Summary of Contents for oConnor C1242-0001
- Page 1 O-Focus DM Photo Set O-Focus DM Cine Set C1242-0001 C1242-0002 User Guide...
-
Page 2: Caution
DO NOT attempt to move the camera by pulling on the O-Focus Ÿ DM handwheel. AVOID overtightening the drive gear onto the lens focus drive. Ÿ ALWAYS use genuine OConnor parts and accessories with the Ÿ O-Focus DM. ALWAYS dismantle when not in use and before transporting. Ÿ... -
Page 3: Table Of Contents
OConnor Offices worldwide........ - Page 4 The O-Focus DM Cine...
-
Page 5: The O-Focus Dual Mini
Features and benefits of your new O-Focus DM The O-Focus Dual Mini, the latest addition to the range of genuine accessories from OConnor, offers a host of inspired and productive features: Ÿ the double-sided follow focus is constructed of lightweight, durable black anodized aluminum Ÿ... -
Page 6: O-Focus Dm Photo
Specification O-Focus DM Photo Set (C1242-0001) Weight of unit (incl. LWS rod bridge, handwheel) ....1.23 lbs (0.56 kg) Weight of bridges (excl. handwheel)....... 0.73 lbs (0.33 kg) Dimensions (excl. -
Page 7: In The Box
Handwheel C1242-1300 C1242-1100 15 mm LWS rod bridge C1241-1540 Gear Z60 Gear Z35 C1241-1900 C1241-1700 Matching OConnor accessories: Marking Discs Gear Z43 Studio rod bridge (conical, 10 pack) C1241-1600 C1241-1100 (depending on lens) C1242-1530 Handwheel (for double-sided use) C1241-1100 (Cine) -
Page 8: O-Focus Dm Cine
Specification O-Focus DM Cine Set (C1242-0002) Weight of unit (incl. LWS rod bridge, handwheel) ....1.52 lbs (0.69 kg) Weight of bridges (excl. handwheel)....... 0.73 lbs (0.33 kg) Dimensions (excl. -
Page 9: In The Box
O-Focus DM (full-size offset knob) Main bridge C1241-1100 C1242-1300 15 mm LWS rod bridge C1241-1540 Gear Z60 Gear Z35 Matching OConnor accessories: C1241-1900 C1241-1700 Marking Discs Studio rod bridge Gear Z43 (10 pack) C1241-1300 (depending on lens) C1241-1600 C1241-1530 Handwheel (for double-sided use) -
Page 10: Components
Components Part no. Gear size Lens type index C1241-1700 35 tooth 0.8M 10 mm face Cine eccentric C1241-1600 43 tooth 0.8M 6 mm face Cine CINE handwheel C1241-1800 50 tooth 0.6M 7.5 mm face Canon ENG focus C1241-1900 60 tooth 0.5M 7.5 mm face Fujinon ENG focus C1242-1001 Ø39 mm surface... - Page 11 Components index screws O-Focus DM Photo C1242-0001 lock lever lock lever main bridge bridge interlock (with output gears) driver gear lock lever witness marker centric hard-stop handwheel hard-stop slider button LWS rod bridge lock lever (rod bridge) flip-lock rod clamp screw...
-
Page 12: Assembling The Bridge
Assembly – assembling the bridge Double-sided design Front and back output gears Flip-lock rod clamp lever Assemble the bridges. Slide the LWS rod bridge onto Mount the driver gear. Choose a compatible driver the main bridge. Turn the lock lever clockwise to gear for your lens (see page 10). -
Page 13: Mounting The Handwheel
mounting the handwheel The O-Focus DM incorporates a Minimal Backlash Mechanism to guarantee precision focus pull with less play and higher accuracy. Note that the assembly instructions apply to both types of handwheel. Push-fit the handwheel firmly onto the main bridge. The handwheel must be fully engaged for the backlash- reducing mechanism to be effective. -
Page 14: Mounting Onto The Camera Rods
For more information about the focal length and diameter of a wide range of camera lenses visit OConnor Labs online at the OConnor website (OConnor > Labs > ‘Lens Diameters’). Mount the O-Focus DM to the lens focus drive. -
Page 15: Mounting The O-Focus To The Lens
15 mm or 19 mm studio camera rods (see page 10). For more information about different types of camera rods visit OConnor Labs online at the OConnor website (see OConnor > Labs > ‘Rod Standards Explained’). -
Page 16: Setting The Focal Distances
setting the focal distances Set the lens focal range for the O-Focus DM Photo. Using a suitable pen mark the reference points for the maximum and minimum focal distances. Hard stops prevent lenses with infinite rotation from being turned too far. The hard stops can also be used as hard focus points for run and gun shooting. - Page 17 setting the focal distances Set the focal distances for the O-Focus DM Cine. Using a suitable pen mark the lens focal reference points. The focus throw is optimized for cine lenses to provide a shorter, more exacting focus pull. focus pull Mount the marking disc.
-
Page 18: Options And Extras
Options and extras For larger camera packages the O-Focus DM can also be used with an optional 70 mm handwheel extension (see page 7 for details). The eye level of the eccentric CFF-1 studio handwheel can be adapted for optimal ‘line of sight’ and for reach. Handwheel extension (70 mm) Note: Adjust the handwheel index up or down... -
Page 19: Oconnor Offices Worldwide
OConnor Offices worldwide ASIA EUROPE HEADQUARTERS CHINA FRANCE 2701 N. Ontario St. Room 706, Tower B 171 Avenue des Gr sillons é Burbank, CA 91504 Derun Building 92635 Gennevilliers CEDEX YongAn Dongli A No. 8 France Tel.: +1 818 847 8666 Jianwai Ave. - Page 20 Connor ™ itec Group brand C1242-4980/1...
