- Page 1 Flush Mounting Instructions TitanPower-ALDH40-PS Solar Thermal Collectors...
- Page 2 TitanPower-ALDH40-PS Collector Installation Manual Number of Solar Collectors in Series Quantity Quantity Component SKU Description Req. Req. Simpson Strong ConnectMaxx- drive screw 1/4" TRHW- diamx4.5 in _25x4_5INLAGSET length Machine Screw: ConnectMaxx-Roof 5/16"-18 Hook Clamp Base Thread, 1" Plate-Bolt Length Lock Washer: ConnectMaxx-Roof 5/16"...
- Page 3 TitanPower-ALDH40-PS Collector Installation Manual ConnectMaxx- Socket Head Cap TRHW-M8X25MM screw M8x25 ConnectMaxx- Flange Lock Nut A2 DIN 6923 M8 TRHW-M8NUT ConnectMaxx- Flush Mount TRTP-Roof Hook Roof Hook Clamp-FM Clamp Flexible ConnectMaxx- stainless steel TPALDH29- connector w/2 2, 8 2X-2, 4X FlexConnect clamps and 4 O-rings...
- Page 4 TitanPower-ALDH40-PS Collector Installation Manual Standard Roof ConnectMaxx- Mount TRUV-RHFLASH Flashing, Aluminum Figure 2. Pre-drill Lower Mounting Holes Figure 1. Upper Roof Hook Clamp Step 1: Pre-assemble the upper roof hook Step 2: Pre-drilling holes for lower roof hook clamps. Locate the clamp in Fig.
- Page 5 TitanPower-ALDH40-PS Collector Installation Manual and 5/16” hex nut, and 5/16” screw size deep. Roof hook clamps should be spaced a maximum of 48” in lock washer to attach the base plate to the the horizontal direction (see Reference Diagram 1). Distances roof hook clamp.
- Page 6 TitanPower-ALDH40-PS Collector Installation Manual Figure 6. The roof hook clamp should be placed under Figure 5. Roof flashing is placed over roof hook clamp to shingles as shown. prevent water from leaking through roof penetrations. Step 5: Place roof flashing over the lower roof hook Step 6: Cut overhanging shingles if necessary to clamp.
- Page 7 TitanPower-ALDH40-PS Collector Installation Manual Figure 10. Collector header connection mechanism Figure 9. Bolting the upper roof hook clamp Step 9: Bolt the upper roof hook clamp into the rafters and Step 10: Attach the flexible hydraulic apply the flashing as specified in step 5 and 6. When the connectors to the headers with the O-rings flashing doesn’t obstruct the shingle, the shingle does not and clamp.
- Page 8 TitanPower-ALDH40-PS Collector Installation Manual Figure 11. Securing the second collector to the roof hook clamp Figure 12. Repeat the upper mounting mechanism for the second collector Step 11: Slide the second collector’s lower lip into the lower roof Step 12: Slide the upper roof hook clamp into hook clamp.
- Page 9 TitanPower-ALDH40-PS Collector Installation Manual Figure 17. Install bracket connectors Figure 18. Lag bolt the upper roof hook clamp Step 14: Insert the connection bracket between the two collectors and secure the Step 15: Bolt the upper roof hook clamp in for the second bolts at both the bottom and the top of the collector and install the roof flashing.
- Page 10 TitanPower-ALDH40-PS Collector Installation Manual Figure 19. The roof flush mount finished product. Step 14: The product should look like the image shown in Fig. 19.
