U S E R G U I D E
CONTENTS

1.1 Parts supplied

1.2 Installation

4. Congestion zone warning

6.2 General

1. GENERAL
1.1 Parts supplied
RoadPilot microGo
Power cable
USB cable
CD-Rom containing synchronisation software which
enables the camera database to be updated via the
internet (Windows 2000, XP or Windows Vista). The
CD will guide you through the installation process for
the RPSync software.
I s s u e 1 . 6
Mounting bracket
1.2 Installation
1. Fix bracket to windscreen using suction cup -
Lift clamp
To remove, lift the locking clamp and gently pull on
the tab on the suction cup.
2. Plug in power cable -
Ext. antenna (optional)
Note - the cables should be fed through the bracket
before connecting to the microGo.
3. Clip microGo to bracket
4. Plug cable into cigarette lighter
Swivel antenna to get
best view of sky
Note - the first time microGo is powered up it may
take a few minutes to obtain a GPS fix (cold start).
Note - you must load the CD-Rom and register in
order to perform downloads of new speed camera
locations etc.
Warning - cutting or modifying the cigarette lighter
plug/power cable or the use of non-genuine RoadPilot
cables will invalidate the warranty.
- 1 -
Lock clamp
Power
Slacken to adjust
bracket angle
Suction
cup tab
12-24v DC
