- Page 1 ZONE4R Instruction manual...
- Page 3 ZONE4R Instruction manual ZONE4R Manual...
- Page 4 Wiring is easy, using industry standard CAT5 (or higher) computer network cable. Both T-568A and T-568B cable terminations can be used. It is possible to use more than one ZONE4R remote panel per zone. Maximum number of remote panels per ZONE4 preamplifier is 8 panels in any configuration : e.g.
-
Page 5: Front Panel And Operation
ZONE4R Instruction manual Front panel and operation... - Page 6 ZONE4 controls 1. Music level control: this knob has the same functionality as the music level knob on the ZONE4 main unit. Turn the knob to adjust the music level. The actual value is displayed on the screen ‘2’ for a few seconds. Push the knob to mute the music, the mute status is indicated by led ‘4’.
- Page 7 ZONE4R Instruction manual 4. Music level mute led: this led lights up when the music is muted. 5. Line input selector switches (music) : use these switches to scroll downward through line input A to D. The selected input is shown in the display ‘2’.
- Page 8 ZONE4 controls ZONE4R connector and wiring details 1 2 3 4 Ground connection (GND) -> connect to RJ45 pin 1 and 3 and 7 (colours : see table below)
- Page 9 ZONE4R Instruction manual Data connection (Rx B) -> connect to RJ45 pin 4 (colours : see table below) Data connection (Tx A) -> connect to RJ45 pin 5 (colours : see table below) Power supply (+12VDC) -> connect to RJ45 pin 2 and 6 and 8 (colours : see table below) RJ45 connections on rear of ZONE4 main unit ‘to zone remote wall panels’...
- Page 10 ZONE4 controls Pin number RJ45 T-568A cable colour T-568B cable colour EUROBLOCK 4 code code (See picture above) Pin 1: GND white – green white – orange connector 1 Pin 2: 12 VDC green orange connector 4 Pin 3: GND white –...
-
Page 11: Installation Instructions
With every push, the zone number changes 1 up, from 1 to 4 and back to 1 and so on. You can connect multiple ZONE4R units to the ZONE4 main unit using a straight through CAT5 cable hub. You can assign multiple ZONE4R units to the same zone. - Page 12 ZONE4 controls ZONE4R zone select switch at the back of the ZONE4R unit. ZONE4R optional accessories • RJ45SPLIT: 1 in/4 out straight through RJ45 splitter box. This unit can not be housed in a back box.
- Page 13 ZONE4R Instruction manual Dimensions: 29 (h) x 104 (w) x 40 (d) mm The RJ45 input is located at the side of the unit • BB1: ZONE4R on-wall back box Dimensions: 80 (h) x 114 (w) x 48 (d) mm...
- Page 14 ZONE4 controls • BBI1: ZONE4R in-wall back box. ZONE4R is also compatible with BTicino 503E in-wall boxes or 503NP on-wall boxes.
- Page 15 Use CAT5 or CAT6 cable only. Maximum approved cable length is 100 meters per zone. • ZONE4R cover plate is not interchangeable. • CAT5 cable terminations according to T-568A or T-568B are possible. For details about wiring please refer to the wiring details and colour code. T-568B termination is not recognized in the USA, but is considered as standard cable termination in many other countries.
- Page 16 Audioprof nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
