HenryCare Wheel Chair Instructions
GENERAL GUIDE AND SAFETY INFORMATION
THIS INFORMATION IS APPLICABLE TO ALL MANUAL WHEELCHAIRS
IT SHOULD BE READ BY BOTH OCCUPANTS AND CARERS WITH ALL OTHER
INFORMATION SUPPLIED BEFORE ANYONE ATTEMPTS TO USE THE CHAIR
THE PURPOSE OF A WHEELCHAIR IS TO PROVIDE FUNCTIONAL MOBILITY FOR
PEOPLE WHO CANNOT, OR FIND IT DIFFICULT TO WALK.
Factors considered in selecting a wheelchair apply to both occupants and carers
and include:
•
•
•
•
•
•
•
•
•
•
Clinical Assessment teams have a responsibility to provide the wheelchair
occupant and carer, where applicable, with a means of acheiving effective
mobility, bearing in mind all the above considerations.
There are many different types and variations of wheelchairs available today. It
may not be possible to satisfy all requirements and environments with one chair
for every need of the occupant (and carer) for home, travel or work.
Source-remobility.net
MANUAL WHEELCHAIRS
method of propulsion
seating position
occupant size and weight
physical ability of occupant and carer ( where applicable )
ease of use
environment
safety
degree of independence
transportation
costs
Section 2 Index
Nov 1998 Rev 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Attendant Propelled and is the answer not in the manual?

Questions and answers

Summary of Contents for HENRY Attendant Propelled

  • Page 1 HenryCare Wheel Chair Instructions Section 2 Index MANUAL WHEELCHAIRS GENERAL GUIDE AND SAFETY INFORMATION THIS INFORMATION IS APPLICABLE TO ALL MANUAL WHEELCHAIRS IT SHOULD BE READ BY BOTH OCCUPANTS AND CARERS WITH ALL OTHER INFORMATION SUPPLIED BEFORE ANYONE ATTEMPTS TO USE THE CHAIR THE PURPOSE OF A WHEELCHAIR IS TO PROVIDE FUNCTIONAL MOBILITY FOR PEOPLE WHO CANNOT, OR FIND IT DIFFICULT TO WALK.
  • Page 2 Users should contact their approved distributor if they are having problem in using their wheelchair, a simple adjustment or alternative build configuration may help to resolve the problem. Remploy manual wheelchairs can be divided into three broad categories. • Attendant Propelled • Occupant Propelled • Pushchairs and Buggies This general information section covers safety issues of wheelchair use covering all of these.

  • Page 3: Side Transfer

    HenryCare Wheel Chair Instructions 2.1.2 GETTING IN AND OUT OF A WHEELCHAIR FACING FORWARDS Section 2 Index For maximum safety, these operations should be carried out with the help of an attendant. The occupant should always try to assist the attendant wherever possible to share the total effort.
  • Page 4 HenryCare Wheel Chair Instructions Section 2 Index Figure 1 - Getting in/out of the wheelchair Figure 2 - Side Transfer Figure 3 - Maintain a firm grip on the push handles Figure 4 - Attendant Control Source-remobility.net Nov 1998 Rev 2...

  • Page 5: Pushing Techniques

    HenryCare Wheel Chair Instructions 2.1.4 BRAKES Section 2 Index Hand brakes are provided for preventing wheel movement when parked, particularly on a slope, or during occupant transfer to and from the wheelchair. The action of a brake shoe pressing on the tyre makes correct inflation pressure important, see section 12.1.
  • Page 6 HenryCare Wheel Chair Instructions Fig. 5. going down a kerb start position make sure that the front end of the chair is lowered slowly to Fig. 6. the floor, and that the going down a kerb castors are pointing to finish position the rear.
  • Page 7 HenryCare Wheel Chair Instructions 2.1.6 KERBS Section 2 Index Negotiating a kerb. The methods described here involve an attendant controlling the operation. Active users adopt balancing techniques carry out kerb manoeuvres independently, but methods will vary according to the setting of the chair, the physical strength of the user and skills acquired through training and practice with wheelchair experts.
  • Page 8 HenryCare Wheel Chair Instructions Section 2 Index Figure 7 - Ensure that push handle locks are fully engaged before using Figure - 8 Detachable push handles must be inserted correctly Figure 9 - Going down/up a flight of steps Source-remobility.net Nov 1998 Rev 2...
  • Page 9 HenryCare Wheel Chair Instructions 2.1.7 STEPS & SLOPES Section 2 Index Where possible, the hazard of negotiating steps should be avoided. Modern public buildings should provide permanent wheelchair ramps, with a practical slope angle for safe access, loose ramps pushed against a kerb are not recommended.

