Page 1: Power Amplifier
The Director ® Model D4400 Model D3400 16 Channel High Efficiency • Digital Signal Processor • Ethernet Interface & Control Power Amplifier Professional Installer’s Gratification Guide ® Making Good Sound Great 22410 70th Avenue West • Seattle, WA 98043 USA 425-775-8461 •... -
Page 2: Important Information
Important Information Dealer Name _____________________________________ Date Installed __________________________________ Serial Number ___________________________________ Ethernet MAC Address _________________________ IP Address Dynamic / Static ___________________ ®... -
Page 3: Table Of Contents
Table of Contents Table of Contents The Director Model D3400 • Model D4400 Cool and Different Features ......2 A Guided Tour Front Panel . - Page 4 Table of Contents Advanced Topics Speaker and wiring impedance ....28 Amplifier bridging ......29 In wall volume controls .
- Page 5 Introduction Introduction To label The Director Models D4400 and D3400 just ® multi-zone amplifiers is like calling a Ferrari just a car. There is so much more to both products in terms of performance and capability. Ethernet control, unparalleled energy efficiency, rack saving compact design, superb sound quality and bulletproof reliability are just a few key features of The Director.
-
Page 6: Cool And Different Features
Cool & Different Features Cool and Different Features Volume Control The primary focus of our latest firmware is volume control via browser or Telnet commands. You can now control volume in any zone! Control via the browser will allow you to control volume in any zone along with EQ and source selection. - Page 7 Cool & Different Features • E : Via a browser or Telnet commands thErnEt ontrol you can control and query almost all the functions of The Director. You can mute zones, change source inputs, adjust equalization, recall memories, check line voltage, display pro- tection logs and get an email if something goes wrong.
- Page 8 Really Cool Stuff in The Director As great as these features on the previous page are, here is a list of some of the new and unique parts of The Director; • o lEd: Ever wonder if there really was UtPUt rESEnt a signal on the speaker outputs of an amp? No wondering...
-
Page 9: A Guided Tour
A Guided Tour Of The Director Model D3400 / D4400 Front Panel Zone Status LEDs - At the bottom of the Power LED - Starting with the easy one... columns are the channel status LEDs which when you have the AC Power switch on the are dual color and serve two purposes. -
Page 10: Rear Connections
A Guided Tour Of The Director Model D3400 / d4400 Rear Panel on each amplifier zone, or the ethernet con- trol, selects which input is playing in that specific zone. For Bus 1, the second pair of Ethernet LAN Connection - Plug The jacks can be used to daisy chain to another Director into a 10BaseT network here. - Page 11 A Guided Tour Of The Director Model D3400/ D4400 LED) of only this zone. To bridge two channels, Master Power Switch - This switch controls this button must be in. the main AC power. Since The Director draws only a few watts during standby, the only time Speaker Outputs - Cool terminal blocks which you need to turn the master power off is if the are designed to make an installer smile.
-
Page 12: Making Sense Of The Trigger Ins And Outs
Guided Tour - Trigger Ins & Outs Making Sense of the 12 Volt Triggers The Director has five ways you can bring the unit from standby to on and ready to serve. In addition, you can use the triggers from The Director to turn on more units of The Di- rector or other components as well. -
Page 13: Internet Connectivity And Control
Internet Connectivity and Internet Connectivity and Control Control Setting up The Director Model D3400 or D4400 is a breeze. Just plug it into an existing network and let the Important Note: DHCP server assign The Director amplifier an IP address. If you are connecting multiple The Director amplifier will then show up in your network units on a network, The Directors... - Page 14 Internet Connectivity and For Apple/Mac Desktops and Laptops: Control Apple does not support UPnP device discovery. Your easiest method for connecting with a Mac is to directly con- nect to The Director amplifier. The default IP address of The Director amplifier is 192.168.0.249 so in order to connect to The Director, you will need to give your computer a static IP address.
- Page 15 Internet Connectivity and Operation Tab Control The first page you see when connecting to The Director the first time via a web browser will be the Operations page. The functionality and controls on this page are described below: Groups: Grouping allows for channels to be grouped for control via telnet for simple efficient operations.
