Summary of Contents for Sun Microsystems SUN-SG8SCS
- Page 1 SUN Group Smart Cloud Signage USER’S MANUAL Model No. SUN-SG8SCS...
-
Page 2: Using This Manual
Using this manual Congratulations on your purchase of this Smart CS (Cloud Signage) -BOX which is a powerful and popular home entertainment device. Your LCD/LED or CRT TV will become a current fashionable smart CS and TV after connected to this box. This box builds on Google Android operating system，With integrated wireless access and tens of thousands free Android application programs, you can watch TV and films in local devices or internet, play game, listen music, browse internet... -
Page 3: Table Of Contents
Contents ASSEMBLING ............................3 ..............................3 NPACK ........................3 ET TO KNOW YOUR DEVICE TV ............................4 ONNECT TO GETTING STARTED ..........................5 ........................... 5 URN ON AND TURN OFF ............................ 5 OW TO OPERATE ........................5 ETUP FOR USING FIRST TIME ENTERTAINMENT ............................ -
Page 4: Assembling
Assembling Unpack Check your product box for the following items： • Smart TV-BOX • Power adapter • USB BlueTooth Dongle 1pc（ option） • Air mouse or 2.4G mouse 1pc（ option） • HDMI cable 1pc（ option） • AV line • User’s manual 1pcs Get to know your device •... -
Page 5: Connect To Tv
① USB interface ② Video and L/R output ③ HDMI output interface ④ RJ-45 network interface ⑤ Power adapter interface • Left side • Right side SD/MMC CARD Connect to TV 1. For LCD/LED TV, connect with HDMI cable. For getting best display effect, it is recommended connect to LCD/LED TV . 2. -
Page 6: Getting Started
3. Connect the power adapter to AC power source and the device. AC power voltage： AC 110/220V 50/60HZ Output of power adapter：DC 5V/2A Please pull out the power adapter when the device is not in use. Getting started Turn on and turn off Connect the power adapter to AC power source and the device ,the device will ●... - Page 7 （2）Select【Language & input】in item list on screen left side. （3）Select【Language】in item list on top screen and then select the language which you want. （4）Press【 】one time or【 】several times to go back to main menu. Network settings ● 1. When using Ethernet, please insert the cable plug to RJ-45 interface of the device.
-
Page 8: Entertainment
（3）Select one of the WI-FI network which you want to connect, The dialog box will appear on screen, input the password and then select 【connect】. （4）The indication note“connected” will appear under the name of network if no problem. （5）Press【 】one time or【 】several times to go back to main menu. - Page 9 （2）Select the video file which you want to play. From the internet: （1）Input and enter into a website,select【Video】. （2） Input the key words about the video which you’re interested in,and Click 【Search】 . （3）Select the videos which you want to play.
-
Page 10: Play Game
（4）Press【 】one time or【 】several times to go back to main menu. You can also change the link application of “watch TV” yourself. Play game （1）Select the game which you want to play in main menu.For example:Angry Birds. （2） The device will open the game application default linked, you can enjoy the funny game immediately. -
Page 11: Install From App Market
Install from APP market （1）Install an APP market application in device, for example, “Google Play Store”. （2）Open the APP market application in main menu . （3） Before you enter “Google Play Store” ,you are required to login a Google account. （4）If you login successfully,you can install any free application from among tens of thousands applications in APP market. - Page 12 （5）Press【 】one time or【 】several times to go back to main menu after uninstall.
-
Page 13: Specification
Specification Hardware Processor ARM Cortex A9 Freq 1.4GHz*2 Open GL ES2.0 3D processing DDR3 Storage 16GB Nand Flash Interface Video Output HDMI v1.3 up to 1080p@60Hz) / CVBS Audio Output HDMI v1.3 / Audio L,R Ethernet RJ45(10/100Mbps) LAN Wireless IEEE 802.11 b/g/n USB Host USB 2.0 host x 4 Card Reader...
