Model TLC
PLEASE READ AND UNDERSTAND THE REQUIREMENTS BEFORE PROCEEDING
Type of Appliances
Your Model TLC chimney is intended for venting gas,
liquid, or solid fuel-fired, residential-type appliances and
building heating appliances or as defined in NFPA 211, in
which the maximum continuous flue gas temperatures do
not exceed 1000°F. It has been tested and approved to
withstand temperatures of up to 2100°F for three
10-minute intervals.
Pre-Installation Guidelines
If you choose to have your product installed by
others, we recommend these products be installed by
professionals who are certified by NFI (National Fireplace
Institute) or equivalent.
Your Model TLC chimney and connecting stovepipe
diameter should be sized in accordance with the
appliance manufacturer's recommendations.
Plan the installation of your appliance and chimney in
such a way that both your chimney and your stovepipe
run as short and straight as possible. By having too long
and/or multiple-bend installations, you can reduce system
draft that can affect the operation and/or performance
WARNING:
Hart & Cooley, Inc.
Factory-Built Type HT Insulated Chimney - Tested to UL103
A MAJOR CAUSE OF CHIMNEY-RELATED
FIRES IS FAILURE TO MAINTAIN REQUIRED
CLEARANCES (AIRSPACES) TO COMBUSTIBLE
MATERIALS. IT IS OF UTMOST IMPORTANCE
THAT THIS CHIMNEY BE INSTALLED ONLY IN
ACCORDANCE WITH THESE INSTRUCTIONS.
Please read all instructions before beginning your installation.
Failure to install this system in accordance with these instructions will
void the conditions of certification and the manufacturer's warranty.
Keep these instructions in a safe place for future reference.

Installation Instructions

All-Fuel Chimney - 5" to 8"
of your appliance and/or chimney system. The chimney
should be located within the building in order to avoid
cutting or altering load-bearing members, such as joists,
rafters, studs, etc. If you have to cut or alter an existing
load-bearing member, special reframing methods are
required, which often include doubling of adjacent
members. If such a case arises, contact your local
Building Code Official regarding local regulations and
proper installation methods.
Sections of the Model TLC chimney that pass through
accessible areas of the building, such as through closets,
storage areas, occupied spaces, or any place where the
surface of the chimney could be contacted by persons
or combustible materials, must be enclosed in a chase
to avoid personal contact and damage to the chimney.
The chase may be fabricated using standard building
materials. Drywall mounted on 2" x 4" studs is typically
used in this situation. The space between the outer wall
of the chimney and the enclosure must be at least a
minimum of 2 inches.
MAINTAIN A 2-INCH MINIMUM AIRSPACE
CLEARANCE BETWEEN INSULATED CHIMNEY
SECTIONS AND COMBUSTIBLE MATERIALS.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TLC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hart and Cooley TLC

  • Page 1: Installation Instructions

    Your Model TLC chimney is intended for venting gas, rafters, studs, etc. If you have to cut or alter an existing liquid, or solid fuel-fired, residential-type appliances and...
  • Page 2 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions WARNING: DO NOT PLACE ANY INSULATING MATERIALS OR RUN ANY ELECTRICAL WIRING WITHIN THE REQUIRED AIR CLEARANCE SPACE SURROUNDING THE CHIMNEY. Before beginning the installation, ensure that you obtain required for added safety, stability when exposed to high...
  • Page 3: Ceiling (Support)