  • Page 10: Occupant Controlled Mobility

    HenryCare Wheel Chair Instructions The fitting of the basic type of wheelchair seat belt is by looping the belt around the tubular upright backrest frame. The belt position is fixed at a point below occupant waist level, where it feels most comfortable, and held from sliding up and down the tube by the upholstery fixings.
  • Page 11 HenryCare Wheel Chair Instructions Balance Training Section 2 Index Physically active, independent people require wheelchairs which allow them to safely negotiate kerbs and achieve efficient control and manoeuvrability. It can be hazardous for an occupant to attempt wheelie positions on wheelchairs which are stable above 10 degrees rearwards static stability, as physical effort needed to manoeuvre and pull a wheelie can be excessive, consequently increasing the risk of accidentally tipping over backwards.
  • Page 12 HenryCare Wheel Chair Instructions 2.1,9 TRANSPORTATION Section 2 Index Wherever possible it is recommended that wheelchair occupants transfer to a vehicle seat during a journey, with the wheelchair securely stored separately in a purpose made storage area. Stowing the wheelchair in a car boot The folded chair should be placed close to the car boot with armrests, footrests and other removable parts detached to split total weight into component form.
  • Page 13 HenryCare Wheel Chair Instructions Section 2 Index Figures 13 & 14. A Sideways Folding wheelchair can be stored behind the front seat. Fig 15 Side view of Remploy Powerider tied down to floor of a vehicle using webbing restraints Note that separate occupant crash tested restraint is not shown in this view.
  • Page 14 HenryCare Wheel Chair Instructions 2.1.9 continued: Section 2 Index Guidelines for Wheelchair & Occupant Transportation in Vehicles This information is given in order to reduce the risk of bad practice. It is based on current available knowledge. Wheelchair users and transport operators have a responsibility to ensure that safety measures take account the needs of wheelchair occupants and other passengers to minimise the risks involved for each individual situation.

  • Page 15: Fire Precautions

    HenryCare Wheel Chair Instructions 2.1.10 FIRE PRECAUTIONS Section 2 Index DISABLED PERSONS ARE AT GREATER RISK THAN OTHERS IN THE ENVIRONMENT IN WHICH A WHEELCHAIR IS USED SHOULD INCORPORATE SAFETY PRECAUTIONS TO MINIMISE FIRE RISK When using the chair, both indoors and outside, always take precautions against fire risks.

  • Page 16: General Care And Maintenance

    HenryCare Wheel Chair Instructions 2.1.12 LOOKING AFTER YOUR WHEELCHAIR - Section 2 Index GENERAL CARE AND MAINTENANCE READ ALL INFORMATION PROVIDED BEFORE ATTEMPTING TO USE Users should not attempt major repairs or modifications. Approved Distributors have full Service Information and are able to advise if the chair becomes damaged, requiring major part replacement, or refitting.
  • Page 17 HenryCare Wheel Chair Instructions SERVICE CHECK LIST Section 2 Index Brakes The brake should hold the chair on a ramp angle of approx. 10 degrees. Try the chair on a slope or ramp which you may use. If necessary, have the brake is readjusted.
  • Page 18 HenryCare Wheel Chair Instructions REMPLOY HEALTHCARE GROUP Section 2 Index Distributed by : Other Approved Distributors : Source-remobility.net Nov 1998 Rev 2...
