Specification
Model
WIP80-G20
Pick up Element
Color 1/3" PC1099 CMOS
Effective Picture Ele-
728(H)×488(V)
ments (H×V)
Horizontal Resolution
1000TV Line
Minimum Illumination
0.1Lux
S/N Ratio
More than 50dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic
0.45
20 Meters (with ￠5X24PCS Infrared LED)
IR Distance
IR Status
Under 10Lux by CDS
IR Power On
CDS AUTO Control
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
DC12V (+/-10%)/350mA
Power/Current
Lens
Board Lens 3.6mm / F2.0
Dimension (mm)
175(W) x69(H) x55(D)mm
Weight (g)
500
Storage Temperature
-30~+60℃ RH95% MAX
Operating Temperature
-10~+45℃ RH95% MAX
Packing List
No
Name
1.
Weatherproof IR Color Cameras
2.
User Guide
Franchiser：
Model
Number
WIP80-G20
1
WIP80-G20
1
WIP80-G20 Color Camera
IR Color Camera
Weatherproof
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Advertisement
Table of Contents
Summary of Contents for Wodsee WIP80-G20
- Page 1 Specification WIP80-G20 Color Camera Model WIP80-G20 Pick up Element Color 1/3" PC1099 CMOS Effective Picture Ele- 728(H)×488(V) ments (H×V) Horizontal Resolution 1000TV Line Minimum Illumination 0.1Lux IR Color Camera S/N Ratio More than 50dB Weatherproof Scanning System 2:1 interface Synchronous System Internal, Negative sync.
- Page 2 Fixing and using this model are con- can get high definition picture in low Lux condition. venient too. It is very good for you to apply to your CCTV DC12V WIP80-G20 system. * Auto Electronic Shutter (AES) Please read this instruction manual carefully to en- Built-in auto electronic shutter function.
