Foursevens Mini M2A Operator's Manual

Model
MA
POWER One AA battery
(up to 1.5 volts)
High: 90 lumens
OUTPUT
Low: 2.7 lumen
Runtime at High: 1.3 hours
RUNTIME
Runtime at Low: 2.5 days
Strobe, S.O.S and Beacon
STROBE
flash modes
105*75
Comparison Table
Quark Mini Models:
MA ML MLR2 M2A
Battery Type AA Battery X X
X
Lithium CR123A
CR2 Battery X
X
Operating Voltage 0.9V-1.5V
0.9V-3.0V X X X
X X X X
Output Modes 3 Levels
X X X X
Strobe, SOS, Beacon
Features Fully Knurled X X X X
X X X X
Premium Cree XP-G
AR Coated Lens X X X X
X X X X
IPX-8 Waterproofing
7 Modes X X X X
10-Year Performance Guarantee X X X X
Operation
Operating your Mini MA is simple. Make sure battery is inserted with the positive
side (+) toward the head. To turn it on, tighten the bezel ('head') fully down. The
Mini MA will turn on when the bezel is fully tightened, and turn off when the bezel is
loosened.
Selecting Regular Outputs
To select a different output level, turn the Mini MA off and then on again within 1
second. This will select the next level of output in the following sequence:
High
Low Medium
If the Mini MA is turned off for 2 seconds or longer, it will revert back to Low.
Selecting Special Outputs
The Mini MA has 4 special output modes: Strobe, S.O.S., Beacon (Hi), and
Beacon (Lo). To access these modes, quickly switch through two full 'cycles' of the
regular outputs, starting with Low. The two full cycles must be completed within 3
seconds:
Low Medium High Low Medium High Special Outputs
You can continue to cycle through the special outputs in the following sequence:
Beacon(Hi) Beacon(Lo)
Strobe SOS
After Beacon (Lo) mode, the output reverts back to Regular Low. Both Beacon modes
will first flash 5 times and then once every 10 seconds.
MA ML MLR2 M2A
180
Lumens (out the front) High 90 180 180
Low 2.7 3.0 3.0 3.0
High (hours) 1.2 0.67 1.7
Output Runtimes 1.3
Low (days) 6.25 1.2 3.4
2.5
Dimensions Length (in)
3.0 2.3 2.0 5.0
Diameter (in) 0.7
0.7 0.8 0.75
Weight (oz) 0.62 0.6 1.0
0.67
Specifications
Dimensions Power Source
Length: 3.0 in One AA Battery
Diameter: 0.7 in Operating Range: 0.9V~1.5V
Weight: 0.67 oz
Typical Output and Runtimes
Output (out the front)
Mode Runtime
Low 2.5 days
2.7 lumens
Medium 25 lumens 18 hours
High 90 lumens 1.3 hours
Special Output
Strobe 12 hours
S.O.S. 4 hours
Beacon (high)
20 hours
Beacon (low)
100 hours
MA
OPERATOR'S MANUAL
Warranty
FOURSEVENS warrants its products to be free from defects in materials and
workmanship. We will repair or replace, at our option, without charge any product or
part which is found to be defective under normal use and service within 120 months
from the date of purchase with proof of purchase. Such repair or replacement shall
be the purchaser's sole and exclusive remedy under this warranty. This warranty
does not cover normal maintenance and service and does not apply to any products
or parts which have been subject to modification, misuse, abuse, negligence,
accident, or improper maintenance or repair by anyone other than FOURSEVENS.
