Chapter 2 Connecting Mechanism

2.1 Introduction

The Powerline Adapter supports up to 500Mbps data rate. With this high speed connection rate, this
Powerline Adapter allows you to setup a high speed home network by using your home existing
electrical wiring. Simply plug this Powerline Adapter into an ordinary power outlet to extend your
Cable/xDSL broadband connection or existing LAN network to any other electrical outlet in any rooms of
your house.
Note that this Powerline Adapter works in pairs. You need to plug one Powerline Adapter into a power
outlet for each computer (Connect to the computer LAN card) you want to connect (Network access);
you will also need another Powerline Adapter connected to your Cable/xDSL broadband (Ethernet port)
in order to extend your broadband connection or Internet surfing. With clean powerline, the distance
between two Powerline Adapters can reach 300 meters at lease, but the actual distance may vary due
to the environment.
Section below describes the Powerline Adapter's LED indicators, physical interface and hardware
connection mechanism.

2.2 LED Indicator

The LED indicator displays information about the device's status.
Item
Power LED
Status
On
The adapter is on.
The adapter is in power-saving mode or in pairing
Blinking
procedure.
Off
The adapter is off.
4
TL-PA411
AV500 Powerline Adapter
Indication
