Radius W-300 User Manual

W-300
Wireless Headset
User Guide
KEM-ML33803B

Introduction

Please observe the following to ensure reliable operation of the headset:
Read this manual thoroughly and observe the operating instructions and information
provided.
Place the base station on a non-slip surface and lay the connection cables so they cannot be
the source of an accident.
Do not expose the equipment to extreme temperatures or high relative humidity and protect
it from direct sunlight and dusty conditions.
Clean the equipment with a soft, damp cloth. Do not use any solvents or aggressive cleaning
agents.
Only connect approved accessories.
Only use the adapter supplied.
Never open the unit. Opening the unit annuls claims under the terms of guarantee and
exposes the person to the risk of an electric shock.
Repairs to defective units should only be carried out by service centres recommended by the
sales outlet.
We recommend removing the batteries if the equipment is not to be used for longer periods.
Only replace the batteries with types recommended by us. Dispose of defective batteries
according to the applicable local laws (not in household waste). We assume no liability for
damage caused by using the equipment for unintended purposes.
European Communities (EC) RF Radiation Exposure Statement: The installation of the base
unit should allow at least 20 centimetre between the base and persons in compliance with
EC RF exposure Council Recommendation
Declaration of conformity
Company:
Address:
Declare that the product DECT W300 is in compliance with the Annex III of the R&TTE-Directive
1999/5/EC and then with the following essential requirements:
Article 3.1.a (protection of the health & the safety of the user) : EN60950-1:2006+A11: 2009
+A1:2010
Article 3.1.b (protection requirements with respect to electromagnetic compatibility : ETSI
EN301489-6 V1.3.1 (2008-08 ) & ETSI EN301489-1 V1.8.1 (2008-04 )
Article 3.2 (effective use of the radio spectrum) EN301406 V2.1.1(2009-07)
The presumption of conformity with essential requirements regarding Council Directive
1999/5/EC is ensured.
Signature :
DECLARATION OF CONFORMITY
Date :
We cannot guarantee the information which relates to the technical properties or that contained
in this document is correct. The product and its accessories described in this document are
subject to constant improvement and further development. For this reason, we reserve the right
to modify components, accessories, technical specifications and related documentation of the
product described herein without notification.

Battery Safety Precautions

Do not burn, disassemble, mutilate, or puncture. Like other batteries of this type, toxic materials
could be released which can cause injury y .
To reduce the risk of fire or personal injury y , use only the battery listed in User's Guide.
Keep batteries out the reach of children.
Remove batteries if storing for over 30 days.
Make sure your package includes the following items:

Packing contents

Base Station
Wireless Headset
AC-DC adaptor
Li-Polymer battery pack
for the Wireless Headset
Head Band

Headset and Base Layouts

English
E
1
1 Slide Switch
2 Talk/End key
3 Mute key
4 LED
5 Name Card

Setup the wireless headset

Electrical outlet
AC-DC adaptor for base unit
1
Solo pack Packing contents Solo pack
1 EU adaptor transform plug 1
1 1
UK adaptor transform plug
1 Headset Cushion 2
4
Name Tag
1
1
Manual
1 Telephone Handset Lifter Optional
7
2
3
4
5
6
9
10
11
12 13 14 15
8
6 LED 11 Listening +/- key
7 LED 12 Power jack
8 Microphone 13 Lifter
9 Microphone +/- key 14 Phone
10 Register key 15 Handset
Base unit
Desktop phone
Lifter
E
1. Unplug the handset cord from phone.
2. Plug the phone cord that is connected to the base into the handset jack on the phone.
CAUTION: Your phone may have two similar jacks. Put the cord only in the jack from which the
handset came.
3. Plug the handset cord into the handset jack in the bottom of the base.
4. Plug the AC charger into an outlet and into the base's AC charging jack.
NOTE: Place the Base unit apart the Desktop Phone at least 15cm to avoid interference.
CAUTION:
Plug the adapter into the nearest mains socket. USE ONLY WITH PROVIDED
ADAPTER. Using other power supplies may damage the unit and voids warranty.
Warning:
The headset does not work and damaged if the wrong battery are inserted. Risk of
explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the
instruction.

Install Headset battery

1. Lift up the door of battery on the headset.
2. Connect the battery plug to the headset plug.
Note: 1. The headset battery is disconnected before shipment.
2. Connect the battery plugs carefully without removing the battery out from the Headset.

Install Headband and headset cushion

1. Snap the headset speaker into the retaining
ring of desired wearing position.
NOTE:
1. The retaining ring is made with rapid prototype plastic. Adjust the headband slowly and
carefully.
2. Please do not swap Headset and headband. Each headband is fit for the paired Headset only.

Setup Handset Lifter (Optional)

1. Plug handset lifter power cord into handset lifter jack on base. Push firmly into base.
2. Position handset lifter under the handset on your phone. Verify that the lifter is located on top
of the telephone speaker.

LED state

1. LED Flashing Pattern
Flashing Pattern LED ON-OFF sequence
Normal flashing ON (1 sec), OFF (1 sec)
Fast flashing ON (250 ms), OFF (250 ms)
Moderate Flashing ON (500 ms), OFF (500 ms)
Slow flashing ON (2 sec), OFF (2 sec)
Very slow flashing OFF (8 sec), ON (2 sec), OFF (2 sec) ,
ON (2 sec)
2
E
2. Place the headset cushion onto the
headset speaker.
3
