  • Page 1 USER MANUAL VERSION V1.4 DECEMBER 2010 Point-of-Sale Hardware System...

  • Page 2: Important Safety Instructions

    Copyright 2010 All Rights Reserved Manual Version 1.4 Part Number: 3LMPP7900214 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 3 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 4: Legislation And Weee Symbol

    LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.

  • Page 5: Revision History

    Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release 2007 August • Cover page update • System View update • System Installation update 2007 December • System Disassembly update • Specification update •...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ......1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ..........2 2. System View ......3 2-1. Front View ...............3 2-2. Side View ..............3 2-3. Rear View with stand ..........4 2-4. Rear View without wall mount bracket .....4 2-5.
  • Page 7 4-6. SSD Card Replacement .........15 4-6-1. On a Fan System ............ 15 4-6-2. On a Fanless System ..........16 4-7. Cash Drawer Installation ........17 4-7-1. For B78 motherboard ..........17 4-7-2. For B68/B98/C48 motherboard ....... 19 5. Specification ......21 6.

  • Page 8: Packing List

    Packing List 1-1. Standard Accessories System (with stand) Driver bank User guide Power adapter Power cord RJ45-DB9 cable (x2)

  • Page 9: Optional Accessories

    1-2. Optional Accessories Metal MSR Metal VFD Wall-mount Kit SSD module WLAN Card (with internal antenna)

  • Page 10: System View

    System View 2-1. Front View 2-2. Side View Fanless System Fan System Item No. Description Touch Screen MSR Module (Optional) External Antenna (Optional) Hinge Cover for stand installation Stand...

  • Page 11: Rear View With Stand

    2-3. Rear View with stand Fan System Fanless System 2-4. Rear View without wall mount bracket Fan System Fanless System Item No. Description VFD (Optional) HDD Door for fan system Ventilation for fan system Cable management outlet VESA hinge bracket I/O ports cover...

  • Page 12: I/O Ports View

    2-5. I/O Ports View Fan System d e f g Fanless System d e f g Item No. Description Parallel USB x 4 COM 1, 2, 3, 4 (from right to left) Line-out MIC-in Cash Drawer (12V or 19V, can support 24V) Power Switch DC-In PS/2...

  • Page 13: System Dimension

    2-6. System Dimension 15" System 17" System 411 mm 386 mm 220 mm 220 mm 80 ° 80 ° 250 mm 250 mm...

  • Page 14: System Assembly

    System Assembly To remove and replace the HDD, please follow below steps. The procedures may be different depending on the fan or fanless system being installed. 3-1. HDD replacement for fan system Turn to the rear side of the system. Unscrew the screw (x1) securing the HDD door and the rear cover of the system.

  • Page 15: Ram Replacement

    3-3. RAM Replacement Please open the rear cover (see Chapter 3-1 or 3-2) first then remove and replace the RAM module. You can refer to the motherboard layout to find the memory compartment. (See chapter 6 for different motherboard) Removing a RAM module Please Open the rear cover by unfasten the screws (x17) to access the motherboard.

  • Page 16: Power Adapter Replacement

    3-4. Power Adapter Replacement Disconnect the power cable from the adapter pre-installed in the power bracket attached in the stand. Unscrew the screws (x2) and separate the power bracket from the stand. Disconnect the other end of the power adapter from the connector on the I/O panel.

  • Page 17: Peripheral Installation

    Peripheral Installation 4-1. MSR Installation Unfasten the thumb screws (x2) to remove the I/O cover. Connect the MSR module into the system and fasten the screws (x2). Connect the PS/2 Connector into the PS/2 port on the I/O panel. Note: the PS/2 port locates in different places on the I/O panel according to the fan or fanless system being installed.

  • Page 18: Wall Mount Kit Assembly

    4-3. Wall Mount Kit Assembly Accessories items a. Metal bracket with thumb screw b. Screw x 1 c. Wall mount bracket Fix the metal bracket (a) to the VESA bracket and the display with the screw (b) (x1). Align the tear drop holes of the wall mount bracket (c) into the 4 VESA bracket screws.

  • Page 19: Desktop Stand Assembly

    4-4. Desktop Stand Assembly Accessories items a. VESA bracket b. Stand bracket c. Stand d. Hinge cover x2 e. Screws for both sides of stand x6 f. Screws for VESA bracket x 4 VESA bracket assembly Align the standard VESA mounting holes of the VESA bracket (a) and the display and fix them with the screws provided (f) (x4).

