Homebase Pebble Firepit Assembly Instructions Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

GB/WARNING
Accessible parts may be very
hot. Keep young children
away.
Use
outdoor
Read the instructions before
using the appliance.
IMPORTANT
Please check the pack contents before attempting to assemble this firepit. A full list of parts is given
on the page 3, also directions on what to do if there are damaged or missing parts. The Batch Code
Number can be found on the carton close to the Bar Code. Please retain this information for any
future reference.
CAUTION
Use outside only. Never use firepit inside or in confined space or under canopies or trees.
Do not use or pour petrol, methylated spirits or paraffin onto burning coals.
Locate on a firm and level surface, away from wooden fences, shrubs, trees, sheds.
Do not use on decking unless a heat resistant screen is used between the decking and the
firepit
Ensure there is at least 1 metre clearance around all sides of the Firepit when in use.
Refer to enclosed food safety instructions before beginning to cook.
This Firepit may get very hot. Keep small children and pets clear of cooking area.
An adult should always be in charge of the firepit.
Do not move the Firepit when in use or when still hot.
When adjusting or handling the firepit, it is advisable to use heat resistant gloves.
TOOLS REQUIRED
Homebase Limited.Avebury, Milton Keynes, MK9 2NW
Tel: 0845 0778888
www.homebase.co.uk
Assembly Instructions
only.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pebble Firepit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Homebase Pebble Firepit

  • Page 1 An adult should always be in charge of the firepit. Do not move the Firepit when in use or when still hot. When adjusting or handling the firepit, it is advisable to use heat resistant gloves. TOOLS REQUIRED Homebase Limited.Avebury, Milton Keynes, MK9 2NW Tel: 0845 0778888 www.homebase.co.uk...
  • Page 2 Arrangements will be made to obtain a replacement part; unfortunately it is not practical to send large items by post. If any fittings are damaged or missing please contact Homebase Ltd on 0845 0778888 You will need to have the following information available: Your name &...
  • Page 3 PARTS CONTENTS BASE BODY MESH BRACKET ASH DRAWER ASH DRAWER RAIL FIRE BOWL MESH LID MESH LID LOOPED LINK GRILL 4 PACKS PEBBLE POKER COVER...
  • Page 4 FIXING SHOWN ACTURAL SIZE 2 2 2 2 6mmx16mm BOLT 6 6 6 6 WING NUT 4 4 4 4 6mmx16mm WING BOLT Assembly Instruction STEP 1. Fit the ash drawer rail (E) into the base(A) . STEP 2. Insert the ash drawer(D) to the base (A). STEP 3.
  • Page 5 and wing nut (S2). STEP 4. Place the mesh bracket (C) on the body (B). STEP 5.Place the fire bowl (F) onto mesh bracket (C). STEP 6. Put the grill onto fire bowl (F).
  • Page 6 STEP 7. Put the pebble (J) evenly onto the mesh bracket (C) STEP 8. Assemble the mesh lid handle(H) onto to the mesh lid (G) by using bolt (S1) and wing nut (S2) as shown in diagram. Now your firepit is ready.
  • Page 7 To avoid risk of injury all bolt ends should be fastened on the inside of the Firepit LIGHTING AND USE INSTRUCTIONS 1.Place a layer of Homebase Charcoal or Charcoal Briquettes in the firebowl. Do not exceed the height of the rim 2.Arrange the charcoal into a pyramid and use Homebase Firepit Lighting Cubes or Fluid to ignite the...
  • Page 8 ! Attention! This barbecue will become very hot, do mot move it during operation ! Do not use indoors ! Caution! Do not use spirit, petrol or comparable fluids for lighting or re-lighting ! Warning! Keep children and pets away...
