OPERATING INSTRUCTIONS
OPERATION
This storage heater takes in Energy
when electricity tariffs are low and
dissipates it when tariffs are normal.
SAFETY INSTRUCTIONS
1. Ventilate rooms well during commissioning
2. Do not move the heater in any way once installed without
the services of a competent electrician.
3. Do not cover the heater with clothing etc. at any time or
position furniture close to or against the heater.
4. Ensure a clearance of at least 150mm between heaters and
curtains.
5. Floor standing heaters must only be fi tted with the back
against a wall.
6. Should your heater fail to operate either employ the services
of a competent electrician or Telephone (0845) 600 5111.
ALSO REFER TO COVER PAGE
COMMISSIONING
Set both the Input Control and the Output Control to 6 and
leave the heater for 48 hours.
Following the commissioning period adjust the controls as
stated below.
SETTING THE CONTROLS
The controls are located under the hinged fl ap at the top right hand
corner of the heater.
To adjust the controls on the heater use a coin and engage it in the
slots provided on the top surface of the knob. There are no user
adjustable controls on the WMX706N.
CONTROL FUNCTIONS
THE INPUT CONTROL
For models WMS712N, 718N, 724N only:
This heater is fi tted with a user adjustable automatic input control
which varies the charge taken in response to weather conditions taking
into account the amount of energy already stored in the heater.
Set at 6 the heater takes maximum charge and at 1 the heater
takes a minimum charge at any room temperature. The casing of
the heater, particularly in late evening, may feel cool, this is quite
normal. The input control may require a few days experimentation
before your comfort level is established.
Initially set the control to 3, the following evening if the room is too warm
reduce to 2 or if it is too cool increase to 4. On subsequent evenings
adjust by half divisions until your comfort level is achieved.
Having established the setting the input will automatically carry the
amount of heat stored to compensate for weather variations.
For models WMX712N, 718N, 724N only:
Initially set the input to 4. If the heater does not maintain a satisfactory
room temperature the following day this setting should be increased.
Conversely if the room temperature is too high this setting should
be reduced.
The input control should only require seasonal adjustments.
THE OUTPUT CONTROL
For all models except WMX706N
Most of the stored heat is radiated from the casing during the
discharge period. However, some of the heat is emitted through the
grille at the top of the heater and this additional heat (or boost) is
regulated by the Output Control.
With this set to 6 the boost begins in the early afternoon. Turning the
control towards 1 will progressively delay the commencement of the
boost. At 3 the boost will start in the evening. Once set, the boost
will repeat itself automatically day after day.
If no boost is required e.g. when the room will be unoccupied for a long
period, set the Output Control to 1. With the control in this position,
the heater will take less energy during the next charging up period.
CLEANING
To maintain the appearance of the heater wipe occasionally with a
dry cloth when the heater is cool.
Do not use abrasive powders of furniture polish.
Discolouration of wall fi nishes can sometimes occur immediately
above a storage heater due to the properties of some paints and
decorating materials or the presence of environmental impurities
in the air (such as soot or incense generated from the burning of
candles etc.).
AFTER SALES SERVICE
Your storage heater is guaranteed for two years from date of
purchase. We undertake to repair or exchange within the period,
any part found to be defective due to a manufacturing fault. This
guarantee does not affect your statutory rights.
Should you require after sales service, please contact the supplier
through whom you purchased the heater, or telephone 0845 600
5111.
Please do not initially return faulty appliance, or part of an appliance
to us as this may result in transit damage and/or a delay in providing
service.
Let us know your diffi culty quoting the model number and serial
number (located along the wall bracket). We will then take the
appropriate action.
RECYCLING
For electrical products sold within the European
Community. At the end of the electrical products useful
life it should not be disposed of with household waste.
Please recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice in your country.
Derby Products Pty. Ltd
ABN 81 009 477 561
P.O. Box 84, Glenorchy
Tasmania 7010
Tel: 1800 030 668
e-mail: sales@derbyproducts.com.au
#Web address: www.derbyproducts.com.au
This product complies with the European Safety Standards EN60335-2-30 and the European Standard
Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3.
These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
© GDC Group Ltd. All rights reserved. Material contained in this publication may not be reproduced in whole or in part,
without prior permission in writing.
A division of the GDC Group Ltd, Millbrook House, Grange Drive, Hedge End, Southampton SO30 2DF
Part No. 87570
Issue 2
