Addonics
T E C H N O L O G I E S
Ruby Mobile Rack
RMRSAI & RMRSASC
User's Guide
FCC Warning Statement
This equipment has been tested and found to comply with the limits for a class B digital
device pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy. If not installed and
used in accordance with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If the equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment on and off, the user
is encouraged to try and correct the interference by one or more of the following
suggestions.
Reorient or relocate the receiving antenna
Increase the distance between the equipment and the receiver
Connect the equipment to a different power outlet other than the one where receiver is
connected
Consult a certified television or radio technician
Version 1.0
Enclosure Overview
2.5" SATA
hard drive
Step 1 Separate the top from the bottom cover of the drive enclosure by
loosening the screw as shown on the photo.
Step 2 Align the SATA connector in the 2.5" hard drive with the SATA connector
on the PCB.
Step 3 Wrap the shock absorbers around the hard drive and PCB.
top cover
shock
absorbers
switch
PCB
bottom cover
Advertisement
Table of Contents
Related Manuals for Addonics Technologies RMRSAI
Summary of Contents for Addonics Technologies RMRSAI
- Page 1 2.5” SATA hard drive switch Ruby Mobile Rack RMRSAI & RMRSASC bottom cover User’s Guide Step 1 Separate the top from the bottom cover of the drive enclosure by loosening the screw as shown on the photo. Version 1.0...
- Page 2 Step 4 Turn over the PCB and secure the hard drive to the PCB with the Ruby Enclosure mounting screws that come with the kit. Switch Power LED and Drive Access LED Switch: INT: This mode is used when the enclosure is placed inside a drive cradle.
- Page 3 Model: RMRSAI Model: RMRSASC This Ruby model will not hot-swap. Slide the Ruby enclosure inside the cradle This Ruby model will not hot-swap. Slide the Ruby enclosure inside the cradle and then place switch on INT position before the system can be turned ON.
- Page 4 OPERATING SYSTEM – What version of Windows WHAT’S THE TROUBLE? – Give enough information about your problem so that we can recreate and diagnose it. FREE Software Drivers for all Addonics Technologies Products are available 24 hours per day at the World Wide Web Site: www.addonics.com.