- Page 16 Internet Connectivity and Configuration Tab Control In the Configuration tab, you can rename the amplifier, rename each channel pair or Zone, set the global networking parameters of The Director, Export your Signal Processing and Configuration data and Import EQ settings previously Note: Rear Panel switches on The Exported from another Director amplifier in the system or Director can override the Ethernet...
- Page 17 Internet Connectivity and Signal Processing Tab Control Graphic equalization is by individual zone and with both channels within that zone paired by default. You can “unlock” the zone/channel pair by clicking the “Unlock” checkbox for each respective band. You also have the option of setting the EQ curve globally for The Director by enabling the “All Zones”...
-
Page 18: Control And Queries Via Telnet
Internet Connectivity and Being that you can pull a large amount of power – up to Control 100 watts! – from each and every channel from The Director Model D4400 (65 watts with The Director Model D3400), you just might want to use a sub in one of the bigger rooms No problem at all –... -
Page 19: Control Commands
Internet Connectivity and Example to turn zones 3, 5 and 6 off from an all channels Control on state: Command: mute 3 5 6 <cr> Query: mute? <cr> Response: 0,0,1,0,1,1,0,0 Note: The query “mute?” yields a description of the mute/ off state across all channel pairs/zones;... -
Page 20: Inquiry Commands
Internet Connectivity and Inquiry Commands Control volume_set? Returns volume level for zones 1-8 Example: Returns 11 11 13 57 47 65 49 51 Zone 5 then is set to 47 mute? Returns which zones are muted unmute? Returns which zones are unmuted bus1? Returns which zones are switched to bus#1... -
Page 21: Operation Without An Ethernet Connection
Internet Connectivity and Logging Format Control In response to a logging inquiry (log?), The Director will respond with the most recent fifty events. The format of the logged response is: EECCYYYYMMDDHHMMSS where E= event code, C=zone, Y= year, M= month, D= day, H= hour, M= minute and S=second. -
Page 22: Hook-Up Guide With System Diagrams
Hook Up Guide - System Diagrams Using Bus Inputs to Create Larger Zones ®... - Page 23 Hook Up Guide - System Diagrams Whole House System with Tuner Only Background Music TheDirector ® Model D3400 • Model D4400 Installer’s Guide...
- Page 24 Hook Up Guide - System Diagrams Multiple Unit System with • Tuner Only Background Music • Tuner Triggered on • Daisy Chained Bus 1 ®...
- Page 25 Hook Up Guide - System Diagrams Using the Crossover Option TheDirector ® Model D3400 • Model D4400 Installer’s Guide...
-
Page 26: Room Acoustics
Room Acoustics Acoustics Magazine reviewers and audio system owners spend much time critically appraising speakers and other audio compo- nents. Unfortunately, a phenomenon that has a very large effect upon sound is not easily judged or changed. That effect is the ACOUSTICS of the environment in which you are listening. -
Page 27: Benefits Of Equalization
Equalization Benefits Another set of variables is the shape and volume of your listening room. Large rooms require more bass energy to excite waves within them. Small rooms need less energy, but reflect it differently. And then there’s the fact that most rooms don’t have four walls anymore, but open into dining rooms, lofts, cathedral ceilings, etc. -
Page 28: Adjusting The Signal Processing
Adjusting the Signal Processing Adjusting the Signal Processing Equalizing the System Before proceeding on equalizing the system, it is a good idea to make sure everything is connected and working prop- erly. You know how to check connections and here are some reminders specific to The Director, as well as the steps to equalize. -
Page 29: Parametric And Graphic Equalization
Adjusting the Signal Processing Parametric and Graphic Equalization The graphic equalization controls in The Director are se- lected to correspond with the characteristics of wall and ceil- ing speakers and as such are very effective. Graphic controls are the easiest to tune and provide a “graphic” representation of what the adjustments are. -
Page 30: Subsonic And Tweeter Protection Filters
Adjusting the Signal Processing are found in this range. If accentuated too much (by boosting this control) sounds in the 2500Hz range can seem harsh and fatiguing to the ear due to excessive output by the speaker or because of live, reflective room acoustics. 12kHz —... -
Page 31: A Brazen Plug
