Page 2
1. DESCRIPTION OF EQUIPMENT 1. TYPE OF THE CIRCUIT A. BASE UNIT RECEIVER ; Double conversion superheterodyne receiver B. HANDSET RECEIVER ; Double conversion superheterodyne receiver 2. FREQUENCY AND CHANNELS A. BASE UNIT CT1+ 959.0125 – 959.9875MHz 930.0125MHz – 931.9875MHz 914.0125 –...
Page 3
2. CIRCUIT DESCRIPTION A. BASE UNIT 1. Power supply circuit The DC 9V from the AC adaptor is supplied to JP3 (DC modular jack). This input voltage is supplied to the main circuit through D8 (diode) and supplied to the charge circuit.
Page 4
Speech network adjusts a transmit signal gain and sends it to the telephone line through switching transistor Q3, bridge diode (D1, D2, D3 and D4) and modular jack JP1. 5. Sending and Receiving of data signal The sending MSK data comes out from TX_DATA of CPU (pin 43), and enters into pin 4 of U10 (compander).
Page 5
During the pulse comes out, the CPU makes the Q5 on by maintaining PPD_CON (pin 25 of CPU) high, in this time the switching board will acknowledge the dial clearly by the occurance of the low impedance. 10. EEPROM U6 is the EEPROM. This stores the identification code which are inherent to pair of base unit and handset to safe guard against interference.
Page 6
B. Base RF Section Frequencies [ CT1 ] RX VCO Base unit : f = (f - 21.7MHz) / 2 = 446.39375MHz (20CH) Handset = (f + 21.7MHz) / 2 = 490.59375MHz (20CH) LOCA L Base unit - 21.7MHz = 892.7875MHz (20CH) LOCAL Handset + 21.7MHz = 981.1875MHz (20CH)
Page 7
1. RX VCO circuit RX VCO circuit is configured by Q305, Q306, D302 (varicap diode), L301 (air coil), and some additional passive parts. The control voltage from pin 14 (charge pump out) of the U302 (PLL IC) is supplied to the D302 cathode through passive loop filter (C336, C337, C338, R329, R330, R331) to control the oscillation frequency.
Page 8
Carrier frequency is adjusted correctly by CV301. 4. Receiver RF section Modulated RF carrier from the antenna is filtered by F306 and amplified by Q304. Amplified signal is filtered again by F307. RF carrier and RX local oscillator output from Q305 are mixed at Q303 (1st mixer), then the signal is converted into the 21.7MHz (1st IF frequency).
Page 9
C. Handset 1. Power control circuit 3.6V DC power is supplied from the battery through JP2. U4 has 3 regulated outputs (VREG0, 1, 2) controlled by BS0, BS1 and BS2 respectively. In receiving mode, the BS0 (pin 23 of U5) becomes low, then the receiver part of RF block is supplied with the power of 3.2V from VREG0 (pin 15 of U4).
Page 10
5. Sending and Receiving of data signal The sending MSK data comes out from TX_DATA of CPU (pin 49), and enters into pin 4 of U2(compandor). It is modulated at RF block through the same path as audio signal. The received MSK data which is demodulated at RF block with the same manner as audio signal is going to the low path filter composed of U3B, C32, C33, C34, R30, R31 and R32.
Page 11
D. Handy RF Block Section The RF part of handset is same as base unit.
Page 12
Q308 BFQ67 BFQ67 BFQ67 VCC_VCO VCC_AMP BRF_4_2 BRF_4_3 C366 100P C371 C374 C809,C810 L301,L302 0.35*1.55*1.0+3.0R/NA 0.35*1.45*1.0+3.0R/NA Q306 2SC5620 2SC4226 FOR M/P ROADSTAR CLT-700 Title CT1 BASE UNIT RF Size Document Number CT1_VISION_BRF_ 4_3 Custom Date: Thursday, February 22, 2001 Sheet...
Page 13
R102 R103 680R VCC_AMP CHARGE VCC_VCO RSSI_H/L RSSI_DETECT TCET1103K TX_DATA PLL_STB CHG-1 PLL_DATA PLL_CLK DEMOD_AUDIO DBL324V MOD_AUDIO PCB1 MOD_AUDIO TX_BIAS CTR37 & CTR38 FOR_M/P_ROADSTAR_2001-2 ROADSTAR CLT-700 Title BASE MAIN Size Document Number ita_vision_b4_2 R Date: Sheet Friday, March 23, 2001...
Page 14
RSSI_H/L PLL_STB PLL_DATA VREG2 10U/10V(T) 10U/10V(T) 100P PLL_CLK PGM/CALL TRANS DEMOD_AUDIO MOD_AUDIO (CT1) CT1/+ REDIAL (CT1+) (ENABLE) (DISABLE) CTR37 & CTR38 FOR_M/P_ROADSTAR_2001_02 ROADSTAR CLT-700 Title HANDSET MAIN - CT Size Document Number ct1_vision_h 4_2R Date: Sheet Friday, March 23, 2001...
