important Safety Information .............4 Unpacking and Setup ..............7 Filling with Gasoline and Oil ............8 Operation Precautions ..............9 Operation ..................11 Maintenance .................13 Troubleshooting ................15 Storage ..................17 Wiring Diagram ................17 Parts List ..................18 Generator Assembly ..............19 Warranty and Specifications .......... Back Cover... -
Page 4: Important Safety Information
Important Safety Information WARNING WARNING: Read and thoroughly understand all instructions and safety information before operating this portable power generator. Failure to do so may cause serious injury or death. Do not allow anyone to operate this portable power generator who has not read this manual. -
Page 5: General Safety
Important Safety Information General Safety Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. DANGER READ THE OPERATION MANUAL BEFORE OPERATION. • Do not permit children to operate this equipment at any time. Do not permit others that have not read and understood the complete Operation Manual to operate this equipment. - Page 6 Make sure all safety warning decals are attached and in readable condition. Replace missing or defaced decals. Contact Dirty Hand Tools at 1-877-487-8275 for replacement decals. DANGER USING A GENERATOR INDOORS...
-
Page 7: Unpacking And Setup
Unpacking and Setup Your portable power generator is assembled at the factory, with the exception of the carrying handle, which is packed separately and must be attached to the fuel tank cover with hardware supplied. Attach the handle with a bolt, lock washer, and washer in two places (see line drawing at left). -
Page 8: Filling With Gasoline And Oil
Filling with Gasoline and Oil WARNING FUEL MIX: MIX UNLEADED GASOLINE WITH 2-STROKE ENGINE 50:1 OIL, 50:1 GAS/OIL RATIO, IN A SEPARATE CONTAINER AND ADD TO THE FUEL TANK 2.5 FL. OZ. GALLON 2-CYCLE BEFORE STARTING THE ENGINE 1. Place the portable power generator on a level surface. Set up the generator outdoors in a well-ventilated, dry area, away from building air intakes. -
Page 9: Operation Precautions
Operation Precautions WARNING CARBON MONOXIDE HAZARD USING A GENERATOR INDOORS CAN KILL YOU IN MINUTES. Generator exhaust contains carbon monoxide. This is a poison you cannot see or smell. 1. Keep all safety guards in place and in proper working order at all times. - Page 10 Operation Precautions CAUTION This generator is not intended to power sensitive electronic equipment without the addition of an appropriate line conditioner and surge protector (both not included). Sensitive electronic equipment, including but not limited to audio/video equipment, television sets, computers, and printers, should be operated on approved inverter type generators or pure sine wave generators.
-
Page 11: Operation
Operation POWER CAUTION ONLY AFTER THE GENERATOR IS RUNNING SMOOTHLY SHOULD AN APPLIANCE OR TOOL BE PLUGGED INTO THE AC OUTLET OF THE GENERATOR. OPEN FUEL 1. Prior to each use, connect a #6 AWG grounding wire (not VALVE included) from the ground terminal on the control panel to a grounding rod (not included) that has been driven at least 24 inches deep into the earth. - Page 12 Operation 7. Load And Circuit Breaker: The total combined load through the outlet on the generator must not exceed the Disconnect Unit Can Power Any One of the Following Items: rated maximum power (800 watts) of the unit. Always Powered Running Start-up reduce the load if the AC circuit breaker turns off.
-
Page 13: Maintenance
Maintenance WARNING BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE (5) MINUTES TO ALLOW ALL PARTS TO COOL. Disconnect the spark plug wire, keeping it away from the spark plug. Regular maintenance is the way to ensure the best performance and long life of your machine. - Page 14 Maintenance WARNING TO PREVENT SERIOUS INJURY FROM ACCIDENTAL STARTING TURN THE POWER SWITCH OF THE ENGINE TO ITS “OFF” POSITION. Wait for the engine to cool, and remove the spark plug wire before performing any inspection, maintenance, or cleaning procedures. Changing /Cleaning the Air Filter 1.
-
Page 15: Engine Troubleshooting
Engine Troubleshooting WARNING BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE (5) MINUTES TO ALLOW ALL PARTS TO COOL. Disconnect the spark plug wire, keeping it away from the spark plug. PROBLEM SOLUTION The engine will not start. •... -
Page 16: Generator Troubleshooting
Generator Troubleshooting PROBLEM SOLUTION No output from generator’s AC receptacle. • Engine speed too slow. • Adjust engine speed. Requires qualified technician. • Open or shorted wiring. • Clean and reconnect all wiring. • Faulty capacitor. • Replace capacitor. • Open/shorted rotor or stator windings. •... -
Page 17: Storage
Storage 1. Wait for the engine to cool, then clean the engine with a clean cloth. 2. When the generator is to be stored for longer than 20 days, prepare the engine for storage by emptying the fuel tank and draining all fuel lines (see Figure 8). Clean out area around spark plug and remove. -
Page 18: Parts List
Parts List Part Description Part Description Left Crankcase Intake Valve Gasket Right Crankcase Intake Valve Assy. Bearing (6004) Flange Bolt (M6 x 20) Hole Circlip (#42) Stud (AM6 x 60) Oil Seal (20 x 30 x 7) Intake Gasket Pin (10 x 7 x 14) Carburetor Stud (AM6 x 50) Carburetor Gasket (B) -
Page 19: Generator Assembly
Generator Assembly The parts list and assembly drawing are provided as a reference tool only. It is recommended that any repairs or parts replacement be done by a qualified technician. User repair and parts replacement may void the warranty. -
Page 20: Warranty And Specifications
Accessories Spark Plug Wrench Included *As rated by engine manufacturer ** Unleaded Gasoline, 89+ Octane For Service or Questions Dirty Hand Tools® is a brand of Call 1-877-487-8275 720-287-5182 1100 W 120th Ave., Suite 600 www.dirtyhandtools.com Westminster, CO 80234 • 720-287-5182...