    For sloping roofs, ensure that the framing dimension is (Figure 2). The Model TLC ceiling support will support up to 50 feet • Rain Cap: Deluxe model. measured in the horizontal plane (Figure 3).
  • Page 4 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions Model TLC All-Fuel Chimney - 5" to 8" Installation Instructions Slide the trim ring onto the ceiling support, and slide the Slide the trim ring onto the ceiling support, and slide the Attic Insulation Shield Installation assembly into the framed opening from below.
  • Page 5 Installation Instructions Model TLC All-Fuel Chimney For proper installation, the attic opening must be fully framed at 2 inches of clearance to the chimney pipe with framing material of the same dimension as the ceiling joists, per Table 2 (Framing Dimensions for Attic Insulation Shield).
  • Page 6 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions Place the required offset chimney length(s) as per the To complete a proper wall support installation, the Offset Chimney Installation chart for appropriate following parts will or may be required.
  • Page 7 Installation Instructions Model TLC All-Fuel Chimney Installation Instructions Model TLC All-Fuel Chimney The maximum chimney height above a wall support is The wall support will allow for an adjustment of 2" to 6" The maximum chimney height above a wall support is The wall support will allow for an adjustment of 2”...
  • Page 8 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions Model TLC All-Fuel Chimney - 5" to 8" Installation Instructions Table 4 Framing Dimensions Chimney Size Wall Thimble & Support Brackets 5" 6" 7" 8" Minimum Round Hole Diameter Section "...
  • Page 9 Installation Instructions Model TLC All-Fuel Chimney - 5” to 8” METHOD A per requirements. below the prepared wall thimble opening, See Table 4 Section B and Figure 12 (B). 6. Install an appropriate Insulated chimney length such For concrete block or poured foundation, use suitable as a one foot (or longer if required, not to exceed fasteners.
  • Page 10 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions 14. Use a nonhardening, high-temperature sealant first chimney length above the insulated tee and any (500°F) to seal around the horizontal chimney length additional wall band to be installed at 8-foot intervals where it enters through the exterior of the wall thimble above this point.
  • Page 11 Mark 5 or 6 points to give an outline of the hole. Remember that the hole will need 2” clearance to the The Model TLC cathedral ceiling support will support a chimney surface. Install an attic insulation shield if total of 38 feet of chimney, of which 15 feet of chimney space permits on the underside of the overhang.
  • Page 12 To improve adhesion to the Model TLC chimney, (i.e., bedroom, guestroom, etc.). It must also be installed degrease, clean, and prime before painting. Follow the when height restrictions will not allow the use of the attic paint manufacturer’s instructions.
  • Page 13 This will extend its life and improve the appearance. The chimney may be painted also with a HEAT-RESISTANT paint. To improve adhesion to the Model TLC chimney, degrease, clean, and prime before painting. Follow the paint manufacturer’s instructions. Continue adding chimney lengths until the proper height is achieved.
  • Page 14 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions Roof Guy Installation properly and to avoid smoldering fires. Fast, effective start- ups are important, as is the moisture content of the wood If the chimney extends 5 feet or more above the roof being burned.
  • Page 15 If a chemical cleaner is used to assist in the cleaning 6. After a chimney fire, when it is safe to do so, check of your Model TLC chimney, make sure it is a product internal locations, such as the attic and under the roof, that is noncorrosive.
  • Page 16 12" 18" 24" 36" Notes: Notes: • Model TLC chimneys are limited to offsets not exceeding 30°. Combining offsets for greater angle is • Model TLC chimneys are limited to offsets not not permitted. The 45° elbows may be used only exceeding 30°.
  • Page 17 Installation Instructions Model TLC All-Fuel Chimney Installation Instructions Model TLC All-Fuel Chimney Chart 2 - CHIMNEY HEIGHT ABOVE THE ROOF Chart 2 - CHIMNEY HEIGHT ABOVE THE ROOF Requirement #1: The code requires that the chimney must extend at least 3 feet above the highest point of Requirement #1: The code requires that the chimney must extend at least 3 feet above the highest point of the roof that it penetrates.
  • Page 18 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions Model TLC All-Fuel Chimney - 5" to 8" Installation Instructions Chart 3 - CONNECTOR PIPE CLEARANCE BELOW CATHEDRAL SUPPORT Chart 3 - CONNECTOR PIPE CLEARANCE BELOW CATHEDRAL SUPPORT 1. Identify the type of connector pipe you will be installing.
  • Page 19: Replacement Parts List

    6/12-12/12 Roof Flashing *TLCF12 Locking Band *TLCLB Storm Collar *TLCSC *Specify chimney size. *Specify chimney size. Model TLC chimney and components are listed to UL103HT. Model TLC chimney and components are listed to UL103HT. Hart & Cooley, Inc. Hart & Cooley, Inc.
  • Page 20: Limited Lifetime Warranty

    Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions Limited Lifetime Warranty Model TLC Chimney & Venting Products Hart & Cooley, Inc. (“Hart & Cooley,” “we,” “us,” “our”, “its”) warrants its products to be free from defects in material and workmanship for as long as the original consumer owns the system.
  • Page 21 Chart 2 - Chimney Height Above the Roof ..................17 Chart 3 - Connector Pipe Clearance Below Cathedral Support ............18 Replacement Parts List ........................19 Limited Lifetime Warranty........................20 Model TLC Chimney & Venting Products ......................20 Limitations ................................20 Warranty Coverage ...............................20 Claim Procedure ..............................20 Installation Information Form ......................24...
  • Page 22 Model TLC All-Fuel Chimney - 5” to 8” Installation Instructions NOTES Hart & Cooley, Inc.
  • Page 23 Installation Instructions Model TLC All-Fuel Chimney - 5” to 8” NOTES Hart & Cooley, Inc.
  • Page 24 Model TLC All-Fuel Chimney Installation Instructions INSTALLATION INFORMATION FORM Keep in a safe place for future reference. Chimney Model: _________________________________________________________________________ Type of Appliance: ______________________________________________________________________ Installation Date: ________________________________________________________________________ Description of Installation (chimney and stovepipe configuration): ______________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ PURCHASED FROM Dealer Name: ___________________________________________________________________________...