  • Page 20: Wireless Lan Installation

    4-5. Wireless LAN Installation 4-5-1. On a Fan System Disconnect the HDD cable from the system first (see Chapter 3-1). Unscrew the screws (x17) to remove the rear cover (a). Assemble the antenna cable (b) by fasten the nut, washer and the coaxial cable as picture instructs.

  • Page 21: On A Fanless System

    4-5-2. On a Fanless System For installing the external antenna and the wireless LAN card for fanless System, please see below pictures and instructions. Open the rear cover by removing the screws (x17) Fix the antenna mounting bracket (b) with the screw (x1) onto the LCD chassis under the rear cover.

  • Page 22: Ssd Card Replacement

    4-6. SSD Card Replacement If your system equipped with SSD Card instead of hard drive disk as storage device, please follow below steps to replace the SSD card. 4-6-1. On a Fan System 1. Fasten the screw(x4) on the rear side of the SSD holder bracket to fix the SSD card.

  • Page 23: On A Fanless System

    4-6-2. On a Fanless System 1. Follow 4-6-1 step 1 to assemble SSD module. 2. Turn to the rear side and open the rear cover on a fanless system (see Chapter 3-2). 3. Fasten the screw (x4) as shown to fix the SSD module.

  • Page 24: Cash Drawer Installation

    4-7. Cash Drawer Installation 4-7-1. For B78 motherboard You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 25 Bit 7: Reserved. Bit 6: Reserved. Bit 5: Reserved. Bit 4: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer. = 0: the Cash Drawer opened. Bit 3: Reserved. Bit 2: Cash Drawer “DOUT bit0” pin output control. = 1: Opening the Cash Drawer = 0: Allow closing the Cash Drawer Bit 1: Cash Drawer “DOUT bit1”...

  • Page 26: For B68/B98/C48 Motherboard

    4-7-2. For B68/B98/C48 motherboard You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Below cash drawer installation is applicable for B68, B98 and C48 motherboard. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1...
  • Page 27 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 28: Specification

    Specification Motherboard Fan/Fanless Fanless Fanless Fanless (performance) (Performance) Intel Celeron Intel Celeron Intel Atom N270 Intel Celeron M 1.5GHz M 1.86GHz / Intel Pineview D525 CPU Support processors 1.6G M ULV 1.0GHz / Pentium Core duo 2.0GHz / dual core 1.8G L2 1M, FSB800MHz (BGA) (BGA)
  • Page 29 Motherboard Cash Drawer Port 1 x RJ 11 (12V /19V) Audio Jack 1 x Line-out, 1 x Mic-in Audio Built in Speaker 2x2W 2x2W Power Power Adapter 19V, 90W Control Power Button Peripheral Metal MSR 3 Tracks MSR ( PS/2 ) Metal Customer Flush mount VFD display 2 x 20 characters (COM) Display...

  • Page 30: Jumper Setting

    Jumper Setting 6-1. For B68 Motherboard 6-1-1. Motherboard Layout Version: B68 v1.0...

  • Page 31: Connectors & Functions

    6-1-2. Connectors & Functions Connector Purpose BAT1 CMOS Battery Base ( Use CR2023) Power On Button Touch Sensor Power LED SATA1 HDD Power Connector SATA2 HDD Power Connector LCD Interface Connector IrDA Connector For External Touch Connector Inverter Connector CN10 Card Reader Connector CN11 Line Out...
  • Page 32 Connector Purpose SATA2 SATA Connector SKT1 SPI ROM USB1 USB1, USB2 USB2 USB3, USB4 Power On Bottom CRT Connector CRT Power/I2C Connector COM3/COM4 Power Setting VGA Power Setting COM2 Connector COM2(RS232/422/485) Setting LCD ID Setting RTC Reset Power Mode Setting JP11 Cash Drawer Power Setting (+12V,+19V) JP12...

  • Page 33: Jumper Setting

    6-1-3. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 5 7 9 11 ▲RS232 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 COM3 &...
  • Page 34 Cash Drawer Power Setting Function JP11 ▲+12V +19V Power Mode Setting Function ▲ATX Power AT Power RTC Reset Function ▲CMOS Normal CMOS Reset VGA Power Setting Function ▲No Power +12V ▲ = Manufacturer Default Setting...
  • Page 35 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel LVDS 1366 x 768 Single Panel LVDS 1440 x 900 Dual Panel LVDS 1920 x 1080 Dual Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 800 x 600 Single...

  • Page 36: For B78 Motherboard

    6-2. For B78 Motherboard 6-2-1. Motherboard Layout Version: B78 v2.2...