Brazen Plug A Brazen Plug For Other AudioControl Products AudioControl started out making graphic equalizers in 1977. Our heritage and design experience grew from a back- ground in professional audio, so we were never quite satis- fied with what was available for the consumer audio market. Since that time, we have continued to expand our product offerings to become a key part of great home audio and video systems. -
Page 32: Speaker And Wiring Impedance
Advanced Topics Advanced Discussions Speaker & Wiring Impedance Speaker impedance often is and should be straight for- Calculating Impedance ward. Speakers, like other resistors, wired in parallel “show” For three 8 ohm speakers wired in lower values than the individual components. In case you parallel (pluses connected to pluses) have forgotten, there is an example here for calculating speak- the impedance is... -
Page 33: Amplifier Bridging
Advanced Topics Bridging The Director To increase the output power of The Director Model D3400, you can join (bridge) two channels into a single chan- nel of 250 watts. Accomplishing this is a simple matter. Just press the Mono button to send the same audio signal to both Caution - Do not use a channels of the zone and then connect the speaker terminals speaker rated at less... -
Page 34: Installation Of Multiple Units Of The Director
Advanced Topics Installation of multiple units of The Director May you stack units of The Director on top of each other without an air space in between? The Director is a very energy efficient amplifier and emits little heat so air spaces between units, while always helpful, are not mandatory for a background music system. -
Page 35: Level Matching And Gain Controls
Advanced Topics The circumstances where The Director Model D3400 draws maximum power are very rare outside of an engineer- ing lab. Maximum power is using a sine wave input which has at least a third higher energy density than music. This would mean that all channels are operating at maximum, an unlikely situation even during a really fun party. - Page 36 Advanced Topics Commercial noise masking systems rely on “white noise” which sounds remarkably like a bathroom exhaust fan and like the sound of water in a shower-- both of which are louder than the background noise level in the other parts of the house.
-
Page 37: Troubleshooting
Troubleshooting Troubleshooting the Director Many problems can be eliminated by re-checking the wiring and settings of The Director amplifier. A variety of other subjects are discussed in Advanced Topics starting on page 27. If a problem cannot be solved using this information, please call the AudioControl factory or check at www.audio- Install Tip - There are control.com. - Page 38 Troubleshooting you are using an in-wall volume control, please see Advanced Topics for more information. 4. Speaker channels are cutting in and out: Warning - Always connect a. If using in-wall volume controls, check that they can the safety earth ground. handle the power output.
-
Page 39: Warranty And Service Information
Warranty The Warranty People are scared of warranties. Lots of fine print. Months Legalese Section of waiting around. Well, fear no more. This warranty is de- This is the only warranty signed to make you rave about AudioControl. It’s a warranty given by AudioControl. - Page 40 What to do if you need service What to do if you need service First, contact AudioControl, either by e-mail, phone or FAX. We’ll determine if there is anything wrong that you can fix yourself, or if it needs to be sent back to our factory for repair.
-
Page 41: Block Diagram
Block Diagram TheDirector ® Model D3400 • Model D4400 Installer’s Guide... -
Page 42: Specifications
Specifications The Director® Specifications .......The Director Model D3400 ..The Director Model D4400 Power Output Number of Channels . - Page 44 ® For Those Who Consider Perfection Possible ® 22410 70th Avenue West Mountlake Terrace, WA 98043 USA 425-775-8461 • Fax 425-778-3166 e-mail: sound.better@audiocontrol.com Visit us on the web at www.audiocontrol.com P/N 913 099 Rev. B...
-
Page 45: Important Note
Supplement New Features in the Director! We have added volume control to the latest firmware for our Director series amplifiers. Via the browser you can now control volume in any zone along with EQ and source selection. With the updated Telnet control, you have the means to control the Maximum On volume so that when you turn the unit on volume is set to a predefined value.