  • Page 37: Connectors & Functions

    6-2-2. Connectors & Functions Connector Purpose BAT1 CMOS Battery Base ( Use CR2023) Audio Line Out Audio MIC In Internal Power Switch Speaker & MIC Connector CD-IN Connector CN11 Power Connector For 3.5" HDD CN13 COM5 for Touch CN15 CPU FAN Connector CN16 Hardware Reset CN18...

  • Page 38: Jumper Setting

    6-2-3. Jumper Setting COM2 RS232/485/422 Setting Function JP10 5 7 9 5 7 9 ▲RS232 8 10 6 8 10 5 7 9 11 5 7 9 RS485 6 8 10 12 8 10 5 7 9 11 5 7 9 RS422 8 10 COM3 &...
  • Page 39 Cash Drawer Power Setting Function ▲+12V +19V Power Mode Setting Function ▲ATX Power AT Power CMOS Operation Mode Function ▲CMOS Normal CMOS Reset USB Path Setting Function JP14 ▲To Docking To Motherboard System Indicator Function Function JP13 ▲Disable Enable ▲ = Manufacturer Default Setting...
  • Page 40 LCD ID Setting LVDS Panel# Resolution Bits Channel 640 x 480 Single 800 x 600 Single 1024 x 768 Single 1280 x 1024 Dual 1024 x 768 Single 800 x 600 Single 800 x 600 Single 800 x 600 Single 1024 x 768 Single 1440 x 900...

  • Page 41: For B98 Motherboard

    6-3. For B98 Motherboard 6-3-1. Motherboard Layout Version: B98 v1.0...

  • Page 42: Connectors & Functions

    6-3-2. Connectors & Functions Connector Purpose BAT3 CMOS Battery Base (Use CR2023) Audio Line Out MIC In Internal Power On Switch Connector Speaker & MIC Connector Internal LAN LED CN11 CD-IN / Line-In Connector CN12 LCD Interface Connector CN13 IrDA Connector CN14 Inverter Connector CN15...

  • Page 43: Jumper Setting

    6-3-3. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 11 5 7 9 ▲RS232 6 8 10 12 6 8 10 5 7 9 5 7 9 RS485 8 10 6 8 10 5 7 9 11 5 7 9 RS422 8 10 COM3 &...
  • Page 44 Cash Drawer Power Setting Function ▲+12V +19V Power Mode Setting Function JP11 ▲ATX Power AT Power CMOS Operation Mode Function ▲CMOS Normal CMOS Reset System Indicator Function JP12 ▲Disable Enable ▲ = Manufacturer Default Setting...
  • Page 45 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel LVDS 1366 x 768 Single Panel LVDS 1440 x 900 Dual Panel LVDS 1920 x 1080 Dual Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 800 x 600 Single...

  • Page 46: For C48 Motherboard

    6-4. For C48 Motherboard Motherboard Layout 6-4-1. Version: C48 v2.1...

  • Page 47: Connectors & Functions

    Connectors & Functions 6-4-2. Connector Purpose Power Button Connector Printer Port Reset Printer Port CN5/8 HDD Power CN11 COM5 For Touch CN13 Card Reader Connector CN14 Line out CN15 HDD LED CN16 Speaker & MIC CN17 CD IN CN18 MIC IN CN19 Power LED CN20/JP10...

  • Page 48: Jumper Setting

    Jumper Setting 6-4-3. COM2 RS232/485/422 Setting Function 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 Cash Drawer Power Setting...
  • Page 49 System Indicator Function JP10 ▲Disable Enable Inverter Selection Function JP14 ▲ CCFL CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’.
  • Page 50 COM3 & COM4 Power Setting For C48, COM3/COM4 power adjustment must be made by BIOS/Utility and Jumper. Since COM3/COM4 default is “None“ meaning no power, power must be on through BIOS prior to physical jumper change. BIOS/Utility setup Press <DEL> key to enter BIOS SETUP UTILITY when system boot up.
  • Page 51 LCD ID Setting Several configurations are applied to different sizes of panel. Please refer to the followings to complete relevant settings. 12.1"/15" Terminal Physical Jumper Setting LVDS Resolution Output Interface Bits Channel 800 x 600 Single 1024 x 768 Single 1366 x 768 Single 1st: LCD Panel...
  • Page 52 4. To switch on the power, select "+12V". Please save the change before exiting BIOS to avoid data lost. 5. To switch brightness level, select brightness control and choose level. Please save the change before exiting BIOS to avoid data lost.

  • Page 53: Appendix: Drivers Installation

    Appendix: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.
